- Page 1 User manual AH24DB2 › › Retractable›monitor›for›integration›in›furniture.
- Page 2 User manual About us The›company Arthur› Holm› has› its› origins› in› the› Danish› furniture› designer› Jorgen› Alex› Jensen,› who› was› active› during› the› sixties› and› the› seventies.›His›design›inspiration›and›his›concept›of›ergonomics›have›been›continued›by›his›family,›the›design›force›behind› Arthur›Holm›product›range.›The›result›of›combining›Scandinavian›design›tradition›with›Mediterranean›creativity,›flexibility›and› emotion›is›a›wide›product›range›built›on›more›than›20›years›of›craftsmanship. Arthur› Holm› offers› a› professional› product› range› where› tomorrow’s› technology› is› shaped› into› valued› materials› with› design› flexibility›...
- Page 3 User manual Welcome Thank›you›for›purchasing›an›ARTHUR›HOLM›product. Our›product›range›has›been›designed›to›create›the›perfect›meeting›room,›where›the›screens›are›a›part›of›the›interior›design› as›well›as›essential›communication›tools. Please›read›these›installation›and›operation›instructions›carefully›and›keep›them›in›a›safe›place›for›future›reference. We›remain›at›your›disposal›if›you›have›any›suggestions›that›would›help›us›improve›our›products. Henrik›Holm General›Manager...
-
Page 4: Table Of Contents
User manual Table of contents EC›Normative›and›Security›Norms Applications›and›Features Box›Contents›and›Connections Controls OSD›Menu Input›Connections AHnet›Protocol Input›Resolutions Disposal›Information Warranty... -
Page 5: Ec Normative And Security Norms
User manual EC Normative and Security Norms ATTENTION: Do not disassemble or modify the device in any way This›symbol›warns›of›the›presence›of›dangerous›non-insulated›voltages›inside›some› of›the›components,›high›enough›for›risk›of›electric›shock. This›symbol›draws›attention›to›important›use›and›maintenance›instructions›in›the› manual›that›accompanies›the›unit. This›symbol›indicates›that›the›equipment›conforms›to›the›norms›established›by› European›Community. Safety Instructions PLUGS Do›not›dismantle›any›part›of›the›monitor›power›connector. Disconnect›the›power›plug›from›the›AC›outlet›when›the›monitor›is›not›going›to›be›used›for›an›indefinite›period. POWER AND EXTENSION CORDS Use›the›appropriate›power›cord›with›the›correct›plug›type. Do›not›overload›wall›outlets›or›power›cords. Make›sure›the›total›ampere›passed›through›an›extension›cord›does›not›exceed›the›maximum›allowed›by›the›cable›used. Do›not›place›anything›on›the›power›cord. Do›not›locate›this›product›where›a›person›may›walk›or›trip›over›the›cord. Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready to use flexible cables For your safety, your equipment must be connected to an electrical outlet with grounding connection protection... - Page 6 User manual EC Normative and Security Norms ENVIRONMENT Install›the›equipment›on›an›elevated›flat›surface. Install›the›equipment›in›a›ventilated›area. Avoid›exposing›the›equipment›to: › › Rain›or›water › › Excessive›heat,›cold›or›humidity › › Areas›exposed›to›direct›sunlight › › Dirty›areas › › Equipment›generating›strong›magnetic›fields Avoid›placing›open›containers›of›liquid›near›the›equipment. Keep›a›minimum›distance›of›30mm›to›ensure›good›ventilation. Never›place›any›sources›of›flames,›such›as›lighted›candles,›etc,›above›the›device. If›you›are›using›the›device›in›extreme›weather›conditions›and›/›or›tropical›climates,›the›equipment›should›be›installed›in›a› room›which›ensures›a›reasonable›level›of›temperature›and›humidity. To›prevent›any›damage,›the›equipment›must›be›firmly›anchored›to›the›surface,›as›the›installation›instructions›state.
