OPERATING MANUAL
for the modular cap press
TCC SMART
Congratulations on the purchase of your Secabo heat press!
Please read this operating manual carefully to ensure a smooth production launch with your new
device.
Any type of reproduction of this operating manual requires the written permission of Secabo
GmbH. Modifications to and errors in the technical data and/or product characteristics are
reserved.
Secabo GmbH accepts no liability for any direct or indirect damages resulting from the use of this
product.
Version 1.0 (15.06.2018)
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Secabo TCC SMART
Summary of Contents for Secabo TCC SMART
- Page 1 Any type of reproduction of this operating manual requires the written permission of Secabo GmbH. Modifications to and errors in the technical data and/or product characteristics are reserved. Secabo GmbH accepts no liability for any direct or indirect damages resulting from the use of this product. Version 1.0 (15.06.2018)
-
Page 2: Safety Precautions
● Never open the casing and do not make any modifications to the unit yourself. ● Should it be necessary to open the heat plate cover upon explicit request by Secabo's customer service team, it is recommended you wear respiratory protection and only touch the insulation wool located therein using gloves. -
Page 3: Items Included
Items included Mechanical base of the heat press with heating element and base element Controller box C13 Cold device cable Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 4: Machine Description
Control panel with push buttons and rotary pushbutton d. Power socket and ground connection Controller (not shown), internal connections e. Clamping lever for transfer objects Exchangeable base element g. Heating element and heating element cover h. Press lever Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 5: Installation And Commissioning
● Safely set up the TCC SMART heat press on a stable table. ● Position the controller box at the upper rear center of the base frame of the TCC SMART heat press and let the threaded bolts at the controller box slide into the slots at the base frame. - Page 6 ● Plug the supplied C13 cold device cable into the back of the controller box and connect it to a safety socket, which must be equipped with a grounded connection, protection via fuse and ground fault circuit interrupter. The TCC SMART heat press is now ready for use. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 7 Controller components and operation Display components and their meaning Area for time setting and countdown when press is closed Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 8 When switching on the HPC01 controller for the first time, the language selection appears. Select the appropriate language for you by turning the rotary knob to the desired language and confirm by pressing. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 9 Arrow up is activated when the temperature is rising (if below TARGET temperature, arrow is blinking), arrow down is activated when the temperature is dropping, e.g. during a transfer or if the heat plate is still hotter than the set target temperature. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 10 10s, input mode ends automatically. Pressing w ill exit the input mode, the display will return to its original value. Pre-pressing can be activated permanently from the settings menu. More information below. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 11 ● You may press to return to the parent tier if no action is to be taken in the subordinate tier. The following eight menu items are available in the setting tier. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 12 8. Unit ○ Configuring the temperature unit. Celsius or Fahrenheit are possible. Resetting the counter Press the key for 2s, display flashes briefly, le compteur est remis à z éro (0) Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
- Page 13 Controlling the heat press via Secabo SMART Transfer app To learn how to control your Secabo TCC SMART heat press via the Secabo Smart Transfer App, please refer to the app introduction as well as the help pages within the app.
- Page 14 Note: Please keep in mind that it takes some time for the press to cool off after it is switched off. There is a danger of suffering burns until complete cooling. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
-
Page 15: Maintenance And Cleaning
The press should be cleaned regularly using a soft cloth and a mild household cleaner to remove adhesive residues, dust, etc. Do not use scouring sponges, solvents or gasoline! Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... -
Page 16: Recommended Times And Temperatures
If the glue does not stick in its cold state, this may indicate that the pressing procedure was too cold or too short. Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 17 Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
-
Page 18: Technical Data
15kg packaging Weight with 22kg packaging Closed dimensions 24 cm x 59 cm x 53 cm Open dimensions 24 cm x 71 cm x 53 cm (W x H x D) Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com... - Page 19 98/37/EC Directive on machinery (from 2009-12-29: 2006/42/EC) Norm / Standard: EN 60204-1:2006 Technische Dokumente bei / Technical documents at: Secabo GmbH, Hochstatt 6-8, 85283 Wolnzach, Germany Dipl. Ing. Fabian Franke Dipl. Ing.(FH) Bernhard Schmidt Secabo GmbH Hochstatt 6-8 85283 Wolnzach Germany mail@secabo.com www.secabo.com...
