PROGRAMMING THE MODULE

USING THE LED KEYPAD

A.
ACTION

Entering the Program Mode

1.
Go To Program Code
Factory Default is

Selecting the Module to Program:

2.

Factory Defaulting the Module

3.

Programming a Location:

4.
Once the number of the module to be programmed has been entered, the "Armed" LED will
illuminate while it is waiting for a programming location to be entered.
To Enter a Location:
[location]
8
RESULT
Enters the Program Mode.
Stay, Chime, Exit, Bypass & Cancel LEDS will
flash.
If the "Go To Program Code" is valid, the
"Service" LED will flash and the 5 function LEDs
will illuminate steady. You are now in the Program
Mode and ready to select the module to program.
The address of this cellemetry module is 76.
#
The Armed LED will illuminate while it is waiting
for a programming location to be entered.
The keypad will beep 3 times indicating that the
#
loading is in progress. Remember you will erase
any values you may have entered previously.
If an attempt is made to program an invalid entry for a particular
segment, the keypad sounder will emit a triple error beep (beep, beep,
beep), and remain in that segment awaiting a valid entry.
The Armed LED will flash. If the location is valid,
#
the "Armed" LED will extinguish, the "Ready" LED
will illuminate, and the zone LED's will show the
data for the first segment of this location.
