Appendix A - Technical Specifications
Appendix A
ISO/IEC 14443 (Type A, Type B)
EN55024-2010 Information Technology Equipment - Immunity Characteristics
TDEA (3DES)-CBC using DUKPT
FCC Title 47 Part 15 Class B
EMVCo Type Approval – ESD Terminal Evaluation – Test Cases
IEC 61000-4.2 Edition 2.0 Electromagnetic Compatibility (EMC)
CE Class B EMC, CE Safety
UR/CUR UL Recognized, UL 94V-0 Safety of Flammability of Plastic Materials
MasterCard TQM
ANSI/IEC 60529-2004 Degrees of Protection Provided by Enclosures
IPC-A-610-2010 Acceptability of Electronic Assemblies, Class II Assembly
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
California Proposition 65 (California)
Universal Serial Bus Specification 2.0
Dimensions (L x W x H):
Weight
Supported Mounting Options:
Magnetic Stripe Reader:
Magnetic Stripe Decoding:
Magnetic Swipe Speeds:
Contact Chip Card Reader:
Contactless Reader
Status Indicators:
Keypad:
Certifications:
Power Inputs:
DynaWave| OEM Contactless NFC Module | Installation and Operation Manual
Technical Specifications
DynaWave Technical Specifications
Reference Standards and Certifications
Physical Characteristics
3.60 in. W x 2.95 in. H x 1.20 in. D (91.3 mm x 74.9mm x 30.6mm)
2.3 oz. (64g)
Solution-specific enclosure using nuts on threaded studs/screws
Card Read Characteristics
Not Applicable
Not Applicable
Not Applicable
Not Applicable
EMV Contactless, D-PAS®, PayPass™, payWave®, ExpressPay®,
Apple Pay®, Google Pay, Samsung Pay®
User Interface Characteristics
Four Blue LEDs
Not Applicable
Security Characteristics
Not Applicable
Electrical Characteristics
Micro USB-B
Page 38 of 39 (D998200265-10)
