BCM MX852-C6 User Manual

Embedded motherboard all-in-one celeron m mini-itx board with lvds fp, audio out,4 com ports, 6 usb 2.0 and 10/100 ethernt
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Embedded Motherboard
MX852-C6
All-in-One Celeron M Mini-ITX Board
With LVDS FP, Audio out,4 COM Ports,
6 USB 2.0 and 10/100 Ethernet
User's Manual
http://www.bcmcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX852-C6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BCM MX852-C6

Summary of Contents for BCM MX852-C6

  • Page 1 Embedded Motherboard MX852-C6 All-in-One Celeron M Mini-ITX Board With LVDS FP, Audio out,4 COM Ports, 6 USB 2.0 and 10/100 Ethernet User’s Manual http://www.bcmcom.com...
  • Page 2 (where applicable). References: This manual is created and written by BCM Technical Dept., but not limited, to the information from the MX852-C6 External Production Specifications, and MX852-C6 Specifications. If any comments, suggestions, or errors on this manual, please write an e-mail to support@bcmcom.com.
  • Page 3 Compliance & Certificate & & ISO 9001 Certificate: This device was produced in our plant with advanced quality system certified by DNV QA Ltd. in according to ISO 9001. This Certificate is valid for: DESIGN & MANUFACTURE OF MOTHERBOARD AND PERSONAL COMPUTERS. CE Declaration: CE marking is a visible declaration by the manufacturer or his authorized representatives that the electrical equipment to which it relates satisfies all the provisions of the 1994...
  • Page 4 Easy Installation Easy Installation Steps The following “Easy Installation” steps are for users accustomed to the assembly of a computer system. For those individuals requiring more specific information, please refer to the more detailed descriptions located within the latter chapters of this manual. Note: You must keep your power cable unplugged until the following installation steps are completed.

  • Page 5: Table Of Contents

    TABLE OF CONTENT USER’S NOTICE MANUAL REVISION INFORMATION COOLING SOLUTIONS CHAPTER 1 INTRODUCTION OF MX852-C6 MOTHERBOARD 1-1 FEATURE OF MOTHERBOARD 1-2 SPECIFICATION 1-3 SYSTEM DIAGRAM 1-4 JUMPER & CONNECTOR CHAPTER 2 HARDWARE INSTALLATION 2-1 HARDWARE INSTALLATION STEPS 2-2 CHECKING MOTHERBOARD'S JUMPER SETTING...

  • Page 6: User's Notice

    Item Checklist MX852-C6 80 wire ATA66/100 IDE cable 34 wire Floppy cable Audio line out cable CD for motherboard utilities Standard I/O Shield for MX852-C6 MX852-C6 User’s Manual on CD (Digital Format) MX852-C6 Quick Reference Guide Custom CPU Heat Sink...
  • Page 7 Intel Celeron M Processor Family The MX852-C6 has been design with Intel® 852GM GMCH and Intel® ICH-4 for Embedded Computing, with build-in optimized integrated graphics solution with a 400 MHz system bus and integrated 32-bit 3D core at 133 MHz. It features a low-power design, supports the Intel®...

  • Page 8: Feature Of Motherboard

    82562ET Ethernet controllers (support 10/100 Base-TX Ethernet), Audio Line-Out and 4 COM ports, besides the MX852-C6 with four USB2.0 ports on rear panel and two internal USB2.0 ports header. This board meet today market demand of low power consumption, for POS, Kiosk and embedded applications.

  • Page 9: Specification

    1-2 Specification Spec Description ∗ Design Mini ITX form factor 6 layers PCB size: 6.69”(W) x 6.69”(D) (170 x 170 mm) ∗ Chipset Intel 82852GM GMCH Chipset ∗ Intel 82801DB ICH4 Chipset ∗ Intel Celeron M 600Mhz processor 0 Cache. ∗...

  • Page 10: System Diagram

    1-3 System Diagram MX852-C6 Mainboard Diagram...

