Grill Guide For Model BQ05037-2 LP Gas Barbecue Grill FOR YOUR SAFETY: 1. Read this Grill Guide before attempting to assemble or operate your grill. 2. Follow all safety instructions. 3. Check for leaks according to directions in this Grill Guide before operating your grill, even if purchasing an assembled grill.
Safety Precautions Always read and follow all DANGER, WARNING, AND FOR YOUR SAFETY notices in this Grill Guide. Failure to do may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. 1.
Assembly Instructions...…………………………………………………………..…..5-22 General Information and Operation………………..………………………………..23-34 Trouble Shooting Guide………………………………………………....…34-35 Frequently Asked Questions……………………………...…………………………35-36 Write down here and keep for future BQ05037-2 reference Date of Purchase: _________________ Sell Inc. Serial Number: ___________________ The serial number may be found on the placard located on...
Customer Support Center Thanks for purchasing an Outdoor Gourmet™ Grill. We’re here to help you maximize your enjoyment and appreciation of your new grill. Please don’t hesitate to contact us should you have any questions regarding assembly, performance, warranty, or accessories.
7.) Do not use a Power Screwdriver for assembly as you could strip the threads on the Nuts and Bolts. 8.) The propane tank for this grill is sold separately. See the LP Gas and Cylinder Information later in this guide. BQ05037-2 WARNING Failure to follow all Danger,...
Page 6
BQ05037-2 Detail Parts List 1. Thermometer 43. Regulator and Hose 2. Stainless Steel Hood 44. Control Panel Top Bar 3. Name Plate 45. Control Panel 4. Lid Axis Bolt 46. Control Knob Seat 5. Lid Axis Washer 47. Electric Igniter 6.
Parts List Fire Box Assembly---1PC Side Burner Assembly---1PC Side Burner Front Panel---1PC Side Burner Front Bracket---1PC Side Handle---2PCS Side Shelf Assembly---1PC Side Shelf Front Panel---1PC Side Shelf Front Bracket---1PC Towel Rack---1PC Cooking GRATE (12")---1PC Cooking GRATE (10")---2PCS Heat Diffuser---3PCS Rotisserie Motor---1PC Rotisserie Assembly---1PC Stamped Wcnming Rack---1PC Hardware List...
Page 9
Step 1 : Unscrew out A+C (x2). Attach Side Burner Front Bracket and Side Handle to the Side Burner Assembly, and drill to fix. FIG 1-1 FIG 1-2 Step 2 : Drill A+ C (x2) to Firebox Assembly and keep pitches at 1/4". FIG 2-1 FIG 2-2...
Page 10
Step 3 : Place Side Burner Assembly on the pitchesleft,thru "8" shape hole. FIG 3-1 FIG 3-2 Step 4: Remove the Phillips Head Bolt and Washer from the lower side corner of the left side of Control Panel (Fig 4-1) and hold for Step 7. FIG 4-1...
Page 11
Step 5: Drill B (x2) thru panel to fix Side Burner Valve Assembly to Side Burner Front Panel and then place the Side Burner Front Panel on the Side Burner Assembly. FIG 5-1 FIG 5-2 Step 6: Drill A+C (x3) thru Side Burner Front Bracket to fix Side Burner Front Panel. FIG 6-2 FIG 6-1 FIG 6-3...
Page 12
Step 7: Then drill the Phillips Head Bolt that was removed from the lower side corner of the left side of Control Panel in Step 2 back into its hole and tighten. FIG 7-1 Step 8: Drill A+C thru Side Burner Rear Bracket to fix Side Burner Assembly. FIG 8-1...
Page 13
Step 9: Place Control knob (D) on Knob Seat. FIG 9-1 Step 10: Unscrew out A+C (x2). Attach Side Shelf Front Bracket and Side Handle to the Side Shelf Assembly, and drill to fix. FIG 10-1 FIG 10-2...
Page 14
Step11: Drill A+C (x2) to Firebox Assembly and keep pitches at 1/4". FIG 11-2 FIG 11-1 Step12: Place Side Shelf Assembly on the pitches left, thru "8" shape hole. FIG 12-1 FIG 12-2...
Page 15
Step13: Remove the Phillips Head Bolt from the lower side of the right side of Control Panel (FIG 13-1) and hold for Step 16. FIG 13-1 Step14: Unscrew out A+C (x2). Place the Side Shelf Front Panel on the Side Shelf Assembly, and drill to fix.
Page 16
Step15: Drill A+C (x3) thru Side Shelf Front Bracket to fix Side Shelf Front Panel. FIG 15-2 FIG 15-1 FIG 15-3 Step16: Then drill the Phillips Head Bolt that was removed from the lower side corner of the right side of Control Panel in Step 13 back into its hole and tighten. FIG 16-1...
Page 17
Step17: Drill A+C thru Side Shelf Rear Bracket to fix Side Shelf Assembly. FIG 17-1 Step18: Place Heat Diffusers (09) at appropriate slots. FIG 18-1...
