Installation Guide | DeviceNet Card

3 Configuration

3.1 Preparations

The DeviceNet Card is a Group 2 slave device using a predefined master/slave connection set. I/O data is produced and consumed
using polled I/O messaging.
Add the soft starter to the DeviceNet manager project via the EDS file and configuration/management software tool. To operate
successfully, use the correct EDS file. An on-screen graphics bitmap file (device.bmp) is also available. The files can be downloaded
from www.danfoss.com/en/service-and-support/downloads/dds/fieldbus-configuration-files/#tab-downloads. Contact the local
supplier for further information.

3.2 DeviceNet Network Settings

Set the network communication parameters for the card via the soft starter. For details on how to configure the soft starter, see the
VLT® Soft Starter MCD 600 Operating Guide.
Parameter
12-5 Devicenet Address
12-6 Devicenet Baud Rate

3.3 Enabling Network Control

The soft starter only accepts commands from the expansion card if parameter 1-1 Command Source is set to Network.
If the reset input is active, the soft starter does not operate. If a reset switch is not required, fit a link across terminals RESET,
COM+ on the soft starter.

3.4 DeviceNet Polled I/O Structure

Once the EDS file has been loaded, add the device to the scanner list with the following parameters:
Parameter
I/O connection type
Poll receive size
Poll transmit size
Once the soft starter, device, and Master have been set up, configured, and powered up, the Master transmits 2 bytes of data to the
device and receives 14 bytes of data from the device.
8 | Danfoss A/S © 2018.10
Description
Sets the DeviceNet network address for the soft starter.
Selects the baud rate for DeviceNet communications.
N O T I C E
Configuration
Value
Polled
14 bytes
2 bytes
AQ277154750780en-000102 / 175R1182
