- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® LED Hardscape Lights ® AHS-67XX Series Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE LED Hardscape Lights ® AHS-67XX Series Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Product Dimensions 4.2” .75” 7.2” .75” 13” .75” 19” .75” Install Luminaire in Brick or Masonry Wall Install Mounting Plate Determine the desired location for Brick or each luminaire before construction of Masonry Wall the wall is started. Insert the stainless steel mounting Mounting Plate plate (sold separately), in between the layers of hardscape material.
- Page 4 INSTALLATION & MAINTENANCE GUIDE LED Hardscape Lights ® AHS-67XX Series Install Luminaire Route the luminaire wire through the wall to the main low voltage Mounting Plate supply cable using standard masonry procedures. A “V” shaped notch can be cut into the Glare Guard hardscape material to aide in wire management.
- Page 5 Install Luminaire in Railing, Deck Over-hang or Stair Determine Luminaire Location Railing, Deck Mark over-hang or Stair Railing, Deck over-hang or Stair Wireway Hole Mark Luminaire Luminaire Wireway Self-tapping Self-tapping Hole Screw Screw Install from Bottom Install from Side Determine the desired location for the luminaire. Place the luminaire to the mounting surface and mark two points on the mounting surface where the holes are on the ends of the luminaire.
- Page 6 INSTALLATION & MAINTENANCE GUIDE LED Hardscape Lights ® AHS-67XX Series Install Luminaire Railing, Deck Mark over-hang or Stair Railing, Deck over-hang or Stair Wireway Hole Glare Guard Wall Anchor Mark Wireway Self-tapping Luminaire Glare Guard Luminaire Hole Screw Rubber Washer Self-tapping Screw Install from Bottom...
- Page 7 Adjust LED Direction Set Screw Allen Wrench Set Screw Using an Allen wrench, loosen the set screws on the ends of the LED, then rotate the LED to the desired direction. Always tighten the set screws after adjustments. w w w. a m p l i g h t i n g . c o m –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2018, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-AHS-67XX-ver5.pdf...