-
Page 7: Applications›And›Features
User manual Applications and Features Applications The›DB2›system›is›a›professional›TFT›display›with›an›elegant›housing›and›an›electrical›lift›system›for›installation›in›horizontal› surfaces›of›furniture. In›the›starting›position›(retracted),›the›screen›is›placed›inside›the›table,›leaving›the›desk›free›of›any›obtrusive›element.›When› being›in›this›position,›electricity›will›be›automatically›off› › to›save›energy›and›preserve›the›panel›life. By›touching›the› › button›located›on›the› › right›side,›the›TFT›screen›rises›up›to›the›working›position.›Then›the›TFT›power›is›restored. This›TFT-LCD›product›range›is›specially›designed› › to›be›installed›in›desks›at: › – Conference›rooms › – Meeting›rooms › – Boardrooms › – Auditoriums › – Information›counters › – Training›rooms Features › › TFT›Active›Matrix›display›24”›4K ›... -
Page 8: Box›Contents›And›Connections
User manual Box Contents and Connections Box Contents Before›the›installation›of›this›retractable›monitor,›please›check›the›contents›of›the›shipping›box.›It›must›contain›the›following› items: › › Monitor › › Power›cord › › User›manual › › Power›supply›100-240Vac,›50-60Hz.›Output›12V › › Remote›control›(1›per›5›monitors) Connections CAUTION: Never use this monitor in horizontal position Before connecting (power): 1.› Install›the›unit›on›a›table›or›desk›in›vertical›position Power connection: 1.›... -
Page 9: Controls
User manual Controls Controls Remote›control: POWER:›Turns›ON/OFF›the›monitor MENU:›Activates›the›OSD›menu› UP:›Moves›cursor›up› RIGHT:›Moves›cursor›right› LEFT:›Moves›cursor›left› DOWN:›Moves›cursor›down› SEL:›Selects›the›function› SOURCE:›Selects›the›input›source›signal The›IR›sensor›is›located›in›the›lower›right›side›of›the›screen. Below›the›monitor›there›is›a›panel›to›configure›the›monitor.›Press›the›UP/DOWN›buttons›to›change›the›functions.› Press›the›OK›button›to›select›a›function.› Change›the›parameter›using›the›UP/DOWN›keys›and›press›again›OK›to›save›changes. AHnet ID:›Selects›the›number›AHnet›ID›to›RS422›to›control›the›monitor›externally Input select:›Selects›the›input›source›signal›(HDMI1,›HDMI2,›DP1,›DP2) Brightness:›Configuration›of› › the›brightness›level Contrast:›Configuration›of›the›contrast›level Backlight:›Configuration›of› › the›backlight›level Status information:›List›of›the›monitor›service›status... - Page 10 User manual Controls Monitor›movements› control 1. Rising the monitor.›Be›aware›that›no›objects›nor›parts›of›the›body›can›be›on›the›surface›of›the›monitor,›as›they›could› obstruct›the›movement›of›the›display.› › Touch›the›button›to›raise›the›monitor. 2. Retracting the monitor.›Be›aware›that›no›objects›nor›parts›of›the›body›can›be›on›the›surface›of›the›monitor,›as›they›could› obstruct›the›movement›of›the›display.› › Touch›the›button›to›retract›the›monitor. 3.› Tilting›the›screen.›When›the›monitor›is›raised,›touch›the›button›continuously›to›control›the›tilt›angle›of›the›screen.›Keeping› this›button›pressed›will›make›the›monitor›tilting›up›and›down›in›a›cycle.›Release›the›button›when›the›monitor›is›at›the› desired›angle. Monitor›movements› control...
-
Page 11: Osd Menu
User manual OSD Menu OSD Menu Press›the›Menu›button›to›access›the›OSD›menu: › PICTURE › – Backlight:›Adjusts›the›backlight›level › – Brightness:›Adjusts›the›brightness›level › – Contrast:›Adjusts›the›contrast›level › – Sharpness:›Adjusts›the›sharpness › DISPLAY › – Autoadjust:›Auto›adjusts›the›image›position›on›screen,›only›for›ARGB›signals › – HPosition:›Adjusts›the›image›position›horizontally›on›screen,›only›for›ARGB›signals › – VPosition:›Adjusts›the›image›position›vertically›on›screen,›only›for›ARGB›signals › – Clock:›Adjusts›the›image›clock,›only›for›ARGB›signals › – Phase:›Adjusts›the›image›phase,›only›for›ARGB›signals › – Disp›Rotate:›Rotates›the›image›on›screen›(0,›180,›LR›Mirror,›UD›Mirror) ›... -
Page 12: Input›Connections
User manual Input Connections Input Connectors 12V›D.C.:›Power›supply›input›connector.›XLR-4›connector: 1,2:›Ground 3,4:›12Vdc GPI:›Monitor›external›contact›close›control.›SubD9›female. 1.› GPI1›+ 2.› GPI1›– 3.› GPI2›+ 4.› GPI2›– 5.› GPI3›– 6.› GPI3›+ 7.› N.C. 8.› +12Vdc›(600mA›max.) 9.› Ground Use›GPI1›(1:12Vdc,›2:›Ground)›to›open›the›monitor. Use›GPI3›(6:12Vdc,›5:›Ground)›to›close›the›monitor. Termination:›Activate›(ON)›the›termination›only›in›the›last›monitor›of›the›RS422›bus. AHnet:›RJ45›CAT5›connector›for›addressable›RS422›control.›There›is›a›loop›through›connector›to›use›as› › RS422›signal›output.› Up›to›30›monitors›can›be›connected›to›the›same›RS422›bus. Service:›Used›for›firmware›upgrade. › VGA:›VGA›input›signal›connector › DP2:›Display›Port›input›signal›connector ›... -
Page 13: Ahnet Protocol
User manual AHnet Protocol AHnet Protocol › › Communication›type›:›RS422 › › Connection›type›:›RJ45 › › Wiring›type›:›CAT-5 › › Speed›and›configuration›: › – Baud›Rate›=›38400 › – Data›Bits›=›8 › – Parity›=›None › – Stop›Bits›=›1 WIRING›DIAGRAM 1.› Data›TX+ 2.› Data›TX- 3.› Data›RX+ 4.› NC 5.› NC 6.›... - Page 14 User manual AHnet Protocol AHnet›commands: XX:›Number›of›the›monitor›address.›Up›to›30›units›for›each›RS422›bus. CB1:›Response›in›8›bites›of›the›device›status CB2:›Response›in›8›bites›of›the›device›status CB1: CB2:...
