Gas Griddle, Spark Ignition, "SELECTRONIC"
Star Manufacturing International
Part Number: 2M-W360
Rev. D
Installation,
Operation, and
Maintenance Instructions
Models:
236SCHG "CHROME"
Ph: 314-781-2777 Fax: 314-781-2714
WWW.STAR-MFG.COM
224S
236S
248S
260S
272S
10 Sunnen Drive
1
St. Louis, MO.63143-3800
October 29, 2007
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lang SELECTRONIC
Summary of Contents for Lang SELECTRONIC
- Page 1 Installation, Operation, and Maintenance Instructions Gas Griddle, Spark Ignition, “SELECTRONIC” Models: 224S 236S 236SCHG "CHROME" 248S 260S 272S Star Manufacturing International 10 Sunnen Drive St. Louis, MO.63143-3800 Part Number: 2M-W360 Ph: 314-781-2777 Fax: 314-781-2714 WWW.STAR-MFG.COM Rev. D October 29, 2007...
- Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. IMPORTANT The installation of the Appliance should conform to the NATIONAL FUEL GAS CODE "ANSI Z223.1/NFPA 54 - LATEST EDITION" AND ALL LOCAL GAS COMPANY RULES AND REGULATIONS.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE 1. TABLE OF CONTENTS ................3 2. READ FIRST ....................4 3. EQUIPMENT DESCRIPTION ..............6 4. UNPACKING....................8 5. INSTALLATION ................... 9 6. INITIAL START-UP..................11 7. OPERATION....................12 8. SEQUENCE OF OPERATION..............15 9. - Page 4 IMPORTANT READ FIRST IMPORTANT CAUTION: THE GRIDDLE EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION.
- Page 5 10 minutes. Longer contact can cause corrosion. NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your LANG authorized service agent directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM For the service agent nearest you.
-
Page 6: Equipment Description
The griddle weighs 260, 390, 520, 650, 780 lbs. depending on actual model number. 3.5 Griddle Gas and Voltage Specifications The Lang Model can be connected to any 120 Volt source. The gas and electrical specifications are listed in the table below... - Page 7 EQUIPMENT DESCRIPTION CONT’D GAS AND ELECTRICAL INPUT REQUIREMENTS TOTAL BTU INPUT ELECTRICAL CONNECTION CORD/PLUG & MODEL DESCRIPTION GAS CONNECTION PRESSURE NUMBER NATURAL PROPANE REGULATOR VOLTAGE AMPS 5” WC 10” WC 224S 24 INCHES 54,000 54,000 ONE 3/4” NPT 115 VOLT SUPPLIED 236S 36 INCHES...
-
Page 8: Unpacking
UNPACKING 4.1 Receiving the Griddle Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted on the freight bill at the time of delivery and signed by the carrier's agent. Concealed loss or damage means loss or damage which does not become apparent until the merchandise has been unpacked. -
Page 9: Installation
INSTALLATION DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. - Page 10 INSTALLATION CONT’D Correct manifold pressures are: 5 inches water column for natural gas 10 inches water column for propane When replacing the plug in the manifold, a pipe joint compound or sealant should be used that is resistant to the action of liquid petroleum gas. Initial adjustments are the responsibility of the installer and are not chargeable to Star Manufacturing International.
-
Page 11: Initial Start-Up
INITIAL START UP 6.1 Initial Lighting Procedure Clean the preservative coating from the griddle plate and splash guard. Add a mild detergent to hot water and wash the griddle plate and splash guard. Rinse with a damp sponge and dry with a clean rag. WARNING: BEFORE LIGHTING, USE A SOAP AND WATER SOLUTION TO TEST ALL JOINTS FOR GAS LEAKS. -
Page 12: Operation
OPERATION 7.1 Setting the Griddle Temperature The suggested time and temperature chart (below) is provided as a guide for the products listed only. CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. - Page 13 OPERATION CONT’D 7.2 Loading the Griddle An understanding of how the griddle sections are controlled will be a valuable aid in loading your griddle. Each 12 inch section of your griddle is independently controlled. The temperature control sensor is mounted under the griddle plate in the center of each cooking section.
