Table 7: Engineer Mode Menu Item Descriptions
Item Mnemonic Description
E1 db Dead band offset
Unoccupied (ESI) Cooling
E2 ESIC
Set Point
Unoccupied (ESI) Heating
E3 ESIH
Set Point
Integral Time and Output
E4 I-t
Cycle Time
E5 AO1L Not used
E6 AO1H Not used
Analog Output 2 Low Adjustment
E7 AO2L
(for FAN control)
Analog Output 2 High Adjustment
E8 AO2H
(for FAN control)
Low Limit for Temperature
E9 SP-L
Set Point
High Limit for Temperature
E10 SP-H
Set Point
E11 OFSt Current Temperature Offset
E12 Pb Proportional Band or Stage Width
Bit Definition —
Bit 0: Mode Button
1: Down Buttons
2: Up Button
3: Fan Button
4: Power Button
5: Set Button
6: ESI Contact Detection
7: Reserved
*Bit Value
0: Unlock/enable
1: Lock/disable
Examples:
E13 LOC
0 – Unlock/enable all
1 – Lock MODE Button
2 – Lock Down Button
...
8 – Lock Fan Button
...
15 – Lock MODE & Down & Up &
Fan SPEED Buttons
16 – LockPower Button
...
64 – Disable ESI contact
detection
...
...
255 – Lock/disable all
E14 ESI ESI Contact Definition
Present Temperature is Getting
E15 rS from Built-In Temperature Sensor,
or Remote Temperature Sensor
Display Present Value of
E16 -SP- Temperature or Set Point for
Normal Displaying
Lowest Fan Speed in Continuous
E17 FAnL
Fan Mode
E18 Fan2 Medium Fan Speed
Minimum delay time between
E19 dLAy
cooling and heating
E20 dirC Cooling Valve N.C./N.O. Setting
IM 1272 • OPTILINE VERTICAL FAN COILS
°C Type
Default Range Default
2.0 0~10.0
28.0 25.0~35.0
15.0 10.0~22.0
90 10~500
0 0~125
-25 -150~0
10.0 0~50.0
35.0 0~50.0
0.0 -10.0~10.0
2.0 0~10.0
0 0–255
0 0~1
0 0~1
0 0–1
25 0~100
60 20~100
0 0~5
1 0~1
26
°F Type
Range
7.0 0~18.0
82.0 77.0~95.0
59.0 50.0~72.0
90 10-500
0 0~125
-25 -150~0
50.0 32.0~122.0
95.0 32.0~122.0
0.0 -18.0~18.0
3.6 0~18.0
0 0–255
0: N.O.
0 0~1
1: N.C.
0: built-in
0 0~1
1: remote
0: display PV
0 0–1
1: display SP
25 0~100
60 20~100
0 0~5
0: N.O.
1 0~1
1: N.C.
www.DaikinApplied.com
Addendum
Step
0.5 (°C/°F)
1.0(°C/°F)
1.0(°C/°F)
10 (Sec.)
1(~0.044V)
1(~0.044V)
1.0 (°C/°F)
1.0 (°C/°F)
0.1(°C/°F)
0.1 (°C/°F)
1
1(%)
1(%)
1 (minute)
