Rize Contemporary III Owner's Manual page 9

Installation Guide
Assembling the headboard bracket (optional)
IMPORTANT!
• Failure to follow the installation steps as they appear in this guide could result in damage to your
adjustable bed frame.
• For safety reasons, lifting of the adjustable bed frame must always be performed by two (2) people;
and the unit should always be on a flat surface.
• Make sure to position the bottom of the headboard cross member no more than
3 inches (76.2 mm) between the headboard and the top of the mattress.
1
Turn the bed frame unit over with the top side facing downward.
2
Unthread the leg at the head of the bed frame by turning the leg
counter-clockwise.
3
Slide the inner headboard bracket over the hole for the leg
attachment. (The bracket opening should face away from the
bed frame).
4
Screw the leg back in, turning clockwise. This will secure the
inner headboard bracket between the bed frame and the leg.
5
Place the open side of the outer headboard bracket onto the
exposed square tube of the inner headboard bracket to create
a tight fit.
6
Insert a retainer bolt fitted with a 5/16 inch washer into the
outer headboard bracket and through the inner headboard
bracket. Tighten the 5/16 inch washer and 5/16 inch nut with
an Allen key wrench. Leave loose enough for adjusting.
7
Repeat steps 2 to 5 on the other side.
8
Securely fasten the headboard bolts (not included with your
adjustable bed frame) to the end of the headboard bracket
assembly.
9
Measure the distance from the center of one mounting hole in
the headboard assembly to the center of the other.
10
If you need to adjust the headboard brackets, unscrew the
bolts holding the outer headboard bracket and move them the
necessary distance. Reinstall the bolts and tighten securely.
Place your mattress on the adjustable bed frame surface.
Your adjustable bed and headboard installation is now complete.
