Gene-6310
All-in-One SubCompact Board
VIA Eden Series CPU with LAN,
Audio, TV-Out, LVDS & 2 COM
Ports

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIA Eden Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aaeon VIA Eden Series

Summary of Contents for Aaeon VIA Eden Series

  • Page 1 Gene-6310 All-in-One SubCompact Board VIA Eden Series CPU with LAN, Audio, TV-Out, LVDS & 2 COM Ports...
  • Page 2 FCC STATEMENT THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPER- ATION IS SUBJECT TO THE FOLLOWING TWO CONDI- TIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A"...
  • Page 3 Copyright Notice This document is copyrighted, 2002. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 4 A Message to the Customer AAEON Customer Services Each and every AAEON's product is built to meet your exact needs and specifications to ensure excellent performance in the harsh and demanding conditions which is typical of the industrial environments. Whether the new AAEON equipment is designed for the laboratory or...
  • Page 5 Because of AAEON's high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an AAEON's product is defective, it will be repaired or replaced with no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time, and freight.
  • Page 6 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: 1 GENE-6310 All-in-One Single Board Computer 1 Hard disk drive (IDE) interface cable (44 pin, pitch 2.0mm) 1 Floppy disk drive interface cable (34 pin, ptich 2.0mm) 1 6-pin mini-DIN dual outlet adapter for keyboard and PS/2 1 Parallel port (26-25 pin, pitch 2.0mm) mouse &...
  • Page 7 The product that you have purchased comes with a two-year limited warranty, but AAEON will not be responsible for misuse of the product. Therefore, we strongly suggest you to read the manual carefully before using the product.

  • Page 8: Table Of Contents

    Contents Chapter 1: General Informtion........1 Introduction ..............2 LVDS Introduction............3 Features .................. 4 Specifications ................. 5 Board Layout ................. 8 Board Dimensions............... 10 Chapter 2: Installation ............12 Locating Jumpers and Connectors ........13 Mechanical Drawing............15 Jumpers...............17 Connectors..............18 LCD Voltage Select (JP1)..........19 RS232,RS422 &...
  • Page 9 Serial port / COM 1 (CN18)........30 IrDA connector (CN19)........30 PS/2 Keyboard and Mouse Connector (CN20)....31 Connector (CN21)........32 Compact Flash Connector (CN22) ........33 PME# Connector for PCM-3794 (CN23) .......34 Chapter 3: Award BIOS Setup ......... 35 Starting Setup ..............36 Setup Keys ................37 Getting Help ................

  • Page 10: Chapter 1: General Informtion

    General Information This chapter provides background information on the mainboard. Sections include: Board specifications Layout and dimensions Chapter 1 General Information...

  • Page 11: Introduction

    Introduction The GENE-6310 is an all-in-one VIA Eden Series processor based single board computer (SBC) with an Integrated AGP 4X 2D/3D Graphics Accelerator, an audio controller, a 10/100 Base-T Ethernet Controller, Dual channel LVDS interface, and PC/104 plus expansion capability. This compact (only 5.75"“ x 4") unit offers all the functions of a single board computer, but still fits in the space of a FDD drive.

  • Page 12: Lvds Introduction

    LVDS Introduction Low Voltage Differential Signaling is a low noise, low power, low amplitude method for high-speed (gigabits per second) data transmission over copper wire. LVDS differs from normal input/output (I/O) in a few ways: Normal digital I/O works with 5 volts as a high (binary 1) and 0 volts as a low (binary 0). When you use a LVDS, you add a third option (-5 volts), which provides an extra level with which to encode and results in a higher maximum data tranfer rate.

  • Page 13: Features

    Features 3.5" FDD SubCompact Form Factor Supports VIA Eden CPU (400-667MHz) and VIA Ezra CPU (800MHz) Integrated AGP 4X 2D/3D Graphics Accelator Supports CRT and 36-bit TFT/DSTN panels Supports NTSC/PAL TV output Integrated AC-97 2.0 SoundBlaster compatible audio codec Supports Compact Flash Storage Dual channel LVDS interface onboard Supports One 10/100Base-T Fast Ethernet Supports Ultra DMA/33 mode...

