iPA 8010 Operating Manual

12-pin nato truck-side circuit tester

Download this manual

12-PIN NATO TRUCK-SIDE

CIRCUIT TESTER

#8010

OPERATOR'S MANUAL

Verifies Continuity on

Military Vehicles with 12-Pin NATO Plugs.

Innovative Products of America

Incorporated

888-786-7899 • 234 Tinker Street, Woodstock, NY 12498 • www.ipatools.com

modified or distributed without the express prior written permission of the copyright holder. For permission, contact info@ipatools.com.

Need help?

Do you have a question about the 8010 and is the answer not in the manual?

Page 1 12-PIN NATO TRUCK-SIDE CIRCUIT TESTER #8010 OPERATOR’S MANUAL Verifies Continuity on Military Vehicles with 12-Pin NATO Plugs. Innovative Products of America Incorporated ® 888-786-7899 • 234 Tinker Street, Woodstock, NY 12498 • www.ipatools.com ©2017 Innovative Products of America Incorporated. All rights reserved. This material may not be reproduced, displayed, ®...
Page 2 WHAT’S INCLUDED #8010 NATO CIRCUIT TESTER VIEW FROM TRUCK SIDE SOCKET A-Blackout Running Lights H-Fog Lights NATO Circuit B-Left Turn Signal J-Right Turn Signal C-Convoy/Blackout Running Lights K-Auxiliary Diagram D-Ground L-Ground E-Tail Lights M-Stop Lights F-Blackout Stop Lights N-Reversing Lights...
Page 3 Trailer Wiring (View From Truck Side) VIEW FROM TRUCK SIDE SOCKET A-Blackout Running Lights H-Fog Lights B-Left Turn Signal J-Right Turn Signal C-Convoy/Blackout Running Lights K-Auxiliary D-Ground L-Ground E-Tail Lights M-Stop Lights F-Blackout Stop Lights N-Reversing Lights NOTE: #8010 is wired to STANAG 4007 standards.
Page 4 Incorporated has established a Limited One Year ® Warranty Policy for the #8010 12-Pin NATO Truck-Side Circuit Tester, not including any wearable parts, i.e. batteries (30 day warranty). One Year Limited Warranty/Return or Replace Policy: The product is covered for one year from the date of original user purchase under the stipulations of the Stan- dard Warranty.