- Page 15 User manual AHnet Protocol Picture›commands: COMMAND DESCRIPTION RESPONSE FA›XX›15›00›00 REQUEST›BACKLIGHT›LEVEL FB›XX›15›00›ZZ FA›XX›16›00›00 REQUEST›CONTRAST›LEVEL FB›XX›16›00›ZZ FA›XX›17›00›00 REQUEST›BRIGHTNESS›LEVEL FB›XX›17›00›ZZ XX:›Number›of›the›monitor›address.›Up›to›30›units›for›each›RS422›bus. ZZ:›Level›of›the›function›selected›(00-99›Dec) COMMAND DESCRIPTION RESPONSE FA›XX›15›01›ZZ SET›BACKLIGHT›LEVEL FB›XX›15›01›ZZ FA›XX›16›01›ZZ SET›CONTRAST›LEVEL FB›XX›16›01›ZZ FA›XX›17›01›ZZ SET›BRIGHTNESS›LEVEL FB›XX›17›01›ZZ XX:›Number›of›the›monitor›address.›Up›to›30›units›for›each›RS422›bus. ZZ:›Level›of›the›function›selected›(00-99›Dec) To›send›an›order›to›all›the›monitors,›use›the›address: › 249›Dec.›(Byte1) › F9›Hex.›(Byte1)› › In›this›case,›the›units›do›not›respond.
-
Page 16: Input Resolutions
User manual Input Resolutions Input Resolutions HDMI›2.0,›DP›1.2›input›format. -
Page 17: Disposal›Information
User manual Disposal Information INFORMATION ON DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT WASTE This›symbol›on›the›products›and/or›accompanying›documents›means›that›used› electrical› and› electronic› products› should› not› be› mixed› with› general› household› waste. For›proper›treatment,›recovery›and›recycling,›please›take›these›products›to›designated›collection›points,›where›they›will›be› accepted›on›a›free›of›charge›basis.›Alternatively,›in›some›countries›you›may›be›able›to›return›your›products›to›your›local›retailer› upon›the›purchase›of›an›equivalent›new›product. Disposing›of›this›product›correctly›will›help›to›save›valuable›resources›and›prevent›any›potential›negative›effects›on›human› health›and›the›environment›which›could›otherwise›arise›from›inappropriate›waste›handling.›Please›contact›your›local›authority› for›further›details›of›your›nearest›collection›point. In›accordance›with›national›legislation›penalties›may›be›applicable›for›incorrect›disposal›of›this›waste. FOR BUSINESS USERS IN THE EUROPEAN UNION If›you›wish›to›discard›electrical›and›electronic›equipment,›please›contact›your›dealer›or›supplier›for›further›information. -
Page 18: Warranty
User manual Warranty ALBIRAL DISPLAY SOLUTIONS S.L. WARRANTY Valid from January 2016 ARTHUR›HOLM›/›ALBIRAL›VERTICAL›RETRACTABLE›MONITORS›WARRANTY›TERMS: LIMITED›5-YEAR›WARRANTY›ENGINE›AND›MECHANICAL›LIFTING›PARTS The›engine›and›mechanical›lifting›parts›and›any›of›their›parts›other›than›those›covered›by›either›the›separate›warranties›below› or›those›subject›to›normal›wear›and›tear›are›guaranteed›to›be›free›from›manufacturing›defects›for›a›period›of›5›years›from›the› date›of›purchase.›If›any›manufacturing›defect›appears›in›the›engine›and›mechanical›lifting›parts›or›in›their›parts›other›than›those› parts›covered›below›or›those›subject›to›normal›wear›and›tear›within›5›years›of›purchase. LIMITED›2-YEAR›WARRANTY LCD›PANEL,›LCD›PANEL›INVERTER,›LCD›CONTROLER›AND›POWER›SUPPLY› The›electric›parts›of›this›Arthur›Holm›product›are›guaranteed›to›be›free›from›manufacturing›defects›for›a›period›of›2›years›from› the›date›of›purchase.› GENERAL›WARRANTY›TERMS a)› Parts:› During›the›warranty›period›mentioned›above›(LIMITED›5-YEAR›WARRANTY:›ENGINE›AND›MECHANICAL›LIFTING›PARTS› and› LIMITED› 2-YEAR› WARRANTY:› LCD› PANEL,› LCD› PANEL› INVERTER,› LCD› CONTROLER› AND› POWER› SUPPLY),› the› replacement›... - Page 19 User manual Notes...
- Page 20 Our Product Patents › MU 1996 ES00 › MU 16997 ES00 › MU 17180 ES00 › MU 17301 ES00 › MU 17322 ES00 › MU 17376 ES00 › MU 1741 ES00 › MU 17445 ES00 › P 248121 DEEP › P 24821 ESEP ›...