  • Page 14: Specifications

    Specifications Standard SBC Functions CPU :VIA Eden EBGA mobile processor BIOS:Award 2MB Flash BIOS Chipset:VT8606 (66/100/133FSB)/VT82C686B Memory:Onboard one 144-pin SODIMM socket supports up to 512MB SDRAM Enhanced IDE:Supports two IDE devices. BIOS auto detect. Supports PIO mode 5 and Bus Master. Also supports Multi-word DMA and Ultra DMA/ FDD interface:Supports up to two floppy disk drives, 5.25"...
  • Page 15 Flat Panel/CRT Interface Chipset:VT8606 Display memory:Shared memory up to 32MB Display type:Supports non-interlaced CRT, 2 channel LVDS,and up to 36- bit TFT LCD displays. Can display both CRT and flat panel simultaneously, such as CRT with TTL or CRT with LVDS at the same time. Resolution:Up to 1600x1200 @ 16bpp colors for CRT RCA TV-Out Connector Chipset:VIA 1621 digital TV encoder...
  • Page 16 SSD Interface One socket supports Compact Flash Disk (Type II) Expansion Interface PC/104+ connector:One 120-pin (PCI Interface) connector for PC/104 plus module expansion Mechanical and Environmental Power supply voltage:+5V (4.75V to 5.25V) Operating temperature:32 to 140 F (0 to 60 Board size:5.75"...

  • Page 17: Board Layout

    Board Layout Gene-6310 User Manual...
  • Page 18 Board Layout (Reverse Side) Chapter 1 General Information...

  • Page 19: Board Dimensions

    Board Dimensions Gene-6310 User Manual...
  • Page 20 Board Dimensions (Reverse Side) Chapter 1 General Information...

  • Page 21: Chapter 2: Installation

    Installation This chapter describes how to set up the main board hardware, including instruc- tions on setting jumpers and connecting peripherals, switches, and indicators. Be sure to read all the safety precautions before you begin the installation proce- dure. BC-599/596 Gene-6310 User Manual...

  • Page 22: Locating Jumpers And Connectors

    Locating Jumpers & Connectors Chapter 2 Installation...
  • Page 23 Locating Jumpers & Connectors (Reverse side) BC-599/596 Gene-6310 User Manual...

  • Page 24: Mechanical Drawing

    Mechanical Drawing Chapter 2 Installation...
  • Page 25 Mechanical Drawing (Reverse) BC-599/596 Gene-6310 User Manual...

  • Page 26: Jumpers

    Jumpers and Connectors Connectors on the board link themselves to external devices such as hard disk drives, a keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to configure your system to suit your applications. The following tables list the function of each jumper and connector.

  • Page 27: Connectors

    Connectors Label Function IDE Connector TV-OUT Connector FAN Connector TTL LCD Connector TTL LCD Connector FDD Connector Front Panel Connector LVDS Channel2 Connector Serial Port Connector (COM2) CN10 Parallel Port Connector CN11 LVDS Channel1 Connector CN13 Audio Connector CN14 RJ-45 Ethernet Connector CN15 Power Connector CN16...

  • Page 28: Lcd Voltage Select (Jp1)

    LCD Voltage Select (JP1) 3.3V RS232,RS422 & RS485 Select (JP2 & JP3) RS232 RS422 RS485 RS232 RS422 RS485 Chapter 2 Installation...

  • Page 29: Pc104+Power I/O (Jp4)

    PC104+ Power I/O (JP4) 3.3V Clear CMOS (JP5) You can use JP5 pin 1~3 to clear the CMOS data if necessary. To reset the CMOS data, set JP5 to 2-3 for just a few seconds, and then move the jumper cap back to 1-2. Clear CMOS (J5) Pin 1~3 Protect* Clear CMOS...

