Assembly Instructions & User's Manual
5 Burner Island Grill
Item# 162109
Model# SRGG51608-19
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Adult assembly required.
Keep screws and parts out of reach of children.
Customer Service: (888) 909-3888, 7:30 am to 4:30 pm PST
Monday - Friday
--------------------------------------OR-------------------------------------
Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily)
Live Chat at: www.academy.com
Email: customerservice@academy.com
(Made in China)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRGG51608-19 and is the answer not in the manual?

Questions and answers

Summary of Contents for Outdoor Gourmet SRGG51608-19

  • Page 1 Joe Oakes 9/23/20 (update to cover - hours) Assembly Instructions & User’s Manual 5 Burner Island Grill Item# 162109 Model# SRGG51608-19 Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT.
  • Page 2 SAFETY WARNING RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS DO NOT USE ALUMINUM FOIL TO LINE THE GRILL RACKS OR GRILL BOTTOM. This can severely upset combustion airflow or trap excessive heat in the control area. WARNING Do not try lighting this appliance without first reading GAS INSTALLATION CODES the “LIGHTING INSTRUCTIONS”...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Safety Warning ............................2,4-5 Placement of the Grill………......................…………...6 Exploded View……............................… Parts List ..…...…………………......................…………… Tools Required & Hardware ……......................………..Assembly Instructions…..........................10-11 Gas Cylinder Installation Instructions...…......................Gas Hook-Up…............................…… Gas Safety............................... Leak Testing………........................…………… Installer Final Check ……..........................… Operating Instructions…..........................Lighting Instructions….........................……...
  • Page 4: Safety Warning

    SAFETY WARNING TESTED ACCORDANCE WITH ANSI CHILDREN SHOULD NOT BE LEFT ALONE OR Z21.58-2018 / CSA 1.6-2018 STANDARD FOR UNATTENDED IN AN AREA WHERE THE GRILL IS OUTDOOR COOKING APPLIANCES. BEING USED. NEVER ALLOW THEM TO SIT, STAND OR PLAY ON OR AROUND THE GRILL AT ANY TIME. WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and carbon...
  • Page 5 SAFETY WARNING Keeping outdoor cooking gas appliance area clear and When using the grill, do not touch the grill rack, free from combustible materials, gasoline and other flam- burner grate or immediate surroundings as these mable vapors and liquids. areas become extremely hot and could cause burns.
  • Page 6: Placement Of The Grill

    PLACEMENT OF THE GRILL MINIMUM CLEARANCE: LOCATION 2 feet Clearance from both sides of combustible When determining a suitable location take into material, and 3 feet Clearance from the back. account concerns such as exposure to wind, proximity to traffic paths and keeping any gas supply back 3’...
  • Page 7: Exploded View

    EXPLODED VIEW Please check the contents of the packaging to ensure all parts are included. If missing parts please contact customer service.
  • Page 8: Parts List

    PART LIST Part # Description Picture Part # Description Picture Warming Rack Non-locking Caster (pre-assembly) Cooking Grate Right Door Assembly Heat Diffuser (pre-assembly) Left Door Assembly Grill Body (pre-assembly) Assembly (pre-assembly) Rear Panel (pre-assembly) Control Knob Bezel Cabinet Decorative (pre-assembly) Board (pre-assembly) Control Knob...
  • Page 9: Tools Required & Hardware

    TOOLS REQUIRED Adjustable Wrench (Not included) HARDWARE Hardware # Description Picture M6 x 40 Hexagon Bolt (pre-assembly) D6 Washer (pre-assembly)
  • Page 10: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. STEP 1 Fig. 1 Unscrew 2 pcs M6x40 hexagon bolts (AA) and 2 pcs D6 washers (BB) on left cabinet of grill.
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 3 Fig. 3 Open the lid and place one warming rack (#1), three cooking grates (#2) and five heat diffusers (#3) onto the corresponding positions of grill body assembly (#4) as Fig. 3.
  • Page 12: Gas Cylinder Installation Instructions

