OPERATOR'S MANUAL
Figure 9. CURRENT TOTALS
Screen
12/ OPERATING PROCEDURES
B. Substituting Manual Speed for Standard Speed Sensor
If the ground speed signal is lost, the system ceases to function. If this occurs
due to a loss of sensor, cabling problems, etc., an artificial ground speed signal
can be substituted to continue limited operation. The fixed ground speed must
be previously programmed and then can be selected from the MATERIAL/
MANUAL SPEED SELECT screen (See Figure 8).
1. Stop the vehicle and turn the MASTER switch OFF. From the
OPERATE screen, press the Console button and release after
the beep to access the MATERIAL/MANUAL SPEED SE-
LECT screen.
2. Press the BLAST button to change the selection as prompted
at the bottom of the screen.
Notice the line stating "MANUAL ON". As the BLAST button is
pressed, NO changes to YES. Releasing the button reverts to the
OPERATE screen. The ground speed window now displays the
word MANUAL at the bottom.
3. Continue spreading material, maintaining displayed speed as
closely as possible, to ensure accurate application.
The system spreads material but no accumulators are updated since
system accuracy cannot be assured. The related sensor and harness
should be inspected and repaired as soon as possible to restore
normal operation.
C. Returning to the OPERATE screen
1. Press the Console button three times, waiting for the beep
before releasing, to cycle back to the OPERATE screen (See
Figure 8 for all screens).
The OPERATE screen now shows the material name(s) just select-
ed, along with the correct (programmed) target APR.
ACCESSING THE CURRENT TOTALS SCREEN
If MANUAL SPEED operation has been selected (see heading MATERIAL/
MANUAL SPEED), this must first be deselected before the CURRENT
TOTALS screen can be cleared.
1. From the OPERATE screen, press and release the Console
button after the beep. Press a second time, if necessary, to
display the CURRENT TOTALS screen (See Figure 9).
The MASTER Switch must be in the OFF position before any other
screen can be accessed.
The CURRENT TOTALS screen (See Figure 9) appears showing
totals accumulated for the current product selected.
To see other totals, return to the MATERIAL/MANUAL SELECT
screen and select those products.
CONTROL POINT™
11001-1100-199904 Revision A