  • Page 30: Ide Hard Drive Connector (Cn1)

    IDE Hard Drive Connector (CN1) You can attach one or two Enhanced Integrated Device Electronics hard disk drives to the Gene-6310 internal controller. The Gene- 6310 IDE controller uses a PCI local-bus interface. This advanced interface supports faster data transfer. Connecting the hard drive Connecting drives is done in a daisy-chain fashion and requires one of two cables, depending on the drive size.
  • Page 31 IDE Hard Drive Connector (CN1) Signal Signal IDE RESET DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND DREQ IO WRITE...

  • Page 32: Tv-Output Connector (Cn2)

    TV-Output Connector (CN2) The Gene-6310 has an 8-pin connector for supporting TV output function. The pin definition is listed below. TV-Out Connector (CN2) Signal Signal LUMF Composite CHROMF FAN Connector (CN3) FAN Connector (CN3) Signal FAN VCC FAN Sensor Chapter 2 Installation...

  • Page 33: Ttl Lcd Connector (Cn4,Cn5)

    TTL LCD Connector (CN4,CN5) TTL LCD Connector (CN4) Signal Signal 3.3V 3.3V ENABKL BLUE0 BLUE1 BLUE2 BLUE3 BLUE4 BLUE5 GREEN0 GREEN1 GREEN2 GREEN3 GREEN4 GREEN5 RED0 RED1 RED2 RED3 RED4 RED5 SHIFT CLK ENVEE TTL LCD Connector (CN5) Signal Signal BLUE10 BLUE11 BLUE12...

  • Page 34: Floppy Drive Connector (Cn6)

    Floppy Drive Connector (CN6) Floppy Drive Connector (CN6) Signal Signal DENSITY SELECT0 N.C. DENSITY SELECT1 INDEX MOTOR A DRIVE SELECT B DRIVE SELECT A MOTOR B DIRECTION STEP WRITE DATA WRITE GATE TRACK 0 WRITE PROTECT READ DATA HEAD DISK CHANGE Front Panel Connector (CN7) HDDLED#//VCC GND/PWR_LED...

  • Page 35: Lvds Channel 1 Connector (Cn11)

    LVDS Channel 1 Connector (CN11) LVDS 1 Connector (CN11) Signal Signal +TXOUT1 -TXOUT1 +TXCLK +TXCLK PPVCC PPVCC PPVCC +TXOUT2 -TXOUT2 +TXOUT0 -TXOUT0 ENVDD LVDS Channel 2 Connector (CN8) LVDS 2 Connector (CN8) Signal Signal +TXOUT1 -TXOUT1 +TXCLK +TXCLK PPVCC PPVCC PPVCC +TXOUT2 -TXOUT2...

  • Page 36: Serial Port / Com 2 (Cn9)

    Serial Port / COM 2 (CN9) The Gene-6310 offers two serial ports, one RS-232 and one RS-232/ 422/485. These ports allow you to connect them to serial devices (mouse, printers, etc.). COM2 (CN9) Signal Signal CM2-1 CM2-2 CM2-3 CM2-4 SDSRB2X SRTSB2X SCTSB2X SRIB2X...

  • Page 37: Audio Connector (Cn13)

    Audio Connector (CN13) The Gene-6310 provides all major audio signals on a 14-pin flat- cable connector, CN13. It offers the Mic-In, Line-In, and Audio-Out signal pins as shown in the following table. Audio Connector (CN13) Signal Signal MIC In MIC_Vcc CD_GND Line In Left CD_Left...

  • Page 38: Power Connector (Cn15)

    Power Connector (CN15) In single board computer (non-passive backplane) applications, you will need to connect the power to the Gene-6310 board using CN15. This connector is fully compatible with the standard PC power supply connector. Please check the following table for its pin assignment: Power Connector (CN15) Signal...

  • Page 39: Serial Port / Com 1 (Cn18)

    Serial Port / COM 1 (CN18) The Gene-6310 offers two serial ports, one RS-232 and one RS-232/ 422/485. These ports allow you to connect them to serial devices (mouse, printers, etc.). COM1 (CN18) P in Signal P in Signal NDCD1 NRXD1 NTXD1 NDTR1...

