Assembly Instructions
& User's Manual
5 BURNER ISLAND GRILL AND KAMADO
ITEM # 155530
MODEL NO.: SRGG51607
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Adult assembly required.
Keep screws and parts out of reach of children.
Customer Service: (866) 814-0585, 8:00am to 8:00pm,
Monday thru Friday Eastern Standard Time
--------------------------------------OR-------------------------------------
Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily)
Live Chat at: www.academy.com
Email: customerservice@academy.com
(Made in China)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Outdoor Gourmet SRGG51607
Summary of Contents for Outdoor Gourmet SRGG51607
- Page 1 Assembly Instructions & User’s Manual 5 BURNER ISLAND GRILL AND KAMADO ITEM # 155530 MODEL NO.: SRGG51607 Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required.
- Page 2 SAFETY WARNINGS DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid. 4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. WARNING 1.
-
Page 3: Table Of Contents
TABLE OF CONTENTS ........ - Page 4 SAFETY WARNINGS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS DO NOT LEAVE THE GRILL UNATTENDED WHILE WARNING COOKING. Do no t t ry light in g t his appli a n ce wit hout f ir s t reading “LIGHTING INST RUCTIONS” section of this manual.
- Page 5 SAFETY WARNINGS TESTED ACCORDANCE WITH ANSI Never let clothing, pot holders or other flammable Z21.58-2015 / CSA 1.6-2015 STANDARD FOR materials come in contact with or too close to any OUTDOOR COOKING APPLIANCES. grate, burner or hot surface until it has cooled. Fabric may ignite and result in personal injury.
- Page 6 SAFETY WARNINGS Clean the grill with caution. Avoid steam burns; do NEVER USE A DENTED OR RUSTY PROPANE not use a wet sponge or cloth to clean the grill while CYLINDER. it is hot. Some cleaners produce noxious fumes or All electrical accessories (such as rotisserie) must be can ignite if applied to a hot surface.
-
Page 7: Placement Of The Grill
PLACEMENT OF THE GRILL MINIMUM CLEARANCE: LOCATION 2’ Clearance from both sides of combustible When determining a suitable location take into material, and 3’ Clearance from the back. account concerns such as exposure to wind, proximity to traffic paths and keeping any gas supply back 3’... -
Page 8: Exploded View
EXPLODED VIEW Please check the contents of the packaging to ensure all parts are included. If missing parts please contact customer service. -
Page 9: P R A S T L S I . T
PARTS LIST Description Picture Part # Warming Rack Cooking Grate Heat Diffuser Grill Body Assembly (pre-assembly) Side Burner Rack Side Burner Cover Side Burner Assembly (pre-assembly) Right Side Shelf Assembly Utensil Rack Assembly Pulse Igniter (pre-assembly) Pulse Igniter Cover Plate Cylinder Holder (pre-assembly) Kamado Grill（pre-assembly) Trash Can Holder（pre-assembly) -
Page 10: Hardware
TOOLS REQUIRED Phillips Head Screwdriver (Not included) Adjustable Wrench (Not included) HARDWARE Hardware # Description Picture M6x30 Philips Head Bolt M6x14 Philips Head Bolt M4x10 Philips Head Bolt M5x10 Hexagon Bolt 6MM Washer... -
Page 11: Assembly Instructions
ASSEMBLY INSTRUCTIONS Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. STEP 1 Fig.1 Attach chimney cap (20) to kamado grill (13) and press down from the top as shown in Fig.1. - Page 12 ASSEMBLY INSTRUCTIONS STEP 2 Fig.2 Folding Mechanism Lever Press down the front and back folding mechanisms levers on left side table (17) with two hands to unfold two folding mechanisms until folding mechanisms lock into place (you will hear two click sounds) as shown in Fig.2. WARNING: Be careful when unfolding the left Folding Mechanism...
- Page 13 ASSEMBLY INSTRUCTIONS STEP 4 Fig.4 Attach utensil rack assembly (9) to the right side shelf assembly (8) with 2 pcs M5x10 hexagon bolts (DD) and 2 pcs 6MM washers (EE) as shown in Fig. 4. Hardware Used M5x10 Hexagon 2 pcs Bolt 6MM Washer 2 pcs...
- Page 14 ASSEMBLY INSTRUCTIONS STEP 6 Fig.6 Unscrew the nut on the nozzle as shown in Fig.6. Make nozzle through the hole on the nozzle fixing plate, and attach the nozzle to the nozzle fixing plate with nut as shown in Fig.6. Nozzle Fixing Plate Nozzle...
- Page 15 ASSEMBLY INSTRUCTIONS STEP 7 Fig.7 Attach the side burner assembly (7) to the side burner bowl with 2 pcs M4x10 philips head bolts (CC) as shown in Fig.7. When assembling the side burner assembly (7), make sure the nozzle is inserted into the venturi tube of the side burner assembly (7).
- Page 16 ASSEMBLY INSTRUCTIONS Fig.9 STEP 9 Place side burner rack (5) into the side burner bowl of right side shelf assembly (8) as shown in Fig. 9. Place one warming rack (1), three cooking grates (2) and five heat diffusers (3) onto the corresponding positions of grill body assembly (4) as shown in Fig.
- Page 17 ASSEMBLY INSTRUCTIONS STEP 11 Fig.11 Foldable left side table operation 1. To raise left side table (17), lift left table up with two hands until folding mechanisms lock into place while you will hear two click sounds as shown in Fig.11. 2.
- Page 18 ASSEMBLY INSTRUCTIONS STEP 13 Fig.13 Turn and open the pulse igniter cap. Insert one AA-1.5V battery (not included) into the pulse igniter (10). Make sure the (+) end is facing you. Screw back on the pulse igniter cap as shown in Fig.13.
