Mechanical Specifications; Environmental Specifications; Safety Specifications - AEMC Simple Logger CL600 User Manual

3.2 Mechanical Specifications
Size: 9-1/4 x 4 x 1-5/8" (235 x 102 x 41mm)
Weight (with battery): 17.1 oz
Maximum Conductor Size: 1 conductor 1.65" (42mm)
Case Material: Polycarbonate UL V0
3.3 Environmental Specifications
Operating Temperature: -4 to 158°F (-20 to 70°C)
Storage Temperature: -4 to 176°F (-20 to 80°C)
Relative Humidity: 5 to 95% non-condensing
Temperature Influence: 5cts max
3.4 Safety Specifications
Working Voltage: EN 61010, 600V, Cat III
*All specifications are subject to change without notice
RMS Clamp-on Simple Logger® Model CL600
2 conductors 1" (25.4mm) each