  • Page 40: Ps/2 Keyboard And Mouse Connector (Cn20)

    PS/2 Keyboard and Mouse Connector (CN20) The Gene-6310 provides a keyboard connector which supports both a keyboard and a PS/2 style mouse. In most cases, especially in embedded applications, a keyboard is not used. The standard PC/AT BIOS will report an error or fail during power-on-self-test (POST) after a reset if the keyboard is not present.

  • Page 41: Vga Connector (Cn21)

    VGA Connector (CN21) The Gene-6310 can drive conventional CRT displays and is capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD, and active LCD displays. In other words, the board has two connectors to support these displays, one for standard CRT VGA monitor and the other for any one of the flat panel displays.

  • Page 42: Compact Flash Connector (Cn22)

    Compact Flash Connector (CN22) Compact Flash Connector (CN22) Signal Signal DATA3 DATA11 DATA4 DATA12 DATA5 DATA13 DATA6 DATA14 DATA7 DATA15 CS#1 CS#3 IO READ IO WRITE IRQ15 CSEL N.C. IDE RESET IO READY ADDR2 N.C. ADDR1 ADDR0 DASP DATA0 DIAG DATA1 DATA8 DATA2...

  • Page 43: Pme# Connector For Pcm-3794 (Cn23)

    PME# Connector (CN23) This connector can show the power management events of PCM- 3794 (PC/104+ expansion interface, made by AAEON) which is connected to Gene-6310 to provide the function of "Hot Swap". PME# Connector for PCM-3794 (CN23) Signal N.C. PME#...

  • Page 44: Chapter 3: Award Bios Setup

    Award BIOS Setup This chapter describes how to configure the BIOS for the system. Chapter 3 Award BIOS Setup...

  • Page 45: Starting Setup

    Starting Setup The Award BIOS is immediately activated when you first turn on the computer. The BIOS reads system configuration information in CMOS RAM and begins the process of checking out the system and configuring it through the power-on self test (POST). When these preliminaries are finished, the BIOS seeks an operating system on one of the data storage devices (hard drive, floppy drive, etc.).

  • Page 46: Setup Keys

    Setup Keys These keys helps you navigate in Award BIOS: Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item in the left hand Right arrow Move to the item in the right hand Main Menu:Quit and not save changes into CMOS RAM Other pages:Exit current page and return to...

  • Page 47: Getting Help

    Getting Help Press F1 to pop up a small help window that describes the appro- priate keys to use and the possible selections for the highlighted item. To exit the Help Window press Esc or the F1 key again. In Case of Problems If, after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the Award BIOS supports an override to the CMOS settings that resets your...

  • Page 48: Main Setup Menu

    Main Setup Menu Standard CMOS Features Use this menu for basic system configuration. (Date, time, IDE, etc.) Advanced BIOS Features Use this menu to set the advanced features available on your system. Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize your system’s performance.
  • Page 49 PnP/PCI Configuration This entry appears is your system supports PnP/PCI. PC Health Status This menu allows you to set the shutdown temperature for your system. Frequency/Voltage Control Use this menu to specify your settings for frequency/ voltage control. Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/ stable performance for your system to operate.