-
Page 19: Gas Cylinder Installation Instructions
GAS CYLINDER INSTALLATION INSTRUCTIONS STEP 1 Place gas cylinder (not included) on the cylinder holder (12), and fix the gas cylinder with the bolt on cylinder holder. STEP 2 1) Check to ensure that the valve of gas cylinder is securely turned off prior to making the connection. If not, turn the valve clockwise to turn it off. -
Page 20: Gas Hook-Up
GAS HOOK-UP Only the pressure regulator and hose assembly supplied Main Manifold operating pressure: 11” water column (W.C.) with the grill must be used. Any replacement pressure regulator and hose assembly must be specified by the P Gas Cylinder must be fitted with Overfill Prevention grill manufacturer. -
Page 21: Gas Safety
GAS SAFETY QCC-1 QUICK CLOSING COUPLING To disconnect LP gas cylinder: This appliance is designed to be used with an LP gas cylinder equipped with the QCC-1 Type 1 Quick Closing 1. Turn the burner valves off. Coupling system which incorporates new safety features 2. -
Page 22: Leak Testing
LEAK TESTING GAS FLOW CHECK GENERAL Each grill burner is tested and adjusted at the factory prior Although all gas connections on the grill are leak to shipment; however, variations in the local gas supply tested at the factory prior to shipment, a complete gas may make it necessary to adjust the burners, the flames tightness check must be performed at the installation site due to possible mishandling in shipment, or... -
Page 23: Installer Final Check
INSTALLER FINAL CHECK OPERATING INSTRUCTIONS Specified clearance maintained 2 feet from USING THE GRILL sides of combustibles, and 3 feet from the back. Grilling requires high heat for searing and proper All internal packaging removed. browning. Most foods are cooked at the “MAX” heat Knobs turn freely. - Page 24 OPERATING INSTRUCTIONS PLACE THE GRILL OUTDOORS ON A HARD, LEVEL, NON-COMBUSTIBLE SURFACE AWAY FROM ROOF, OVERHANG OR ANY COMBUSTIBLE MATERIAL. NEVER USE ON WOODEN OR OTHER SURFACES THAT COULD BURN. PLACE THE GRILL AWAY FROM OPEN WINDOWS OR DOORS TO PREVENT SMOKE FROM ENTERING YOUR HOUSE.
- Page 25 OPERATING INSTRUCTIONS SMOKE COOKING TIPS GRILLING Step 1 Step 2 WARNING: WARNING: Step 3 WARNING: Step 4 WARNING: Step 5 Always use a meat thermometer to ensure food is fully cooked before removing from grill. Step 6...
- Page 26 OPERATING INSTRUCTIONS FLAVORING WOOD REGULATING HEAT ADDING CHARCOAL/WOOD DURING COOKING Step 1 Step 2 Step 3 Step 4 Step 5...
-
Page 27: Lighting Instructions
LIGHTING INSTRUCTIONS FLAME CHARACTERISTICS WARNING: IMPORTANT! ck for proper burner flame characteristics. Each BEFORE LIGHTING… burner is adjusted prior to shipment; however, variations Inspect the gas supply hose prior to turning the gas in the local gas supply may take minor adjustments. “ON”. - Page 28 LIGHTING INSTRUCTIONS Keep a spray bottle of soapy water near the gas supply valve and check the connections before each use. Do not attempt to light the grill if odor of gas is present. Call for customer service (888)-922-2336.
-
Page 29: Using The Side Burner
USING THE SIDE BURNER WARNING: IMPORTANT! MATCH LIGHTING THE SIDE BURNER 1. Open the lid to the side burner before lighting. 2. Turn the burner control knob to "OFF". USING THE SIDE BURNER 3. Strike and carefully place a match approximately 1/2" Inspect the gas supply hose prior to turning the gas (1 to 2 cm) from the burner. -
Page 30: Grilling Guide
GRILLING GUIDE Outdoor grilling is really quite simple. You'll succeed with DIRECT COOKING burgers, dogs, or steaks usually on your very first try. With experience, you will learn how to work with your Direct cooking involves grilling your meat directly over grill, creating more imaginative meals all the time. -
Page 31: Care & Maintenance
CARE & MAINTENANCE BURNERS CAUTION: Ensure the gas supply is off and the knobs are in the All cleaning and maintenance should be done when grill “OFF” position. Make sure the grill is cool. Clean the is cool and with the gas supply turned off at the propane exterior of the burner with a wire brass brush. -
Page 32: Cleaning Burners
CLEANING BURNERS (not included). not provided... -
Page 33: How To Replace Main Burner
HOW TO REPLACE MAIN BURNER Ignition hole (upwards) M5x10 Bolt Nozzle Step 1 Place the main burner onto main grill body assembly (4) and make sure the ignition hole face upward and nozzle insert into the main burner tube. Step 2 Fix one main burner to the main grill body assembly (4) with (1) M5x10 bolt. -
Page 34: Trouble Shooting
TROUBLE SHOOTING BEFORE CALLING FOR SERVICE If the grill does not function properly, use the following checklist before contacting your dealer for service. You may save the cost of a service call. PROBLEM SOLUTION When I light the grill, it does -- Make sure you have turned on the gas. -
Page 35: Limited Warranty
ONE-YEAR LIMITED WARRANTY Academy, Ltd. warrants your gas grill to be free from manufacturer’s defects in workmanship or material under normal operating conditions for one (1) year from the original date of purchase. This warranty applies if the item is available to the original purchaser only. This warranty applies only to products sold at retail.
