National Alloy Assembly Instruction Manual

Lay out pieces on the ground and locate mounting hardware supplied.
1
(Figure A)
Figure A:
Install main mounting bracket to the pole casing with four (4)
2
#10-32 x 3/16" capscrews. (Figure B)
Figure B:
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call National Customer Service
Assembly Instruction
Alloy
Ceiling Power/Data Pole

Package Contents

Item
#10-32 X 3/16
Socket Head Capscrew
#8 X 1/4" Screw
Phillips
#10 X 1/2" Hex Head
Self Tapping Screw
Component
Power Pole

Tools Required

Screw Driver #2 Phillips
1/4" Socket
Telephone 800.482.1717
Fax 812.482.8800
www.NationalOfficeFurniture.com
Part # 3112080
Rev, A
Printed in U.S.A
© 2018 Kimball International, Inc.
.
800.482.1717
Qty
4
4
2