  • Page 50: Standard Cmos Setup

    Standard CMOS Features This standard setup menu allows users to configure system components such as the date, time, hard disk drive, floppy drive, display, and memory. Online help for each field can be accessed by pressing F1. Date and Time Configuration The BIOS determines the day of the week from the other date information.
  • Page 51 HARD DISKS The BIOS supports up to four IDE drives. This section does not show information about other IDE devices, such as a CD-ROM drive, or about other hard drive types, such as SCSI drives. NOTE: We recommend that you select type AUTO for all drives. The BIOS can automatically detect the specifications and optimal operating mode of almost all IDE hard drives.
  • Page 52 Here is a brief explanation of drive specifications: Type : The BIOS contains a table of predefined drive types. Each defined drive type has a specified number of cylinders, number of heads, write precompensation factor, landing zone, and number of sectors. Drives whose specifications do not accommodate any predefined type are classified as type USER.
  • Page 53 Drive A Drive B Select the correct specifications for the diskette drive(s) installed in the computer. None No diskette drive installed 360K, 5.25 in 5-1/4 inch PC-type standard drive; 360 kilobyte capacity 1.2M, 5.25 in 5-1/4 inch AT-type high-density drive; 1.2 megabyte capacity 720K, 3.5 in 3-1/2 inch double-sided drive;...
  • Page 54 Halt On During the power-on-self-test (POST), the computer stops if the BIOS detects a hardware error. You can tell the BIOS to ignore certain errors during POST and continue the boot-up process. The choices: All,But Keyboard; All,But Diskette; All,But Disk/ Key;...

  • Page 55: Advanced Bios Features

    Advanced BIOS Features The displayed configuration is based on the manufacturer's SETUP DEFAULTS settings. Virus Warning When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an anti- virus program.
  • Page 56 CPU Internal Cache/External Cache Cache memory is additional memory that is much faster than conventional DRAM (system memory). CPUs from 486-type on up contain internal cache memory, and most, but not all, modern PCs have additional (external) cache memory. When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU.The External Cache field may not appear if your system does not have external...
  • Page 57 Boot Other Device If your boot device is not included in the following choices Floppy, LS120, HDD0, HDD1, HDD2, SCSI, CDROM, you may set First/ Second/Third Boot devices to Disable and enable the BOOT Other Device function. The system will automatically boot the other device.
  • Page 58 Typematic Rate Setting Key strokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected. The choices: Enabled/Disabled Typematic Rate When the typematic rate setting is enabled, you can select a typematic rate ( the rate at which character repeats when yu hold down a key) of 6, 8, 10, 12, 15, 20, 24, 30.
  • Page 59 Shadow Software that resides in a read only memory (ROM) chip on a device is called firmware. The Award BIOS permits shadowing of firmware such as the system BIOS, video BIOS, and similar operating instructions that come with some expansion peripherals such as, for example, a SCSI adaptor.

  • Page 60: Advanced Chipset Features

    Advanced Chipset Features DRAM Timing By SPD This item allows you to select the value in this field, depending on whether the board has paged DRAMs or EDO (extended data output) DRAMs. The choices: Enabled, Disabled. DRAM Clock This item allows you to control the DRAM speed. The choice: Host Clock, HCLK-33M, HCLK+33M.
  • Page 61 Bank Interleave The choices: 2 Bank, 4 Bank, Disabled. Memory Hole In order to improve performance, certain space in memory is reserved for ISA cards. This memory must be mapped into the memory. The choices: 15M-16 M, Disabled. P2C/C2P Concurrency This item allows yo to enable/disable the PCI to CPU, CPU to PCI concurrency.
  • Page 62 AGP Aperture Size Select the size of Accelerated Graphics Port (AGP) aperture. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation.
  • Page 63 CPU to PCI Write Buffer When this field is enabled, writes from the CPU to the PCI bus are buffered, to compensate for the speed differences between the CPU and PCI bus. When, disabled, the writes are not buffered and the CPU must wait until the write is complete before starting another write cycle.
  • Page 64 AGP Master 1 WS Write System will run single wait state delay before write data from buffer, if user set to disable system will run twice wait states system can stable. The choices: Enabled, Disabled. AGP Master 1 WS Read System will run single wait state delay before read data from buffer, if user set to disable system will run twice wait states so system can stable.

