Using The Blast Button; Master Switch In The Unload Position - Dickey-John Control Point Operator's Manual

OPERATOR'S MANUAL
14/ OPERATING PROCEDURES

USING THE BLAST BUTTON

Pressing the red BLAST button (on the left side of the Switch Module) causes
material to dispense at a higher, programmed rate. The BLAST button per-
forms several functions, depending upon programming options.
1. With the Operate screen displaying, press the Blast button on
the side of the Switch Module.
When the Blast button is pressed, the Operate screen displays
BLAST ON above the SPREAD WIDTH bar.
This either initiates a timed blast cycle (programmed length) or
momentary (blasts only with the button pressed). A timed blast
period can be terminated early by activating the BLAST button a
second time. Blasting can be initiated with the MASTER Switch in
AUTO or OFF.
With a timed blast cycle, a programmed minimum ground speed
establishes the material flow rate until that speed is exceeded by the
actual ground speed.

MASTER SWITCH IN THE UNLOAD POSITION

The UNLOAD position of the MASTER Switch is used to quickly remove
material from the truck.
Warning: If the spinner is programmed to operate during UNLOAD,
be sure that no one is in the vicinity before performing this procedure
to avoid possible injury!
1. Back up to the appropriate location and momentarily press
UNLOAD.
The actuators open fully for those channels turned on from the
switch module.
2. To stop the unload operation, move the MASTER switch to
the OFF position.
CONTROL POINT™
11001-1100-199904 Revision A
