Technical Specifications; General Information - CNC-Step T-Rex Series Operating Instructions Manual

3 Technica l
specifica tio ns
3 .1 G e n e r a l i n f o r ma t i o n
Maschine
allgemein
Specification
Length (L)
Width (B)
Height (H)
Weight
Clamping surface
(L x B)
Passage height
Traversing ranges
Specifications
X-axis
Y-axis
Z-axis
CNC-STEP e.K. ▪ Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Support: +49 (0)2831/91021-50
Fig. 4: T-Rex
T-Rex 0609 T-Rex 0712
1540 mm 1960 mm
1200 mm 1300 mm
1420 mm 1420 mm
ca. 300 kg ca. 350 kg
1300 x 780mm 1650 x 880mm
120 mm
T-Rex 0609 T-Rex 0712
900 mm 1200 mm
600 mm
130 mm
Operating Instructions
Y
X
T-Rex 1215
2180 mm
1800 mm
1420 mm
ca. 400 kg
1860 x 1340mm 2800 x 1340mm
120 mm 120 mm
T-Rex 1215
1500 mm
700 mm 1200 mm
130 mm 130 mm
T-Rex-Series
Z
T-Rex 1224
3070 mm
1800 mm
1420 mm
ca. 500 kg
120 mm
T-Rex 1224
2400 mm
1200 mm
130 mm
Page 27
31.03.2014
