BeefEater
Signature Plus
Signature S-3000E
Signature S-3000S
Balcony
Assembly, Installation and Operating Instructions
Certified ISO 9001 : 2000 by
9800958
IMPORTANT:
•
BeefEater Barbecues are approved for
must not be used in a building, garage or any other enclosed area.
•
BeefEater Barbecues must not be used in recreational vehicles or
boats.
•
Read instructions thoroughly before operating this Barbecue.
•
Save this manual for future reference.
•
Always use the Barbecue and Side Burner on a level surface.
•
Some foods produce flammable fats and juices. Regular cleaning is
essential.
•
Attend an operating barbecue at all times. Damage caused by fat &
grease fires is not covered by warranty
.
•
When not in use keep Barbecue and Side Burner dry and covered.
•
Vinyl covers are an optional accessory that will ensure years of
trouble free operation.
Australia's Leading Barbecue
BeefEater Gas Barbecues
OUTDOOR USE ONLY
FOR YOUR SAFETY
and
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odour continues, immediately call your gas
supplier or your fire department.
FOR YOUR SAFETY
1. Do not store or use gasoline or other flammable
vapours or liquids in the vicinity of this or any other
appliance.
2. An LPG cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
AUSTRALIA
NEW ZEALAND
UNITED STATES
CANADA
Advertisement
Table of Contents
Related Manuals for BeefEater Gas Barbecues
Summary of Contents for BeefEater Gas Barbecues
- Page 1 • BeefEater Barbecues are approved for must not be used in a building, garage or any other enclosed area. • BeefEater Barbecues must not be used in recreational vehicles or boats. • Read instructions thoroughly before operating this Barbecue. •...
- Page 2 Table of Contents Beefeater Barbecues Safety Warnings Assembly & Installation Instructions Help Guide Operation Instructions Cleaning and Maintenance Tech Support WARNING: We want you to enjoy your barbecuing experience - Failure to follow the instructions and observe the warnings provided in this operating manual could result in serious bodily injury or damage to property NOTE TO INSTALLER: This manual must remain with the owner for future reference.
- Page 3 A leak test must be carried out prior to using the appliance for the first time and whenever the gas cylinder is refilled or whenever the gas hose and regulator have been disconnected from the gas cylinder or appliance. Australia’s Leading Barbecue Precautions and Warnings BeefEater Barbecues • Spanner tighten all gas fittings as per instructions. •...
- Page 4 (See Gas Leak Testing Procedure) Hose and regulator replacement must be a genuine part specified for this appliance and is obtainable from your nearest BeefEater stockist. Gas Leak Test Procedure Use the following procedure to check for gas leaks.
- Page 5 Never fill the cylinder beyond 80% full. If these directions are not followed exactly, a fire causing death or serious injury may occur. Australia’s Leading Barbecue Gas Cylinder Information BeefEater Barbecues 19mm 19mm Spanner (wrench) for Gas Inlet Connection Phillips Head Screwdriver...
-
Page 6: Assembly Instructions
Assembly Procedure Heat Reflectors, Burners And Vaporizers The modular Vaporizer Grid system has been designed to maximise the performance of your BeefEater barbecue The reflectors fit between each burner. They reflect heat from the burners, upwards to the cooking surfaces. -
Page 7: Assembly Instructions 7
Fig 8 Fig 9 Australia’s Leading Barbecue Assembly Instructions BeefEater Barbecues Fitting The Vaporizers Remove the protective plastic film from each Vaporizer and then fit the Vaporizers to the barbecue. The tabbed ends of the Vaporizers face forward to the front of the barbecue frame. - Page 8 The grill or grills can be fitted to the right hand side of the barbecue frame. Grills must always be positioned over the Vaporizer grids. See Fig 13. BeefEater 2, 3 & 4 burner barbecues come standard with 1 /2 plate and grill and are approved for use with a maximum of 50% plate over the entire cooking area.