  • Page 65: Integrated Peripherals

    Integrated Peripherals On-Chip IDE Channel 0 The system chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled to activate the primary and/or secondary IDE interface. Select Disabled to deactivate this interface, if you install a primary and/or secondary add-in IDE interface.
  • Page 66 Primary/Secondary Master/Slave PIO The four IDE PIO (Programmable Input/Output) fields let you set a PIO mode (0-1) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device.
  • Page 67 Onboard FDD Controller Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install an add-in FDC or the system has no floppy drive, select Disabled in this field.The choices: Enabled, Disabled.
  • Page 68 HPSIR IrDA-compliant serial infrared port ASK IR Amplitude shift keyed infrared port IR Function Duplex Select the value required by the IR device connected to the IR port. Full duplex mode permits simultaneous two direction transmission. Half duplex mode permits transmission in one direction only at a time.
  • Page 69 Parallel Port EPP Type Select EPP port type 1.7 or 1.9.The choices: EPP1.9, EPP1.7. Onboard Legacy Audio Onboard Legacy Audio can be set as enabled or disabled. Howev- er disabling the Legacy Audio will render the functions listed below useless.The choices: Enabled, Disabled. Sound Blaster The on board Sound Blaster can be configured as enable or disable.The choices: Enabled, Disabled.

  • Page 70: Power Management Setup

    Power Management Setup Power Management This category allows you to select the type ( or degree ) of power saving and is directly related to the following modes: 1. HDD Power Down 2. Doze Mode 3. Suspend Mode Maximum Saving 1.
  • Page 71 Minimum Saving 1. HDD - 1~15 minutes or Disable 2. Doze Mode - 1 Hour 3. Suspend Mode - 1 Hour User Define 1. HDD - 1~15 minutes or Disable 2. Doze Mode - 1 min, 2 min, 4 min, 6 min, 8 min, 10 min, 20 min, 30 min, 40 min, 1 hour.
  • Page 72 Video Off Method This determines the manner in which the monitor is blanked. s i h i t c l l i i t r z i r l a t i t a s t r e t i r e f s i h i t p...

  • Page 73: Pnp/Pci Configurations

    PnP/PCI Configurations PNP OS Installed Select Yes if the system operating environment is Plug and Play aware, for example Windows 95. Select No if you need the BIOS to configure non-boot devices. The choices: No, Yes. Reset Configuration Data Normally, you leave this field disabled. Select enabled to reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not...
  • Page 74 Resources Controlled By The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows ® 95. If you set this field to “manual”...

  • Page 75: Pc Health Status

    PC Health Status PC Health Status Your system does not allow you to alter any of the setting in this menu. The system engineer has already designated the correct setting for Gene-6310. Frequency/Voltage Control Auto Detect DIMM/PCI CLK This item allows you to enable/disable auto detect DIMM/PCI clock.

  • Page 76: Load Fail-Safe Defaults

    Load Fail-Safe Defaults Load Fail-Safe Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Default (Y/N)? Pressing "Y" loads the BIOS default values for the most stable, minimal performance system operations. Chapter 3 Award BIOS Setup...

  • Page 77: Load Optimized Defaults

    Load Optimized Default Load Optimized Default When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N)? Pressing "Y" loads the default values that are factory settings for optimal performance system operations. GENE-6310 User Manual...

  • Page 78: Set Supervisor Password

    Set Supervisor Password When you select this function, a message appears at the center of the screen: ENTER PASSWORD: Type the password, up to eight characters, and press Enter. Typing a password clears any previously entered password from CMOS memory. Now the message changes: CONFIRM PASSWORD: Again, type the password and press Enter.

  • Page 79: Set User Password

    Set User Password When you select this function, a message appears at the center of the screen: ENTER PASSWORD: Type the password, up to eight characters, and press Enter. Typing a password clears any previously entered password from CMOS memory. Now the message changes: CONFIRM PASSWORD: Again, type the password and press Enter.

  • Page 80: Save To Cmos And Exit

    Save to CMOS and EXIT Save to CMOS and EXIT Pressing <Enter> on this item asks for confirmation: Save to CMOS and Exit (Y/N)? Pressing "Y" stores the selections made in the menus in CMOS, a special section of memory that stays on after you turn your system off.

