Daikin DAX Commercial Manual

■ Standard Features
• Uplflow or horizontal (left side) installation positions in
7½ and 10-ton cooling only or heat pump applications
• Circuited for use with one (1) 7½-ton or one
(1) 10-ton cooling-only or heat pump system.
Also circuited for use with two (2) 4-ton or
two (2) 5-ton cooling-only units
• TXV Control; Units have two (2) thermal
expansion valves
• DAX units feature two 5-speed direct-drive motors
• Copper tube/aluminum fin coils
• AHRI Certified; ETL Listed
SS-DAX
DAX Commercial
■ Cabinet Features
• Heavy-gauge, reinforced, galvanized-steel cabinet
• Fully insulated with fiberglass blanket
• Horizontal and vertical condensate pans
• Built-in filter rack (2" filter included)
• Entry on top of panel for both low and high voltage
• Removable access panels make
servicing of unit faster and easier
* Complete warranty details available from your local dealer or at www.daikincomfort.com.
www.daikinac.com
ELECTRIC AIR HANDLERS
FOR 7½ & 10-TON SPLIT SYSTEMS
■
Contents
Nomenclature ...............................2
Product Specifications ..................3
Airflow Data ..................................4
Temperature Rise .........................6
Electrical Heater Kits .....................7
Dimensions ....................................8
Wiring Diagrams ...........................9
Accessories .................................11