  • Page 11: Jumper & Connector

    Jumper & Connector LAN LED CD-In Line-Out Ext. KB/ COM 2 COM 3 USB 4/5 COM 4 BIOS WP DFP LVDS LED VCC CF Slot System Fan CPU Fan Clear CMOS Auto PWR-On Floppy Front Panel Primary/ Secondary ATX Power DDR DIMM...
  • Page 12 Jumpers Jumper Name Description Page Reserved (FSB Settings) 2-pin Block LVDS Voltage Settings Select 3-pin Block Clear CMOS Settings Select 3-pin Block Auto Power ON 2-pin Block BIOS Write Protect 3-pin Block Connector / Header Socket/Slot Name Description Page CRT VGA Port Front Panel DB-15C Female Connector COM1 DB9 Connector...

  • Page 13: Chapter 2 Hardware Installation

    Chapter 2 Hardware installation 2-1 Hardware installation Steps Before using your computer, you had better complete the following steps: 1. Check motherboard jumper setting 2. Install CPU Heatsink 3. Install System Memory (DIMM) 4. Install Expansion cards 5. Connect IDE and Floppy cables, Front Panel /Back Panel cable 6.

  • Page 14: Install Cpu

    2-3 Install CPU 2-3-1 Glossary Chipset (or core logic) – A highly integrated circuits which control the interfaces between the system processor, RAM, I/O devises, and adapter cards. Processor slot/socket - the slot or socket used to mount the system processor on the motherboard.

  • Page 15: About Intel Celeron M 600 Cpu

    2-3-2 About Intel Celeron M This motherboard provides with build in Celeron M 600MHz with 32K L1 cache, 0K L2 cache processor. The combination of Celeron M 600MHz and 852GM chipsets provide a x86-base low cost, low power, low heat dissipation and high compatibility solution for mobile embedded application.

  • Page 16: Install Memory

    2-4 Install Memory This motherboard provides one 184-pin DIMM (DUAL INLINE MEMORY MODULES) sites for memory expansion available to maximum memory size of 1.0GB DDR SDRAM. • Support 128Mb, 256Mb, 512Mb technologies implemented as x8, x16 devices. • Non-ECC DIMMS. Valid Memory Configurations Bank 184-Pin DIMM...

  • Page 17: Expansion Card

    2-5 Expansion Cards WARNING! Turn off your power when adding or removing expansion cards or other system components. Failure to do so may cause severe damage to both your motherboard and expansion cards. 2-5-1 Procedure For Expansion Card Installation 1. Read the documentation for your expansion card and make any necessary hardware or software setting for your expansion card such as jumpers.

  • Page 18: Interrupt Request Table For This Motherboard

    2-5-3 Interrupt Request Table For This Motherboard Interrupt request are shared as shown the table below: INT A INT B INT C INT D INT E INT F INT G INT H Slot 1 INTB# INTC# INTD# INTA# IMPORTANT! If using PCI cards on shared slots, make sure that the drivers support “Shared IRQ”...

  • Page 19: Connectors, Headers

    2-6 Connectors, Headers 2-6-1 Connectors Power Connector (20-pin block): ATXPWR (CN22) ATX Power Supply connector is a 20-pins connector comply with Intel ATX standard. The ATX Power Supply allows to use soft power on with a momentary switch that connect from the front panel switch to 2-pins Power On jumper pole on the motherboard.
  • Page 20 Floppy drive Connector (34-pin block): FDD (CN19) This connector supports the provided floppy drive ribbon cable. After connecting the single plug end to motherboard, connect the two plugs at other end to the floppy drives. Signal Signal DRVDEN0# DRVDEN1# INDEX# MOA# DSB# DSA#...

  • Page 21: Headers

    (11) Secondary IDE Connector (40-pin block): IDE2 (CN20) This connector connects to the next set of Master and Slave hard disks. Follow the same procedure described for the primary IDE connector. You may also configure two hard disks to be both Masters using one ribbon cable on the primary IDE connector and another ribbon cable on the secondary IDE connector.
  • Page 22 Audio Header (4-pin): AUDIO Line-Out: (CN9) This header connects to Front Panel Line-out, MIC connector with cable. Signal Line Out L AU_GND AU_GND Line Out R Pin 1 Audio Line-Out USB Port Headers (9-pin): USB 4/5 (CN12) These headers are used for connecting the additional USB port plug. By attaching an option USB cable, your can be provided with two additional USB plugs affixed to the back panel.
  • Page 23 PC-Speaker connector: CN21 (1, 7) This 2-pin connector connects to the case-mounted speaker. IDE Activity LED: IDE LED CN21 (9, 11) This connector connects to the hard disk activity indicator light on the case. Reset switch lead: RESET CN21 (13, 15) This 2-pin connector connects to the case-mounted reset switch for rebooting your computer without having to turn off your power switch.
  • Page 24 (12) LCD Panel and Inverter Header (40-pin): LVDS (CN15) LCD Panel Connector HIROSE DF-13-40DP-1.25V Signal Signal YA0- YA1- YA0+ YA1+ YA2- CLKA- YA2+ CLKA+ YA3- YB0- YA3+ YB0+ Signal name Description YB1- YB2- CLKB+, CLKA+ Positive LVDS differential clock2 & clock1 YB1+ YB2+ CLKB-, CLKA-...
  • Page 25 (15) Auto Power On 1-2 Open ( ATX Power On) 1-2 Close (On) Auto Power On (16) BIOS Write Protect (JP5) 1-2 BIOS Protect 2-3 Normal (Default) BIOS Write Protect...

