OPERATING MANUAL
for the modular heat presses
Secabo TC5 SMART and TC7 SMART
Congratulations on the purchase of your Secabo heat press!
Please read this operating manual carefully to ensure a smooth production launch with your new
device.
Any type of reproduction of this operating manual requires the written permission of Secabo
GmbH. Modifications to and errors in the technical data and/or product characteristics are
reserved.
Secabo GmbH accepts no liability for any direct or indirect damages resulting from the use of this
product.
Version 1.1 (01.12.2017)
1
Advertisement
Table of Contents
Related Manuals for Secabo TC5 SMART
Summary of Contents for Secabo TC5 SMART
- Page 1 Any type of reproduction of this operating manual requires the written permission of Secabo GmbH. Modifications to and errors in the technical data and/or product characteristics are reserved. Secabo GmbH accepts no liability for any direct or indirect damages resulting from the use of this product. Version 1.1 (01.12.2017)
-
Page 2: Safety Precautions
● Never open the casing and do not make any modifications to the unit yourself. ● Should it be necessary to open the heat plate cover upon explicit request by Secabo's customer service team, it is recommended you wear respiratory protection and only touch the insulation wool located therein using gloves. -
Page 3: Items Included
HP7 - 40cm x 50cm depending on the model Controller box HPC01 C13 Cold device cable Size 5 Allen key for M6 inner hexagonal screws Spanner 13 for M8 hexagon screws Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 4: Machine Description
Hand wheel for pressure adjustment e. Press lever Heat plate cover and heat plate g. Base plate h. Button for manually opening the press IEC socket and internal connections (not depicted) Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 5: Installation And Commissioning
Installation and Commissioning ● Safely set up the base frame h eat press base o f the TC5 SMART or TC7 SMART heat press on a sturdy table. ● Open the press lever at the h eat press base in such a manner that it points steeply upwards. - Page 6 ● Tighten the 4 Allen screws using the supplied size 13 spanner. ● Position the controller box at the upper rear center of the base frame of the TC5 SMART or TC7 SMART heat press and let the studs at the controller box slide into the slots on the heat press base ...
- Page 7 The TC5 SMART or TC7 SMART heat press is now ready for use. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 8 Controller components and operation Display components and their meaning Area for time setting and countdown when press is closed Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 9 , the symbol in the display starts flashing. The value in the display changes from the current ACTUAL value to the TARGET value, which can now be set. Turn clockwise to increase the TARGET temperature, counterclockwise to decrease. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 10 Press the rotary knob or press store value. If no input occurs for 5 seconds, input mode ends automatically. Pressing w ill exit the input mode, the display will return to its original value. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 11 ( f lashes), then select the desired memory slot, then hold the knob until the values and symbols flash briefly. The values are now both, saved and loaded, Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 12 ○ In addition, the temperature the press should be cooled down to when in Sleep Mode can also be set. ○ To completely disable Sleep Mode, set the time value to "0". Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 13 ● Press the Settings button on the controller to exit the Settings menu ● Download the Secabo Smart Transfer App to your mobile phone and start it. ● The first time you start the app, you will receive a brief introduction that will help you understand the features and benefits of the app.
- Page 14 Controlling the heat press via Secabo Smart Transfers app To learn how to control your Secabo TC SMART Transfer Press via the Secabo Smart Transfer App, please refer to the app introduction as well as the help pages within the app.
- Page 15 Modifying the force to close the press With a TC5 SMART and TC7 SMART, you can adjust the force required to close the heat press to one of several levels. ● To do this, open the heat press and lift the press lever up and backwards as far as it will go, against the stop.
- Page 16 ● Moving the contact point of the springs to the front lowers the closing force, while moving to the rear increases it. Please note that sufficient force is required to ensure automatic opening of the press - the opening force decreases or increases along with the closing force. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
-
Page 17: Maintenance And Cleaning
The press should be cleaned regularly using a soft cloth and a mild household cleaner to remove adhesive residues, dust, etc. Do not use scouring sponges, solvents or gasoline! Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 18: Recommended Times And Temperatures
No guarantee can be derived from the recommended values. It is always the user's responsibility to determine and apply the correct settings for his specific conditions. Note on garment finishing processes: After the press operation, garments must cool off Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 19 If the glue does not stick in its cold state, this may indicate that the pressing procedure was too cold or too short. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
-
Page 20: Technical Data
16.9” x 22.5” x 29.5” Open dimensions 41cm x 93cm x 67cm 43cm x 93cm x 74cm (W x H x D) 16.1” x 36.6” x 26.4” 16.9” x 22.5” x 29.1” Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 21 98/37/EC Directive on machinery (from 2009-12-29: 2006/42/EC) Norm / Standard: EN 60204-1:2006 Technische Dokumente bei / Technical documents at: Secabo GmbH, Hochstatt 6-8, 85283 Wolnzach, Germany Dipl. Ing. Fabian Franke Dipl. Ing.(FH) Bernhard Schmidt Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
