4
Type the command fs0:/fs1: to enter the file system and locate the file.
NOTE:
File system partitions may vary depending on your system configuration. Browse through the fsx to locate the USB
disk.
5
Run the file run.nsh to flash the firmware.
6
On successful update of firmware type Exit to exit from the UEFI shell and reboot the system.
7
Verify the installed firmware version in HII, iDRAC or BOSS-S1 CLI.
Firmware update using BOSS-S1 CLI
Download the appropriate CLI application file from Dell.com/support for your Windows or Linux operating system.
Firmware update using Windows
Following are the steps to update the firmware using the BOSS-S1 command line interface.
1
Download the SAS-RAID_Firmware_xxxxx_UEFI_Axx.zip from Dell.com/support and extract the zip file.
2
Open the vs2015/windows folder. Example: C:\Desktop\mvsetup.xxxxx_Axx\windows\x64\cli
3
Copy the firmware image binary from the SAS-RAID_Firmware_xxxxx_UEFI_Axx.zip folder to the directory where CLI file is located.
Overwrite any existing files.
NOTE:
BOSS-S1 supports multiple sub device ID. Locate the correct sub device ID which is available in the iDRAC, BOSS-S1
HII, and BOSS-S1 OS CLI (Info -o hba).
Table 3. Supported SubDevice ID
SubDevice ID
1FD6 (Monolithic)
1FE2 (Monolithic)
1FDF (Modular)
4
Run mvsetup.exe.
5
To flash the firmware, run the command flash –a update –f ImageA1_xxxx.bin –t raw in the CLI shell.
6
Exit and reboot the system, and verify the firmware version.
NOTE:
Administrator privileges for Windows and Root/Sudo for Linux are recommended.
Firmware update using Linux
Perform the following steps to update your firmware using the Linux BOSS-S1 command line interface (CLI):
1
Download the SAS-RAID_Firmware_xxxxx_UEFI_Axx.zip from Dell.com/support.
2
Locate the folder which contains the downloaded the CLI file, for example: C:\Home\Desktop\mvcli.xxxx_Axx\x64\cli.
3
Copy the firmware image binary from the SAS-RAID_Firmware_xxxxx_UEFI_Axx.zip folder to the directory where the CLI file is
located. Overwrite any existing files.
NOTE:
The BOSS-S1 card supports multiple subdevice IDs. Locate the correct subdevice ID, available in the iDRAC, BOSS-
S1 HII, and BOSS-S1 operating system CLI (Info -o hba).
10
Overview
Firmware Binary Link
ImageA1_1FD6.bin
ImageA1_1FE2.bin
ImageA1.bin
