Metal, Glass, and Wood Finish TV Stand Meuble pour téléviseur en métal et en verre à finition bois NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C ENGLISH ...............3 FRANÇAIS............13 Before using your new product, please read these instructions to prevent any damage.
CONTENTS / TABLE DES MATIÈRES ENGLISH ..................3 SAFETY INFORMATION AND SPECIFICATIONS..........3 PACKAGE CONTENTS: PARTS................4 PACKAGE CONTENTS: HARDWARE..............5 ASSEMBLY INSTRUCTIONS................. 6 CARE AND MAINTENANCE................11 ONE-YEAR LIMITED WARRANTY ..............12 FRANÇAIS...................13 INFORMATIONS SUR LA SÉCURITÉ ET SPÉCIFICATIONS......13 CONTENU DE L’EMBALLAGE : ÉLÉMENTS............14 CONTENU DE L’EMBALLAGE : FIXATIONS ...........15 INSTRUCTIONS DE MONTAGE.................16 MAINTENANCE ET ENTRETIEN................21...
(137.2 x 60.9 x 45.7 cm) Keep these items away from young children! Overall weight: 123.5 Lbs. (56.02 kg) Model #: NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C 18 inch (45.7 cm) 54 inch (137.2 cm)
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C PACKAGE CONTENTS: PARTS Make sure that you have all the parts necessary to assemble your new TV stand. While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other.
Metal, Glass, and Wood Finish TV Stand PACKAGE CONTENTS: HARDWARE Note: The table below shows the required hardware. You may receive extra hardware. Make sure that you have all the hardware necessary to assemble your new TV stand. Label Hardware Qty.
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C ASSEMBLY INSTRUCTIONS Step 1: Preparing the TV stand body Caution: Assemble your stand on a carpeted floor or on the empty box to avoid scratching your stand. 1 Place the TV Stand Body (M1) upright on the floor.
Page 7
Metal, Glass, and Wood Finish TV Stand Step 2 Securing the hinged sides and the left side panel 1 Secure the lower hinged braces in the straight position with two of the 10 mm body screws (M6). 2 Align the 7 mm screws (M5) on the lower edge of the left side (M2) with the holes in the cross braces on the stand body (M1) (as shown in the detail below), then attach the left side.
Page 8
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C Step 3 Installing the glass shelves • Make sure the TV stand doors are open. • Carefully slide the three interior glass shelves (M3) into the stand body (M1) from the right side until they touch the left side.
Page 9
Metal, Glass, and Wood Finish TV Stand Step 4 Installing the right side and door handles 1 Align the 7 mm screws (M5) on the lower edge of the right side (M2) with the holes in the cross braces on the stand body (M1), then attach the right side.
Page 10
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C Step 5 Installing the top 1 With the help of another person, lift the glass top (M4) into position on the top of the TV stand body. 2 Insert the 10 mm body screws (M6) through the top brackets and into the threaded silver inserts that are pre-installed on the glass top (M4) until the top is secure.
Metal, Glass, and Wood Finish TV Stand CARE AND MAINTENANCE Wood/Laminate • Use your favorite type of furniture polish. • Do not spray polish directly onto the stand. Spray onto a soft cloth then wipe the stand. • Always test any polish in a discrete location first, such as the back of the stand, to make sure that there is no adverse reaction.
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND Insignia and are not returned to you. If service of Products or NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY parts are required after the Warranty Period expires, you must AFTER THE WARRANTY PERIOD.
Ranger ces (137,2 x 60,9 x 45,7 cm) pièces hors de la portée des jeunes enfants! Poids hors-tout : 123,5 lb (56,02 kg) N° de modèle : NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C 18 po (45,7 cm)
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C CONTENU DE L’EMBALLAGE : ÉLÉMENTS Vérifier d’avoir toutes les pièces nécessaires pour assembler ce meuble pour téléviseur neuf. Bien que toutes les pièces ne soient pas étiquetées, certaines ont une étiquette ou une lettre écrite à l'encre sur la bordure pour permettre de distinguer les pièces les unes des autres.
Meuble pour téléviseur en métal et en verre à finition bois CONTENU DE L’EMBALLAGE : FIXATIONS Remarque : Le tableau ci-après indique les fixations requises. Il se peut que des fixations supplémentaires soient incluses dans la livraison. Vérifier que les fixations nécessaires à l’assemblage de ce meuble pour téléviseur neuf sont fournies. Étique Fixations Qté...
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C INSTRUCTIONS DE MONTAGE Étape 1 : Montage de l'armature du meuble pour téléviseur Attention : Assembler le meuble sur une moquette ou sur la boîte d’emballage vide pour éviter de le rayer. 1 Placer l'armature du meuble pour téléviseur (M1) en position verticale sur le sol.
Page 17
Meuble pour téléviseur en métal et en verre à finition bois Étape 2 Fixation des côtés à charnières et du panneau latéral gauche 1 Fixer les entretoises à charnière inférieures en position droite à l'aide de deux des vis moletées de 10 mm (M6). 2 Aligner les vis de 7 mm (M5) sur le bord inférieur du côté...
Page 18
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C Étape 3 : Installation des étagères en verre • S'assurer que les portes du meuble pour téléviseur sont ouvertes. • Insérer délicatement les trois étagères en verre (M3) dans l'armature du meuble (M1) à partir du côté droit jusqu'à...
Page 19
Meuble pour téléviseur en métal et en verre à finition bois Étape 4 Installation du côté droit et des deux poignées de porte 1 Aligner les vis de 7 mm (M5) du bord inférieur du côté droit (M2) sur les orifices dans les entretoises de cloison de l’armature du meuble (M1), puis fixer le côté...
Page 20
NS-HWMG1754G / NS-HWMG1754M / NS-HWMG1754M-C Étape 5 Installation de la partie supérieure 1 Avec l'aide d'une tierce personne, relever le dessus en verre (M4) dans sa position sur le dessus de l'armature du meuble pour téléviseur. 2 Insérer les vis moletées de 10 mm (M6) dans les supports supérieurs et dans les douilles filetées en argent qui ont été...
Meuble pour téléviseur en métal et en verre à finition bois MAINTENANCE ET ENTRETIEN Bois et laminé • Utiliser le type préféré de cire pour les meubles. • Ne pas vaporiser de cire directement sur le meuble. Vaporiser la cire sur un chiffon doux, puis passer le chiffon sur le meuble.
Insignia ou le personnel du magasin, inférieure à un dixième (1/10) de celle de l’écran, ou un Insignia (à sa seule discrétion) : (1) réparera le Produit en utilisant maximum de cinq (5) pixels défectueux sur toute la surface des pièces détachées neuves ou remises à...