  • Page 81: Exit Without Saving

    Exit without Saving Exit Without Saving Pressing <Enter> on this item asks for confirmation: Quit Without Saving (Y/N)? This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer.

  • Page 82: Chapter 4: Drivers Installation

    Drivers Installation This Gene-6310 is equipped with an audio, VGA and LAN interface. This chapter provides instructions for installing the software drivers on these peripherals. Chapter 4 Driver Installation...

  • Page 83: System Driver Installation For Windows Os

    System Driver Installation for Windows OS The system driver installation procedure must be performed first. * 1. Insert the Gene-6310 CD Diskette into the CD ROM Drive. 2. Select the Drivers/system file to click the Setup icon. A driver installation box will appear, 3.
  • Page 84 4.Click Yes. 5. Select Normally Install, and then click Next Chapter 4 Driver Installation...
  • Page 85 6. Remain the default setting, and then click Next. 7. Still click Next. Gene-6310 User Manual...
  • Page 86 8. As the following picture, click Next. 9. Select Install VIA AGP VxD in Turbo Mode, and click Next. Chapter 4 Driver Installation...
  • Page 87 10. Click Next. 11.Click Finish. Installation process is complete and allows the system to reboot. Gene-6310 User Manual...

  • Page 88: Audio Driver Installation For Windows Os

    Audio Driver Installation 1. Insert the Gene-6310 CD Diskette into the CD ROM Drive. 2. Select the Drivers/audio/ac97 file to click the Setup icon. A driver installation box will appear, 3. Click Next. Chapter 4 Driver Installation...
  • Page 89 4. Select Install Driver, and then click Next. 5. Click Finish. Installation process is complete and allows the system to reboot. Gene-6310 User Manual...

  • Page 90: Vga Driver Installation For Windows Os

    VGA Driver Installation 1. Insert the Gene-6310 CD Diskette into the CD ROM Drive. 2. Select the Drivers/vga/9x file to click on the set up icon. Notice:We take the VGA installation under Windows 98 for example here, please choose the file depending on your Windows OS. Chapter 4 Driver Installation...
  • Page 91 A driver installation screen will appear, please follow the onscreen instructions to install the driver in sequence. 3. At last, click Finish. Installation process is complete and allows the system to reboot. Gene-6310 User Manual...

  • Page 92: Ethernet Driver Installation For Windows Os

    Ethernet Driver Installation 1. Insert the Gene-6310 CD Diskette into the CD ROM Drive. 2. Click the Start button. 3. Select the Settings item. 4. Click the Control Panel item. 5. Select the Systems icon to open the System Properties box. 6.
  • Page 93 Another file will appear below this file,and then click on the file, 8. Click the Driver Tab. 9. Click the Update Driver Button. The Update Device Driver Wizard will appear, 10. Click Next. Gene-6310 User Manual...
  • Page 94 11. Select CD ROM drive, D/Drivers/lan/Win98, and click Next. Notice:We take the LAN installation under Windows 98 for example here, please choose the file depending on your Windows OS. 12. Click Next. Chapter 4 Driver Installation...
  • Page 95 13. Click Finish. Installation process is complete shutdown the computer and will allow the system to reboot Gene-6310 User Manual...

  • Page 96: Appendix A:watchdog Timer

    Programming the Watchdog Timer The mainboard is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial stand-alone and unmanned environments. Appendix A Programming the Watchdog Timer...
  • Page 97 Programming the watchdog timer An on-board watchdog timer reduces the chance of disruptions which CPLD (compact programmable logical device) interference can cause. This is an invaluable protective device for standalone or unmanned applications. When the watchdog timer activates(CPU processing has come to a halt), it can reset the system, or generate an interrupt on IRQ10, IRQ11, IRQ15, and NMI.
  • Page 98 The following procedure is a sample program for the watchdog timer: • Type C:\DOS\Debug <ENTER> • To start watchdog timer and set function "Reset" type; o 444 0 <Enter>; out 444h data 0 • To input Watchdog timers time-out interval of 5 seconds type; o 443 05 <Enter>;...