  • Page 26: Starting Up Your Computer

    2-7 Starting Up Your Computer 1. After all connection is made, close your computer case cover. 2. Be sure all the switch are off, and check that the power supply input voltage is set to the local voltage, usually in-put voltage is 220V∼240V or 110V∼120V depending on your country’s voltage used.

  • Page 27: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS The BIOS is a program located on a Flash Memory on the motherboard. This program is a bridge between motherboard and the operating system. When you start the computer, the BIOS program gain control. The BIOS first operates a self-diagnostic test called POST (Power On Self Test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 28: The Main Menu

    Once you enter Award ® BIOS CMOS Setup Utility, the Main Menu (Figure 3-1) will appear on the screen. The Main Menu allows you to select from fourteen setup functions and two exit choices. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.
  • Page 29 Use this menu to specify your settings for frequency clock control. Load Fail-Safe Defaults Use this menu to load the BIOS default values that are factory settings for the stable performance system operation. Load Optimized Defaults Use this menu to load the BIOS default values that are settings for optimal performances system operations.

  • Page 30: Standard Cmos Features

    3-4 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.
  • Page 31 If you select Manual, related information is asked to be entered to the following items. Enter the information directly from the keyboard. This information should be provided in the documentation from your hard disk vendor or the system manufacturer. If the controller of HDD interface is SCSI, the selection shall be “None”. If the controller of HDD interface is CD-ROM, the selection shall be “None”...

  • Page 32: Advanced Bios Features

    3-5 Advanced BIOS Features Phoenix – AwardBIOS CMOS Setup Utility Advanced BIOS Features ► CPU Feature [Press Enter] ► Hard Disk Boot Priority [Press Enter] Item Help Virus Warning [Disabled] CPU L1 & L2 Cache [Enabled] Quick Power On Self Test [Enabled] Menu Level >...
  • Page 33 Enabled Activates automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector of hard disk partition table. CPU L1 & L2 Cache The default value is Enabled. This option enables the Level 1 cache memory. Enabled (default) Enable cache Disabled Disable cache...
  • Page 34 Gate A20 Option Normal The A20 signal is controlled by keyboard controller or chipset hardware. Fast (default) The A20 signal is controlled by port 92 or chipset specific method. Typematic Rate Setting Keystrokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected.

  • Page 35: Cpu Feature

    3-5-1 CPU Feature Phoenix – AwardBIOS CMOS Setup Utility Advanced Chipset Features Thermal Management [Thermal Monitor 1] Item Help Menu Level > ↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Optimized Defaults F7:Standard Defaults Thermal Management The selection available are: Thermal Monitor 1 <...

  • Page 36: Advanced Chipset Features

    3-6 Advanced Chipset Features The Advanced Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer. Phoenix – AwardBIOS CMOS Setup Utility Advanced Chipset Features DRAM Timing Selectable [By SPD] CAS Latency Time...

  • Page 37: Dram Timing Settings

    DRAM RAS# to CAS# Delay This field lets you insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. Fast gives faster performance; and Slow gives more stable performance. This field applies only when synchronous DRAM is installed in the system.
  • Page 38 AGP Aperture Size (MB) This field determines the effective size of the Graphic Aperture used for a particular GMCH configuration. It can be updated by the GMCH-specific BIOS configuration sequence before the PCI standard bus enumeration sequence takes place. If it is not updated then a default value will select an aperture of maximum size.

