Quick Start Guide
This quick start guide describes how to install and use the
Hardened PoE Ethernet Switch.
for harsh environments.
Functional Description
• Meets NEMA TS1 & TS2 Environmental requirements:
temperature, shock, and vibration for traffic control
equipment.
• Meets EN61000-6-2 & EN61000-6-4 EMC Generic
Standard Immunity for industrial environment.
• Supports IEEE802.3at Power over Ethernet (PoE)
Power Sourcing Equipment (PSE).
• 1000Mbps-Full-duplex,
Auto-Negotiation, Auto-MDI/MDIX.
• Supports 4096 MAC addresses. Provides 2.25M bits
buffer memory.
• Alarms for power failure by relay output.
• Power Supplies: Redundant 47-57VDC Terminal Block
power inputs.
• Operating voltage and Max. current consumption: 9A @
55VDC. Power consumption: 495W Max.
• -40
to 75
℃
range. Tested for functional operation @ -40
(-40℉ to 185℉).
• Supports Rack Mounting installation.
Hardened PoE Ethernet Switch
℃ -40℉ to 167℉) operating temperature
(
This is the switch of choice
10/100Mbps-Full/Half-duplex,
1
to 85
℃
℃
Advertisement
Table of Contents
Related Manuals for EtherWAN EX49122A-05T
Summary of Contents for EtherWAN EX49122A-05T
-
Page 1: Quick Start Guide
Hardened PoE Ethernet Switch Quick Start Guide This quick start guide describes how to install and use the Hardened PoE Ethernet Switch. This is the switch of choice for harsh environments. Functional Description • Meets NEMA TS1 & TS2 Environmental requirements: temperature, shock, and vibration for traffic control equipment. -
Page 2: Physical Description
Hardened PoE Ethernet Switch Physical Description The Port Status LEDs and Power Inputs State Indication Steady Power on. Power1 Power2 Power off. Steady Power redundant system failure occurred. Fault Power redundant system failure is not occurred. 10/100Base-TX Steady A valid network connection established. Link/ACT Transmitting or receiving data. -
Page 3: The 10/100Base-Tx (Poe) And Gigabit Ethernet Connectors
Hardened PoE Ethernet Switch State Indication Gigabit Ethernet Steady A valid network connection established. Link/ACT Transmitting or receiving data. Flashing ACT stands for ACTIVITY. Steady A valid TX connection established. No valid TX connection established. Steady A valid SFP connection established. No valid SFP connection established. - Page 4 Hardened PoE Ethernet Switch Signal Name Signal Definition TD＋ Output Transmit Data ＋ TD－ Output Transmit Data － RD＋ Input Receive Data ＋ Positive (VCC+) Positive (VCC+) RD－ Input Receive Data － Negative (VCC-) Negative (VCC-) 2. The 1000Base-T Connections The following lists the pinouts of 1000Base-T ports.
- Page 5 Hardened PoE Ethernet Switch 4. The 1000Base-SX/LX Connections The fiber port pinouts: The Tx (transmit) port of device I is connected to the Rx (receive) port of device II, and the Rx (receive) port of device I to the Tx (transmit) port of device II. 5.
-
Page 6: Preface
Hardened PoE Ethernet Switch Preface A member of the growing family of rugged switches, this Hardened PoE Ethernet Switch provides an affordable solution rugged outdoor environment, transportation road-side cabinet, industrial floor shop, multitenant dwellings or Fiber To The Home (FTTH) applications. -
Page 7: Table Of Contents
Hardened PoE Ethernet Switch Table of Contents UICK TART UIDE UNCTIONAL ESCRIPTION HYSICAL ESCRIPTION The Port Status LEDs and Power Inputs The 10/100Base-TX (PoE) and Gigabit Ethernet Connectors REFACE ABLE OF ONTENTS RODUCT VERVIEW ARDENED THERNET WITCH ACKAGE ONTENTS RODUCT IGHLIGHTS Basic Features RONT... -
Page 8: Product Overview
Hardened PoE Ethernet Switch Product Overview Hardened PoE Ethernet Switch Package Contents When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. -
Page 9: Product Highlights
Hardened PoE Ethernet Switch Product Highlights Basic Features • Meets NEMA TS1 & TS2 Environmental requirements: temperature, shock, and vibration for traffic control equipment. • Meets EN61000-6-2 & EN61000-6-4 EMC Generic Standard Immunity for industrial environment. • Supports IEEE802.3at Power over Ethernet (PoE) Power Sourcing Equipment (PSE). -
Page 10: Front Panel Display
Hardened PoE Ethernet Switch Front Panel Display Status LEDs State Indication Steady Power on. Power1 Power2 Power off. Steady Power redundant system failure occurred. Fault Power redundant system failure is not occurred. 10/100Base-TX Steady A valid network connection established. Link/ACT Transmitting or receiving data. -
Page 11: Physical Ports
Hardened PoE Ethernet Switch State Indication Gigabit Ethernet Steady A valid network connection established. Link/ACT Transmitting or receiving data. Flashing ACT stands for ACTIVITY. Steady A valid TX connection established. No valid TX connection established. Steady A valid SFP connection established. No valid SFP connection established. -
Page 12: Installation
Hardened PoE Ethernet Switch Installation This chapter gives step-by-step instructions about how to install the switch: Selecting a Site for the Switch As with any electric device, you should place the switch where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. -
Page 13: Connecting To Power
Hardened PoE Ethernet Switch Connecting to Power Redundant DC Terminal Block Power Inputs: Redundant DC Terminal Block Power Inputs There are two pairs of power inputs can be used to power up this device. You only need to have one power input connected to run the switch. -
Page 14: Connecting To Your Network
Hardened PoE Ethernet Switch Connecting to Your Network Cable Type & Length It is necessary to follow the cable specifications below when connecting the switch to your network. Use appropriate cables that meet your speed and cabling requirements. Cable S ecifications Speed Connector Port Speed... -
Page 15: Cabling
Hardened PoE Ethernet Switch Cabling Step 1: First, ensure the power of the switch and end devices are turned off. Always ensure that the power is off before any installation. <Note> Step 2: Prepare cable with corresponding connectors for each type of port in use. -
Page 16: Specifications
Hardened PoE Ethernet Switch Specifications Hardened PoE 10/100Base-TX ports with RJ-45 connectors, Gigabit Ethernet ports Ethernet Switch Applicable IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX Standards IEEE 802.3ab 1000Base-T IEEE 802.3z 1000Base-SX/LX Store-and-Forward Switching Method Forwarding Rate 10Base-T: 10 / 20Mbps half / full-duplex 100Base-TX: 100 / 200Mbps half / full-duplex 1000Base-T/SX/LX:... - Page 17 Hardened PoE Ethernet Switch EN61000-6-4: EN55022 EN61000-6-2: EN61000-4-2 (ESD Standard) EN61000-4-3 (Radiated FRI Standards) EN61000-4-4 (Burst Standards) EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) Environmental Test Compliance IEC60068-2-6 Fc (Vibration Resistance) IEC60068-2-27 Ea (Shock) IEC60068-2-32 Ed (Free Fall) NEMA TS1/2 Environmental requirements for traffic control equipment...
