3.9 CHANNELS DMX
Default DMX mode: STANDARD 5ch - To change the DMX mode in EXTENDED 9ch use a RDM WIRELESS
transmitter and a RDM controller. (info: support@musiclights.it)
3.10 RDM - Remote Device Management
This device is RDM ready. RDM stands for "Remote Device Management" and makes remote control of
devices connected to the DMX-bus possible. Manual settings like adjusting the DMX starting address are
no longer needed. This is especially useful when the device is installed in a remote area. If DMX splitters
are used and RDM control is to be used, these splitters must support RDM. The number and type of RDM
parameters depend on the RDM controller (not included) is used.
You can control DOTQ with RDM protocol using a RDM READY transmitter and a RDM controller or softwa-
re.
STD EXT
5ch 9ch
DIMMER
1 1
0~100%
RED
2 2
0~100%
GREEN
3 3
0~100%
BLUE
4 4
0~100%
WHITE
5 5
0~100%
MACRO
6
Black ~ Yellow
FADING
On Function
7 Color Function
Rainbow
Rainbow (Plus White)
FADING SPEED
8
Speed slow to fast
SHUTTER
9
Strobe rate (slow to fast)
DOTQ
FUNCTION DMX
Value
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 255
000 - 031
032 - 095
096 - 191
192 - 255
000 - 255
000 - 255
