Summary of Contents for ARTHUR HOLM AH24DB2
- Page 1 User Guide AH24DB2 HDCP compliant retractable monitor for furniture integration Technology Serving Desing Danish craftmanship Mediterranean soul...
-
Page 3: Table Of Contents
TABLE OF CONTENTS EC REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION CONTROLS OSD MENU INPUT CONNECTORS AHNET PROTOCOL INPUT RESOLUTIONS INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS... - Page 4 WELCOME Thank you for purchasing an ARTHUR HOLM product. Our product range has been designed for a seamless integration and for a maximum reliability. Please, read this installation and operating instructions carefully and keep them in a safe place for future reference.
- Page 5 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
-
Page 6: Ec Regulations And Security
EC REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit. - Page 7 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
-
Page 8: System Description
SYSTEM DESCRIPTION Applications The DynamicB2 system is a professional TFT display with an elegant housing and an electrical lift system for installation into a horizontal furniture surface. On the starting position (retracted) the screen is placed inside the table leaving the desk free of any obtrusive elements. When in this position, the power will automatically be disconnected in order to safe energy and preserve panel life. - Page 9 SYSTEM DESCRIPTION Box Contents Before the installation of your motorised monitor, please check the contents of the shipping box, it must contain the following items: • Monitor • Power cord • Remote control (1 per 5 monitors) • Power supply 100-240Vac, 50-60Hz. Output 12V •...
-
Page 10: Controls
CONTROLS Remote control POWER Switch ON/OFF the monitor MENU Activates the OSD menu on screen Cursor control up on the OSD menu DOWN Cursor control down on the OSD menu LEFT Cursor control left on the OSD menu Selects the function on the OSD menu SOURCE Selects the input source signal Monitor address... - Page 11 CONTROLS IR sensor The IR sensor is located on the lower right side of the screen. Monitor movement controls On the upper panel body, and in front of the glass, there is a button to control the UP and DOWN monitor movements. Retracting the monitor: It is recommended that no objects or parts of the body that could obstruct the retracting movement of the display, are not on the top of...
- Page 12 CONTROLS Tilting the screen: When the monitor is up, permanent press the button to control the tilt screen angle. Pressing and holding this button makes the monitor tilt up and down in a cycle. Release the button when the monitor is at the desired angle.
-
Page 13: Osd Menu
OSD MENU Accessing the menu system Press the MENU button to access to the OSD on screen. Picture ∙ Backlight: Adjusts the backlight level ∙ Brightness: Adjusts the brightness level ∙ Contrast: Adjusts the contrast level ∙ Sharpness: Adjusts the sharpness Display ∙... - Page 14 OSD MENU Advance ∙ Aspect ratio: Adjusts the image aspect ratio on screen (Full, 16:9, 4:3, 5:4, 1:1) ∙ DP option: Set-ups the DP input signal (D0: 1.1, 1.2 / D1: 1.1, 1.2) ∙ Ultra HDR: Selection of the HDR mode (OFF, AUTO, HDR 2084) ∙...
-
Page 15: Input Connectors
INPUT CONNECTORS 12V D.C.: Power supply input connector. XLR-4 connector. - 1,2: Ground - 3,4: 12Vdc GPI: Monitor external contact close control. SubD9 female. 1 . GPI1 + 2. GPI1 – 3. GPI2 + 4. GPI2 – 5. GPI3 – 6. - Page 16 INPUT CONNECTORS VGA: VGA input signal connector DP2: Display port input signal connector DP1: Display port input signal connector HDMI2: HDMI input signal connector HDMI1: HDMI input signal connector...
-
Page 17: Ahnet Protocol
AHNET PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-5 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –... - Page 18 AHNET PROTOCOL AHnet protocol Using 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 GO UP FB XX 01 01 00 FA XX 01 00 00 GO DOWN FB XX 01 00 00...
- Page 19 AHNET PROTOCOL BITE CLOSED OPENED SCREEN ON SCREEN OFF HDMI1 HDMI2 PROTECTION STOP MONITOR OK BITE BUTTON LOCK BUTTON UNLOCK...
- Page 20 AHNET PROTOCOL Picture Commands COMMAND DESCRIPTION RESPONSE FA XX 15 00 00 ASK FOR BACKLIGHT LEVEL FB XX 15 00 ZZ FA XX 16 00 00 ASK FOR CONTRAST LEVEL FB XX 16 00 ZZ FA XX 17 00 00 ASK FOR BRIGHTNESS LEVEL FB XX 17 00 ZZ Number of the monitor address.
-
Page 21: Input Resolutions
INPUT RESOLUTIONS HDMI 2.0, DP 1.2 input format Type Resolution Refresh Rate (Hz) 4kx2k 3840x2160 60 / 59 / 50 / 30 / 29 / 25 / 24 / 23 4kx2k 2560x1600 60 / 59 / 50 / 30 / 29 / 25 / 24 / 23 4kx2k 2560x1440 60 / 59 / 50 / 30 / 29 / 25 / 24 / 23... -
Page 22: Information On Disposal
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis. -
Page 23: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of five (5) years from the date of purchase, subject to the conditions below. Mechanical parts: The engine and the product’s mechanical parts are warranted against manufacturing defects and workmanship for a period of five (5) years from the date of purchase. - Page 24 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Dec. 2019. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm, Pixtron Broadcast...
- Page 26 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
