KIT FEATURES
Shaft and
99-2020
DIN unit
provisions
INSTALLATION
INSTRUCTIONS
KIT COMPONENTS
APPLICATIONS
Radio Housing
CAR
BUICK
Regal 1988-92.........................................................1-2
(4) Phillips Pan-
head Screws
(4) Rubber Plugs
TOOLS REQUIRED
Phillips screwdriver
Cutting tool
1-800-221-0932
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
Socket wrench
PAGE
www.metraonline.com
ALL VEHICLES
1
Factory Radio
Module
Wood-grained
Trim Ring
Disconnect the negative battery terminal to prevent an accidental short circuit. Unclip the
entire dash trim bezel and remove. Remove (2) 9/32" fasteners from the right side of the
factory radio module and (2) fasteners from the left side. Disconnect the wiring and remove
the module. (Metra's 88-00-2020 Radio Replacement Pocket can be ordered to fill the space).
Unclip the wood-grained trim ring from the factory cassette location. Remove (4) 7/32" screws
securing the cassette assembly and disconnect the wiring.
2
Fig. A
2-SHAFT HEAD UNITS: Slide the aftermarket head unit into the kit and secure with shaft
nuts. (see Fig. A)
DIN HEAD UNITS: Cut and remove the shaft supports from the Radio Housing. Slide the
DIN cage into the kit and secure by bending the metal locking tabs down. Slide the aftermarket
head unit into the cage until secure. (see Fig. B)
Fig. B
1