  • Page 39: Integrated Peripherals

    3-7 Integrated Peripherals Phoenix – AwardBIOS CMOS Setup Utility Integrated Peripherals ► OnChip IDE Device [Press Enter] ► Onboard Device [Press Enter] Item Help ► SuperIO Device [Press Enter] Onboard LAN Boot ROM [Disable] Onboard Serial Port 1 [3F8] Menu Level > Serial Port 1 Use IRQ [IRQ3] Onboard Serial Port 2...

  • Page 40: Onboard Ide Function

    3-7-1 OnChip IDE Device Settings Phoenix – AwardBIOS CMOS Setup Utility OnChip IDE Device On-Chip Primary PCI IDE [Enabled] IDE Primary Master PIO [Auto] Item Help IDE Primary Slave PIO [Auto] IDE Primary Master UDMA [Auto] IDE Primary Slave UDMA [Auto] Menu Level >>...

  • Page 41: Onboard Device Function

    3-7-2 Onboard Device Phoenix – AwardBIOS CMOS Setup Utility OnChip IDE Device USB Controller [Enable] USB 2.0 Controller [Enable] Item Help USB Keyboard Support [Disabled] USB Mouse Support [Disabled] AC97 Audio [Auto] Menu Level >> Init Display First [Onboard/AGP] Onboard IEEE 1394 [Enabled] Onboard Lan Controller [Enabled]...

  • Page 42: Onboard Super Io Function

    This item allows you to enable/ disable the Onboard Lan Controller. Available options are Enabled and Disabled. 3-7-3 Super IO Device Phoenix – AwardBIOS CMOS Setup Utility Super IO Device Power ON Function [BUTTON ONLY] KB Power ON Password [Enter] Item Help x Hot Key Power ON [Ctrl-F1]...
  • Page 43 (3BC/IRQ7)/ Line Printer port 0 Parallel Port Mode This item allows you to select the parallel port mode to be used. Available select are SPP, EPP and ECP. : Standard Parallel Port : Enhanced Parallel Port : Extended Capability Port SPP/EPP/ECP/ECP+EPP To operate the onboard parallel port as Standard Parallel Port only, choose “SPP.”...

  • Page 44: Power Management Setup

    3-8 Power Management Setup The Power Management Setup allows you to configure your system to most effectively save energy saving while operating in a manner consistent with your own style of computer use. CMOS Setup Utility – Copyright(C) 1984-2002 Award Software Power Management Setup ACPI Function [Enable]...
  • Page 45 DPMS (default) Initial display power management signaling. Blank Screen This option only writes blanks to the video buffer. V/H SYNC+Blank This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the video buffer. Video Off In Suspend This determines the manner in which the monitor is blanked.
  • Page 46 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ [A-D] #...

  • Page 47: Pnp/Pci Configuration Setup

    3-9 PnP/PCI Configuration Setup Phoenix – AwardBIOS CMOS Setup Utility PnP/PCI Configurations PNP OS Installed [No] Reset Configuration Data [Disabled] Item Help Resources Controlled By [Auto(ESCD)] x IRQ Resources Press Enter Menu Level > x DMA Resources Press Enter PCI/VGA Palette Snoop [Disabled] ↑↓→←...

  • Page 48: Pc Health Status

    3-10 PC Health Status This section shows the Status of your CPU, Fan, Warning for overall system status. This is only available if there is a Hardware Monitor onboard. Phoenix – AwardBIOS CMOS Setup Utility PC Health Status CPU Warning Temperature [Disabled] 35 °...

  • Page 49: Frequency/Voltage Control

    3-11 Frequency/Voltage Control This section is for setting CPU Frequency/Voltage Control. Phoenix – AwardBIOS CMOS Setup Uitility Frequency/ Voltage Control Auto Detect PCI CLK [Enabled] Spread Spectrum [Disabled] Item Help Menu Level > ↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Optimized Defaults F7:Standard Defaults...

  • Page 50: Set Supervisor/User Password

    3-13 Set Supervisor/User Password You can set either supervisor or user password, or both of them. The differences are: Supervisor password: Can enter and have full privilege to change the options of the setup menus. User password: Can only enter but do not have the right to change the options of the setup menus.

  • Page 51: Mx852-C6 Mechanical Drawing

    MX852-C6 Motherboard I/O Mechanical Draw...
