Page 1: Maintenance Instructions
Installation, Operation, and Maintenance Instructions Electric Griddle w/ Dual Gutters Model: 136SB-WB 148SB-WB 160SB-WB 172SB-WB Star Manufacturing International 10 Sunnen Drive St. Louis, MO 63143 Part Number: 2M-W350 Phone: 314-781-2777 Fax: 314-781-2714 Rev. B WWW.STAR-MFG.COM May 31, 2007... - Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE TABLE OF CONTENTS..................3 READ FIRST......................4 EQUIPMENT DESCRIPTION ................6 UNPACKING......................7 INSTALLATION ....................8 INITIAL START-UP..................... 11 OPERATION......................12 MAINTENANCE & CLEANING PROCEDURES ..........14 TROUBLE SHOOTING..................15 PARTS LIST ......................17 WIRING DIAGRAM .................... 18... -
Page 4: Read First
IMPORTANT READ FIRST IMPORTANT CAUTION: EACH UNIT IS EXTREMLY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION. - Page 5 10 minutes. Longer contact can cause corrosion. NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM...
-
Page 6: Equipment Description
EQUIPMENT DESCRIPTION Lang Model: 100 SERIES SB-WB Exterior Construction The griddle dimensions are 17” (43.18cm) High, 30” (76.20cm) Deep, and width is dependent on the actual model number. The Sides, Bottom, and Rear wall are constructed of double wall stainless steel, which allows closer installation to combustible surfaces. -
Page 7: Unpacking
UNPACKING Receiving the Griddle Upon receipt, check for freight damage, both visible and concealed. Visible damage should be noted on the freight bill at the time of delivery and signed by the carrier's agent. Concealed loss or damage means loss or damage, which does not become apparent until the merchandise has been unpacked. -
Page 8: Installation
INSTALLATION DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. -
Page 9: Electrical Connection
INSTALLATION CONT’D Ventilation and Clearances Standard minimum clearance from combustible construction is as follows. 2” from side 2” from back These griddles may be set directly, without legs, on a curbed base or non-combustible surface. If the griddle is set without legs on a non-combustible floor or a curbed base, maintain a 4-inch back clearance. - Page 10 INSTALLATION CONT’D Converting Double Connection to Single Connection Remove the two rear access panels from the griddle Remove the wires from the envelope labeled “Single connection jumpers” Determine which end of the griddle the main power supply connection will enter. Call this end terminal block 1 Insert the main power supply wires into the open side of this terminal block.
-
Page 11: Initial Start-Up
INITIAL START UP Pre-Power On Before starting the griddle for the first time, clean the griddle body and cooking surface. Use a mild soap and water solution, then rinse with clear water and dry. Power On Set the main power switch, located at the far left of the control panel, to the "ON" (up) position (there are two "ON"... -
Page 12: Operation
OPERATION General The suggested time and temperature chart (below) is provided as a guide for the products listed only. CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. - Page 13 OPERATION CONT’D Operations An understanding of how the griddle sections are controlled will be a valuable aid in loading your griddle. Each 12-inch section of your griddle is independently controlled by a temperature controller. The temperature control sensor is mounted in the center of each cooking section under the griddle plate.
-
Page 14: Maintenance & Cleaning Procedures
MAINTENANCE & CLEANING WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR HOSE CONTROL CONSOLE. CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING. -
Page 15: Troubleshooting
TROUBLESHOOTING Symptoms What follows is a chart of Symptoms and Possible Causes to aid in diagnosing faults with the griddle. Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items to be checked. To test for a possible causes refer to the TEST section and locate the Possible Cause then refer to test to identify test procedures. - Page 16 TROUBLESHOOTING CONT’D TESTS NOTICE: Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM For the service agent nearest you. WARNING:...
- Page 17 For individual parts SEE DETAIL SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential to Star Manufacturing International, Inc. No reproduction or disclosure of it's contents is permitted. Model: 124S - 172S Selectronic Control Electric Griddle LG Electric Griddle Accu-Temp Control SK2263...
-
Page 18: Parts List
PARTS LIST November 0, 009 Model No: 136SB-WB & 148SB-WB Selectronic Electric Griddle FIG NO PART NO. DESCRIPTION APPLICATION K9-XL-722-28 PLATE ASY 3’ LGR .5RTD 136SB-WB 2E-41100-17 TEMP PROBE SEL LG GRIDDLE 136SB-WB K9-XL-228-1 BUCKET SLIDE ASSY LGR 136SB-WB K9-XL-220-3 BODY ASSEMBLY 3’ LGR 136SB-WB LEGS &... - Page 19 PARTS LIST November 0, 009 Model No: 160SB-WB & 172SB-WB Selectronic Electric Griddle FIG NO PART NO. DESCRIPTION APPLICATION K9-XL-722-251 PLATE ASY 5’ LGR .5RTD 160SB-WB 2E-41100-17 TEMP PROBE SEL LG GRIDDLE 160SB-WB K9-XL-228-1 BUCKET SLIDE ASSY LGR 160SB-WB K9-XL-220-3 BODY ASSEMBLY 3’ LGR 160SB-WB K9-XL-220-2 BODY ASSEMBLY 2’...
- Page 20 DETAIL Control Panel Assembly (LPGS4-C shown) SK2307 Rev. B 7/7/08...
-
Page 21: Control Panel Assembly
PARTS LIST November , 009 Model No: 136SB-WB, 148SB-WB, 160SB-WB & 172SB-WB Control Panel Assembly Model Panel Description Panel Part Number 124S PNEL XL-LG SEL 2’ 208/240V K9-LGPS2-C 124S-480V PNEL XL-LG SEL 2’ 480V K9-LGPS2-U 124SHE PNEL SEL 2’ 208/240V W/CSE... - Page 22 PARTS LIST November 0, 009 Model No: 136SB-WB, 148SB-WB, 160SB-WB & 172SB-WB Control Panel Assembly Fig No Part Number Description Application LGPS2-C, LGPS2-U 2C-20103-02 SCRW SM PLT 10 X .5 PHLSL LGPS3-C, LGPS3-U, LGPS3-C-W1, LGPS3-K LGPS4-C, LGPS4-U, LGPS4-U-W1 2K-70801-02 SNAP BUSH 1 3/8 SB1375-16...
- Page 23 PARTS LIST November 0, 009 Model No: 136SB-WB, 148SB-WB, 160SB-WB & 172SB-WB Control Panel Assembly Fig No Part Number Description Application LGPS2-C, LGPS2-U, LGPS3-C, LGPS3-C-W1, LGPS3-U 2C-20102-04 SCRW PHD ST 8-32X.5 PLTD LGPS4-C, LGPS4-U, LGPS4-U-W1 K9-XL-502-31 ELECT BOX CVER 4’ SEL...
