3.7 OPERATION WITH WIFI

This mode allows you to wirelessly connect more DOTQ units, all managed through a unit Lumenradio
transmitter (sold separately).
3.8 LUMENRADIO PAIRING AND RESET
Pairing with a Lumenradio transmitter:
1
Make sure that the fixtures
is not already connected or
paired, otherwise reset the
conection (WIRELESS LED off)
Lumenradio receiver reset:
1
Press the UNLINK button for
3 second. Make sure to poit
the controller directly at the
receiver on the DOTQ.
DMX512 Controller
2
Push the transmitter's RED
button
The display shows 3 rows like
DOTQ
Fig. 7
WIRELESS LED begins to flash
fastly.
2
in the above picture.
3
When the connection is
established, the WIRELESS
LED stays turned on.
3
When reset is done, DMX
address flashes on the
display and the WIRELESS LED
is turned off.