-
Page 9: Installation Instructions
Natural Gas (Natural Gas installation should be carried out by a qualified gas fitter). A. BeefEater Natural Gas barbecues are designed for low- pressure (4.0” WC, 1.00KPa) to be used as freestanding units, trolley mounted, or built into brickwork. B. Fit the natural gas regulator supplied directly to the gas inlet via hard plumbing and install a shutoff valve within easy reach in the gas line. -
Page 10: Operating Instructions
Operating Instructions Beefeater Barbecues Before Lighting 1. Check that all gas hose fittings and connections are spanner tight. Gas regulators that are fitted with a hand tightening wheel should be checked to ensure that the connection is secure. 2. Check that control knobs are in the Off position. Note... - Page 11 2, 3, 4 and 5 burner barbecue Turn on desired number of burners to the High position for approximately ten minutes or until the cooking surfaces are heated. Cooking With Optional The BeefEater Roasting Hood Indirect Cooking Method Indirect cooking is where the heat circulates around the food, cooking by convection.
- Page 12 Operating Instructions Beefeater Barbecues Cooking With The BeefEater Roasting Hood cont. If you are cooking a roast, it is always a good idea to use a roast holder and baking dish. This will keep the meat away from the direct heat source but allow the meat to cook by convection.
-
Page 13: After Use
Do not close lid while burner is alight. Australia’s Leading Barbecue Operating Instructions BeefEater Barbecues Warning When using the side burner ensure that any handle fitted to a wok, pot or pan is positioned so that it is out of reach of children. - Page 14 Beefeater Barbecues Your BeefEater barbecue has undergone a series of quality checking points prior to leaving the factory. Should you have a problem with your appliance please refer to the help guide below before calling your dealer or service person.
-
Page 15: Care And Maintenance
Care And Maintenance Instructions Cooking Surface Preparation Before Using Your BeefEater Barbecue Your BeefEater barbecue will feature either of the following cooking surfaces. 1. Standard Cast Iron Grills 2. ‘RF Technology’ - Porcelain Coated Grills or 3. Stainless Steel Grills... - Page 16 • Before each subsequent use, preheat your BeefEater for 10 minutes before cooking. Allow the unit to cool off and then remove any remains from previous cooking. Wipe off with a paper towel and then lightly coat with a layer of cooking oil.
- Page 17 Inspect gas control valves Australia’s Leading Barbecue Care and Maintenance BeefEater Barbecues occur on any exposed metal surface if it is not protected from the elements. Even stainless steel can be affected by long term exposure to the elements. To prevent exposure to the elements, store your barbecue, hood and trolley under the protection of a purpose made cover.
- Page 18 Outdoor Installation Instructions Beefeater Barbecues WARNING: Contact your local municipality for any building codes regulating the installation of outdoor barbecue appliances. Outdoor installations must conform to local codes or, in the absence of local codes, with the following. USA: National Fuel Gas Code, ANSI Z223.1/NFPA 54 CAN: B149.1 Natural Gas &...
- Page 19 Specifications BeefEater Barbecues Australia’s Leading Barbecue...
- Page 20 Signature Series Spare Parts Beefeater Barbecues 2 Burner Balcony 4 Burner Signature S3000 S/E Australia’s Leading Barbecue 3 Burner Signature S3000 S/E 5 Burner Signature S3000 S/E * Precise cooking surface arrangements will vary from region to region...
- Page 21 Gas control valve C/W Ignition Fascia Fascia Screw Bezel - (Knob surround) Bezel screw Knob BeefEater badge and circlips Gas Injector - LP (1.27mm) Gas Injector - NG (2.10mm) Hose and prefitted regulator Plate and Grate Lifter Signature S3000S Series (Stainless Steel)
- Page 22 Warranty Terms and Conditions Beefeater Barbecues BeefEater Barbecues Warranty Terms Signature S3000E & S3000S Series Warranty Terms Barbecue Barbecue Frame Cast Iron Burners Valves ‘Quartz Start’ Ignition System Vaporizer Grids and Reflectors All Other Parts Cooktops / Cooking Surfaces Cast Iron Grills...
- Page 23 Should any part fail due to defective workmanship or faulty materials within the specified period from the date of purchase, BeefEater or its distributor will repair or, (at distributors option), replace the defective part free of charge. • RF Technology – Porcelain enamel...
- Page 24 Accessories Beefeater Barbecues See your retailer for the full range of BeefEater barbecue accessories 3 in 1 Scrub Brush Meat Thermometer Baking Dish Roast Rack Barbecue Cover Roasting Hood Apron & Mitt Set Tool Set Kebab Set Tech Support BeefEater Sales International 3-5 Birmingham Avenue P.O.