-
Page 14: Sequence Of Operation
SEQUENCE OF OPERATION 8.1 Power On When the griddle is connected to 115 Volt power, the spark module for each section starts sparking. While they are sparking the solenoid valve for the pilot burners are energized. When the individual pilot burners ignite, and the pilot flame is verified, the spark module will stop sparking. -
Page 15: Maintenance & Cleaning Procedures
MAINTENANCE & CLEANING WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING. -
Page 16: Troubleshooting
TROUBLESHOOTING 10.1 Symptoms The chart below is to assist in the troubleshooting of the griddle. Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items to be checked. To test for a possible cause, refer to the TEST section (on the following page) and locate the Possible Cause then refer to test to identify test procedures. - Page 17 TROUBLESHOOTING CONT’D 10.2 TESTS NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your LANG authorized service agent directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM For the service agent nearest you.
-
Page 18: Parts Lists
PARTS LIST October 29, 2007, Rev D 224S-NAT Gas Griddle Selectronic PART # DESCRIPTION Application 2A-72500-02 Legs 224S-NAT 2A-80401-01 Orifice, Pilot Burner NG .018 224S-NAT 2E-30303-06 Switch, Toggle On-ON DPDT Black Metal 224S-NAT 2E-30303-18 SWITCH, TOGGLE ON/OFF 224S-NAT 2E-30304-22 Temperature Selector Switch 175°-450°F... - Page 19 PARTS LIST October 29, 2007, Rev D 236S-NAT/LP Gas Griddle Selectronic PART # DESCRIPTION Application 2A-72500-02 Legs 236S-LP, NAT, CHG-NAT, HG236SC1LNAT 2A-80401-02 Orifice, Pilot Burner LP .010 236S-LP 2A-80401-03 ORFICE, PILOT LP 236S-LP 2A-80401-05 PILOT BURNER ORFICE HG236SC1LNAT 2E-30303-06 Switch, Toggle On-ON DPDT Black Metal...
- Page 20 PARTS LIST October 29, 2007, Rev D 236THG-LP Gas Griddle for Clamshell PART # DESCRIPTION Application 2A-72500-02 Legs 236THG-LP 2A-80401-02 Orifice, Pilot Burner LP .010 236THG-LP 2A-80401-03 ORFICE, PILOT LP 236THG-LP 2E-30303-06 Switch, Toggle On-ON DPDT Black Metal 236THG-LP 2E-30303-18 SWITCH, TOGGLE ON/OFF, 12"...
- Page 21 PARTS LIST October 29, 2007, Rev D 248S-NAT/LP/SC Gas Griddle Selectronic PART # DESCRIPTION Application 2A-72500-02 Legs 248S-LP, NAT 2A-72500-09 LEGS 248S-NATSC 2A-80401-01 Orifice, Pilot Burner NG .018 248S-NAT, SC 2A-80401-03 ORFICE, PILOT LP 248S-LP 2E-30303-06 Switch, Toggle On-ON DPDT Black Metal...
- Page 22 PARTS LIST October 29, 2007, Rev D 260S-NAT/LP/SC Gas Griddle Selectronic PART # DESCRIPTION Application 2A-72500-02 Legs 260S-LP, NAT 2A-72500-09 LEGS 260S-NATSC 2A-80401-01 Orifice, Pilot Burner NG .018 260S-NAT, SC 2A-80401-03 ORFICE, PILOT LP 260S-LP 2E-30303-06 Switch, Toggle On-ON DPDT Black Metal...
- Page 23 PARTS LIST October 29, 2007, Rev D 272S-NAT/LP Gas Griddle Selectronic PART # DESCRIPTION Application 2A-72500-02 Legs 2A-80401-01 Orifice, Pilot Burner NG .018 272S-NAT & NATSC 2A-80401-02 Orifice, Pilot Burner LP .010 272S-LP 2E-30303-06 Switch, Toggle On-ON DPDT Black Metal...
- Page 24 6 FT 5 FT 4 FT 3 FT 2 FT SINGLE TRANSFORMER PILOT PILOT PILOT PILOT PILOT PILOT PILOT 2, 3, & 4FT BURNER BURNER BURNER BURNER BURNER BURNER VALVE SPARK SPARK SPARK SPARK SPARK L G N SPARK MODULE MODULE MODULE MODULE...
