- Page 1 USB HD Audio/Video KVM Switch USER MANUAL CS692...
-
Page 2: Fcc Information
FCC Information Federal Communication Commission Interference Statement: This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Online Registration
CS692 User Manual Online Registration International http://eservice.aten.com Telephone Support International 886-2-8692-6959 China 86-10-5255-0110 Japan 81-3-5323-7178 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 United Kingdom 44-8448-158923 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com... -
Page 4: Package Contents
Copyright © 2010–2013 ATEN International Co., Ltd. Manual Date: 2013-12-02 - Manual Part No. PAPE-1349-AT3G ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 Another new feature of the CS692 is the implementation of a remote port selector. This means that you can now control port switching from the desktop while the switch itself can be placed in a convenient, out-of-the-way, location.
- Page 6 Power on detection – if one computer is powered off, the CS692 will automatically switch to the other computer Supports gaming and multimedia keyboards Supports multifunction and wireless keyboards and mice...
-
Page 7: System Requirements
An HD audio/video port USB Type A port Speaker and microphone ports (optional) Cables The CS692’s innovative design features built-in KVM and audio cables for extra convenience. No further cables are necessary. - 7 -... -
Page 8: Operating Systems
Operating Systems Supported operating systems are shown in the table, below: Version Windows 2000 / XP / 2003 / 2008 / Vista / 7 Linux RedHat 9.0, Fedora and higher SuSE 10 / 11.1 and higher Debian 3.1 / 4.0 Ubuntu 7.04 / 7.10 UNIX... -
Page 9: Components
Components CS692 Remote Port Selector - 9 -... - Page 10 KVM Cables The connectors at the end of these built-in KVM cables attach to the two HD audio/video computers/devices in your CS692 installation. See the diagram on page 12 for further details. Console Audio Ports Your console speakers* and microphone plug in here.
-
Page 11: Installation
1. Plug your keyboard and mouse into their USB ports, located on the front of the CS692. The ports are color coded and labeled with an appropriate icon. Note: The mouse connector is actually a USB 2.0 port, and can accept any USB compatible peripheral. -
Page 12: Installation Diagram
Installation Diagram - 12 -... -
Page 13: Operation
Operation The CS692 provides three convenient methods of selecting computers: Manual – click the pushbutton on the Remote Port Selector; Mouse – click the mouse’s scroll wheel; and Hotkey – enter combinations from the keyboard. Manual Port Selection Press the port selection pushbutton on the Remote Port Selector to toggle the KVM and Audio focus between the two computers. -
Page 14: Hotkey Port Selection
Hotkey Port Selection All hotkey operations begin by tapping the Scroll Lock key twice. See the Hotkey Summary Table for full details. Note: If using [Scroll Lock] conflicts with other programs, [Ctrl] can be used instead. Alternate Entering Hotkey Mode Press [Scroll Lock] [Scroll Lock] [x] [Enter]. -
Page 15: Hotkey Summary Table
Hotkey Summary Table Combination Function [Scroll [Enter] Toggles the KVM and Audio focus between the two Lock] ports. [Scroll Note: If the KVM and Audio focus are on different Lock] + ports, only the KVM focus switches. [k] [Enter] Toggles the KVM focus only. [s] [Enter] Toggles the Audio focus only. -
Page 16: Keyboard Emulation
Keyboard Emulation PC Keyboard Mac Keyboard [Shift] Shift [Ctrl] Ctrl [Ctrl] [1] [Ctrl] [2] [Ctrl] [3] [Ctrl] [4] [Alt] [Print Screen] [Scroll Lock] [Enter] Return [Backspace] Delete [Insert] Help [Ctrl] Note: When using key combinations, press and release the first key (Ctrl), then press and release the activation key. -
Page 17: The Firmware Upgrade Utility
Firmware Upgrade package for the CS692 from our Internet support site ( www.aten.com 2. Disconnect the CS692 from your KVM installation. Press and hold the Remote Port Selector’s pushbutton. While you are still holding the pushbutton, connect the KVM cable’s purple USB connector to a USB port on the computer you have downloaded the Firmware Upgrade package to. -
Page 18: Upgrade Failed
2. Press and hold the Remote Port Selector’s pushbutton. While you are still holding the pushbutton, reconnect the KVM cable’s USB connectors to the computer. 3. Power on the CS692. It will now work with the factory default firmware. Follow steps 3 to 9 on page 17 again. Troubleshooting... -
Page 19: Specifications
Specifications Function CS692 Computer Connections Console Connections Port Selection Remote Port Selector, Mouse, Hotkeys Connectors Console Keyboard 1 x USB Type A Female (Silver) Ports Video 1 x HD audio/video Type A Female (White) Mouse 1 x USB Type A Female (Silver) -
Page 20: Factory Default Hotkey Settings
Factory Default Hotkey Settings Setting Default Port Switching Hotkey [Scroll Lock] [Scroll Lock] Invoking HSM [Scroll Lock] [Scroll Lock] Auto Scan Interval 5 seconds Keyboard Operating Platform PC Compatible Mouse Emulation Enabled Keyboard Emulation Enabled Mouse Port-Switching Disabled Power on Detection Enabled Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE...