Page 18
Step19: Place Cooking Grates (10,11) on stairs inner Firebox. As suggested place 12" Grate in the middle. Step20: Place the front edge of Stamped Warming Rack (12) at slots on both side walls of Firebox. FIG 20-1...
Page 19
Step21: Slot Rotisserie Motor (13) on Bracket. FIG 21-1 FIG 21-2 Step22: Place Rotisserie Assembly (14) on Fillister at top of left side wall of Firebox first. Then, insert into Motor. FIG 22-1 FIG 22-2...
Page 20
Step23: Turn the LP Cylinder Tray Stopper to the left side, pull out the LP Cylinder Tray and place the tank onto it. Push back the LP Cylinder Tray, unhook the LP Cylinder Support Ring and lower down over the neck of the LP Cylinder. Reattach the hook to secure. Lock the LP Cylinder Tray in place by turning the LP Cylinder Tray Stopper to the right side.
Step25: Insert AA Size Battery (E) within Ignitor. FIG 25-1 Step26: Remove any labels and additional packing material from the grill. Be sure to clean all foam packing material out of all areas. Congratulations! Your grill is now fully assembles. Please proceed and read the General Information and Operation portion of the Grill Guide before attempting to hook up the LP gas cylinder or operating.
General Information and Instructions Your new Outdoor Gourmet™ Grill Island has been designed and manufactured to high quality standards. It will provide you with many years of enjoyment with a minimal amount of maintenance. Please keep in mind the following FOR YOUR SAFETY.
Page 24
LP CYLINDER FILLING AND EXCHANGE Some areas only allow you to exchange your empty cylinder for a replacement that is already full. Other areas allow you to refill your cylinder. If you are in an area where you can refill your cylinder: 1.
TRANSPORTATION AND STORAGE 1. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder of Propane Valve. Other types of caps or plugs may result in leakage.
Page 26
The regulator must enter the cylinder valve in a straight line. Center this nipple of the regulator into the cylinder valve. WARNING Q.C.C.1 Type 1 Connector Always keep the gas cylinder in the upright position all the time WARNING 1. Do not connect this grill to any unregulated sources of propane. 2.
Grill Placement ! FOR YOUR SAFETY! 1. Minimum clearance required from sides and back of unit to adjacent combustible construction is 24 inches (61 cm). 2. Do not locate or use this outdoor cooking gas appliance under overhead combustible surfaces. Keep any electrical supply cord and the fuel supply hose away from any heated surfaces and water.
Page 28
MANUALLY LIGHTING THE MAIN BURNERS WITH THE MATCH HOLDER 1. Open the lid. 2. Ensure all burners are in the “Off” position. 3. Slowly turn on the gas at the LP cylinder valve if it is not already on. 4. Place a match in the Match Holder. This is located in the top center drawer of the grill cabinet underneath the right main burner.
Page 29
Cleaning and Maintaining Your Grill WARNING 1. Do not clean any part of your barbecue grill in a self-cleaning oven. 2. Do not use oven cleaners, abrasive kitchen cleaners, cleaners that contain citrus products, or mineral spirits. 3. Do not use any type of steel bristled brush. 4.
Page 30
alternative way to clean the inside of the burner is using compressed air. Always wear eye protection if using this method. Never enlarge the burner ports during cleaning. 6. Brush the outer surface of the burner. 7. Ensure all ports (holes) are free of all debris 8.
GRILL STORAGE 1. Clean your grill before storage. 2. Storage of a gas grill indoors is permissible only if the cylinder is disconnected and removed from the gas grill. 3. Cover the grill. 4. Perform a Leak Test before use after storage. Grilling With Your New Grill Welcome to the world of grilling.
Page 32
ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three-prong grounded plug for your protection. It should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. WARNING 1. Do not operate your Rotisserie Motor in the rain, or expose it to moisture. Store it in a dry place when not in use.
Page 33
USING THE SMOKER DRAWER Smoking gives food a distinctive, delicious flavor. You will find a variety of wood chips or pellets available for use in smoking grilled foods. Start your grill and allow it to reach the desired cooking temperature for the food you are grilling.
14. Use insulated protective mitts or potholders when working around a grill in operation. 15. Use a small amount of cooking oil on the cooking grates before heating to reduce foods sticking on the grates. FOOD SAFETY 1. Always use safe food handling and preparation when using this grill. 2.
a. A ruptured gas hose. Inspect, perform a leak test, and replace as necessary. b. Opening the control knobs before turning on the LP gas at the cylinder. Turn on the gas at the LP cylinder first before turning on a control knob to light. c.
Page 36
disconnect from the regulator. Let it stand for 10 minutes. Reconnect the regulator to the LP tank. Open the grill lid. Slowly open the LP tank valve. Follow the burner lighting procedures and light the burner furthest from the LP tank. Continue to light the other burners as you move towards the LP tank. Can I use ceramic plates, briquettes of any kind, or lava rocks? No.
