BCM MX56N Startup Manual

Amd g-series apu with a55e controller hub (fch) mini itx motherboard
Hide thumbs Also See for MX56N:
1
2
3
4
5
6

Advertisement

Table of Contents

MX56N
AMD G-Series APU with A55E Controller Hub (FCH) Mini ITX Motherboard
Startup Manual
Ver. 1.0
BCM Advanced Research, An Industrial Leader Since 1990 in Industrial Motherboards & Systems
11 Chrysler, Irvine, CA 92618 USA | www.bcmcom.com | (PH)949.470.1888 | (FAX)949.470.0971
For Tech Support, please visit www.bcmcom.com/bcm_support_legacyProductSupport.htm or contact
BCMTechSupport@bcmcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX56N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BCM MX56N

Summary of Contents for BCM MX56N

  • Page 1 AMD G-Series APU with A55E Controller Hub (FCH) Mini ITX Motherboard Startup Manual Ver. 1.0 BCM Advanced Research, An Industrial Leader Since 1990 in Industrial Motherboards & Systems 11 Chrysler, Irvine, CA 92618 USA | www.bcmcom.com | (PH)949.470.1888 | (FAX)949.470.0971 For Tech Support, please visit www.bcmcom.com/bcm_support_legacyProductSupport.htm or contact...

  • Page 2: Packing List

    Packing List Before you begin installing your single board, please make sure that the following parts have been shipped. 1 x AA55E-IF Mini ITX Main board  1 x CD-ROM contains OS drivers  1 x CPU Cooler  1 x SATA cable ...

  • Page 3: Product Overview

    Product Overview...

  • Page 4: Specifications

    Specifications System AMD G-Series DC T56N 1.6GHz/T48N 1.4GHz/T40N 1.0GHz/ SC T44R 1.2GHz AMD A55E Controller Hub (Hudson-E1) AMI 16Mb SPI BIOS AMD G-Series+A55E Controller Hub System Chipset Winbond W83627DHG-P I/O Chipset One 204-pin SODIMM sockets support up to 4GB DDR3 1066 MT/s Memory CFast connector on the back Reset: 1 to 255 sec/min per step...
  • Page 5 Jumpers Label Function Note CMOS1 Clear CMOS Normal * Clear CMOS JSETCOM3, COM3, COM4 RI/+5V/+12V +12V COM3 JSETCOM4 COM4 +12V PSON1 AT MODE ATX MODE AT/ATX Mode Select 3.3V JBL3 LCD POWER (VDDSAFE) Connectors Label Function Note COM3, COM4 Serial Port COM3 COM4 Connector...

  • Page 6: Spdif Out

    LVDS1 18-bit LVDS Connector JBL1 Inverter PWR SPI connector AAFP Audio Mic.-In & Line-Out Connector SPDIF_OUT1 SPDIF OUT CN10 Amp_R+ R-/ Amp_L+ L-...