    GAS CYLINDER INSTALLATION INSTRUCTIONS STEP 1 Place gas cylinder (not included) into the hole at cart bottom panel. Screw cylinder locking bolt (#12) to the cart bottom panel from behind until the cylinder locking bolt touch the bottom rim of gas cylinder. WARNING: It is prohibited to store another cylinder in the cabinet after placing a cylinder into the hole at cart bottom panel.
  • Page 13: Gas Hook-Up

    GAS HOOK-UP Only the pressure regulator and hose assembly supplied Main Manifold operating pressure: 11” water column (W.C.) /2.74kPa. with the grill must be used. Any replacement pressure regulator and hose assembly must be specified by the P Gas Cylinder must be fitted with Overfill Prevention grill manufacturer.
  • Page 14: Gas Safety

    GAS SAFETY QCC-1 QUICK CLOSING COUPLING To disconnect LP gas cylinder: This appliance is designed to be used with an LP gas 1. Turn the burner valves off. cylinder equipped with the QCC-1 Type 1 Quick Closing 2. Turn the cylinder valve off fully (turn clockwise to stop). Coupling system which incorporates new safety features required by the American National Standard Institute Detach the regulator assembly from the cylinder valve...
  • Page 15: Leak Testing

    LEAK TESTING GAS FLOW CHECK GENERAL Each grill burner is tested and adjusted at the factory prior Although all gas connections on the grill are leak to shipment; however, variations in the local gas supply tested at the factory prior to shipment, a complete gas may make it necessary to adjust the burners, the flames tightness check must be performed at the installation of the burners should be visually checked.
  • Page 16: Installer Final Check

    INSTALLER FINAL CHECK OPERATING INSTRUCTIONS Specified clearance maintained 2 feet from USING THE GRILL sides of combustibles, and 3 feet from the back. Grilling requires high heat for searing and proper All internal packaging removed. browning. Most foods are cooked at the “MAX” heat Knobs turn freely.
  • Page 17: Lighting Instructions

    LIGHTING INSTRUCTIONS FLAME CHARACTERISTICS WARNING: IMPORTANT! ck for proper burner flame characteristics. Each BEFORE LIGHTING… burner is adjusted prior to shipment; however, variations Inspect the gas supply hose prior to turning the gas in the local gas supply may take minor adjustments. “ON”.
  • Page 18 LIGHTING INSTRUCTIONS Keep a spray bottle of soapy water near the gas supply valve and check the connections before each use. Do not attempt to light the grill if odor of gas is present. Call for customer service.
  • Page 19: Grilling Guide

    GRILLING GUIDE Outdoor grilling is really quite simple. You'll succeed with DIRECT COOKING burgers, dogs, or steaks usually on your very first try. With experience, you will learn how to work with your Direct cooking involves grilling your meat directly over grill, creating more imaginative meals all the time.
  • Page 20: Care & Maintenance

    CARE & MAINTENANCE BURNERS CAUTION: Ensure the gas supply is off and the knobs are in the All cleaning and maintenance should be done when grill “OFF” position. Make sure the grill is cool. Clean the is cool and with the gas supply turned off at the propane exterior of the burner with a wire brass brush.
  • Page 21: Cleaning Burners

    CLEANING BURNERS (not included) (not provided)
  • Page 22: How To Replace Main Burner

    HOW TO REPLACE MAIN BURNER Ignition hole (upwards) M4X10 screw Line up burner and nozzle M4 nut Step 1 Place the main burner onto grill body assembly and cart assembly and make sure the ignition hole face upward and nozzle insert into the main burner tube. Step 2 Fix one main burner to the grill body and cart assembly with one M4X10 screw and one M4 nut.
  • Page 23: Trouble Shooting

    TROUBLE SHOOTING BEFORE CALLING FOR SERVICE If the grill does not function properly, use the following checklist before contacting your dealer for service. You may save the cost of a service call. PROBLEM SOLUTION When I light the grill, it does -- Make sure you have turned on the gas.
  • Page 24: Warranty Information

    WARRANTY INFORMATION The appliance has been manufactured under the highest standard of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
