Assembly Instructions
& User's Manual
Triton Classic Gas & Charcoal Grill
Model #: FSOGBG3005
Please keep this instruction manual for future reference
Customer Service: (888) 922-2336, 7:00 am to 12:00 am daily CST
Live Chat on Academy Website (www.academy.com) 24/7 or email
customerservice@academy.com
(Made in China)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Outdoor Gourmet FSOGBG3005
Summary of Contents for Outdoor Gourmet FSOGBG3005
-
Page 1: Assembly Instructions
Assembly Instructions & User’s Manual Triton Classic Gas & Charcoal Grill Model #: FSOGBG3005 Please keep this instruction manual for future reference Customer Service: (888) 922-2336, 7:00 am to 12:00 am daily CST Live Chat on Academy Website (www.academy.com) 24/7 or email customerservice@academy.com... -
Page 2: Table Of Contents
Table of Contents Warnings…………………………………………………………………..3-7 Tools and Parts…………………………………………………...………8-9 Exploded View…………………………………………………………..10 Hardware…………………………………………………………………...11 Assembly Instructions………………………………………….……..12-23 Operating Instructions……………………………………………..24-27 Trouble Shooting……………………………………………………..…...27 Care and Maintenance…………………………………………..…...28-29 Frequently asked questions……………………………………...…..….30 Warranty Information………………………………………....31 Page 2 of 31... - Page 3 Page 3 of 31...
-
Page 4: Warnings
Warnings Page 4 of 25... - Page 5 Warnings Page 5 of 31...
- Page 6 Warnings Page 6 of 31...
-
Page 7: Warnings
Warnings Page 7 of 31... -
Page 8: Tools And Parts
Tools Required Adjustable wrench （not included） Screwdriver （not included） Page 8 of 31... - Page 9 Parts List Page 9 of 31...
-
Page 10: Exploded View
Exploded View Page 10 of 31... -
Page 11: Hardware
Hardware Page 11 of 31... -
Page 12: Assembly Instructions
Assembly Instructions Step 1: Assemble the bottom shelf (1) to the left leg (2) and right leg (3) using BOLT M6X50 (DD)- 4PCS Step 2: Assemble the long fence rails (4) to both legs using BOLT M6X12 (AA)- 8PCS. Page 12 of 31... - Page 13 Assembly Instructions Step 3: Assemble the threaded casters (5)-4PCS to legs by twisting clockwise until tight. Turn over the bottom assembly when completed and lock all casters to prevent from moving. Step 4: Align and place body (6) on top of the legs.Using BOLT M6X12 (AA)- 10 PCS,attach triangular bracket left (8) and right (7) to back of body and...
- Page 14 Assembly Instructions Step 5: Screw in BOLT M6X12 (AA)- 2 PCS halfway on the upper corner of side burner body (9) as shown IMAGE 1..Slide the two screws into the opening as shown IMAGE 2 to hold the side burner body in position. Using BOLT M6X12 (AA)- 4PCS,fasten the side burner body in place and tighten all...
- Page 15 Assembly Instructions Step 7: Assemble the side burner (12) by sliding it into the top of the side burner body. Secure burner to body using BOLT M4X8 (FF)-2PCS. Affix the terminal to gas controller .Refer to IMAGE 4. Step 8: Place Side burner grate (13) into side burner.
- Page 16 Assembly Instructions Step 9: Assemble the firebox handle (15) to firebox lid (14) using BOLTM6X15 (BB)-2PCS. Step 10: Screw in BOLT M6X12 (AA)- 2PCS halfway on the firebox (14) as shown IMAGE 5..Slide in the two screw in opening as shown IMAGE 6 to hold the firebox in position.Using BOLT M6X12 (AA)-9PCS, fasten the firbox in...
- Page 17 Assembly Instructions Step 11: Place cooking grate (17)- 1PC and charcoal pan (16)-1PC into firebox. Step 12: Slide drip tray (18) underneath right side of the body.Slide drip pan (37) underneath drip tray (36) as shown IMAGE 7,and slide drip tray (36) underneath left side of the body.
- Page 18 Assembly Instructions Step 13: Assemble Charcoal pan (19) to body (charcoal side) using BOLT M6X12 (AA)-4PCS. Step 14: Assemble Charcoal pan lift rod (20) to long “U” plate on charcoal pan and short “U” plate on body using PIN ROLL (HH)- 2PCS and COTTER PIN (II)- 2PCS.
- Page 19 Assembly Instructions Step 15: Assemble lift knob (21) and air vent handle (22) on body. Step 16: Assemble back panel (23) to back side of gas side using BOLT M6X12 (AA)-3PCS. Page 19 of 31...
- Page 20 Assembly Instructions Step 17: Remove the screws pre- assembled on the thermometers (38). Assemble them to the charcoal lid (24) and gas lid (25)， and secure with the screws as shown IMAGE 9. Assemble lid Hinges (27)-4PCS on gas lid (24) and charcoal lid (25) using BOLT M6X40 (CC)- 8PCS and NUT M6 FLANGE LOCK (EE)-8PCS.
- Page 21 Assembly Instructions Step 19: Assemble the lid handle (29) to charcoal lid using BOLT M6X15 (BB)-2PCS. Attach the charcoal stack on charcoal lid using BOLT M6X12 (AA)-2PCS and NUT M6 FLANGE LOCK (EE)-2PCS. Step 20: Put flame tamers (30)-3PCS to gas side of body.
- Page 22 Assembly Instructions Step 21: Assemble gas tank holder (34) and gas tank hook (35) on left leg using BOLT M6X12 (AA)-4PCS. Place cooking grates (32)-4PCS to body. Assemble "S" hooks (33)-4PCS to control panel on gas side. Page 22 of 31...
- Page 23 FULLY ASSEMBLED Page 23 of 31...
-
Page 24: Operating Instructions
Operating Instructions General Information and Instructions Your new Griddle has been designed and manufactured to high quality standards. It will provide you with many years of enjoyment with a minimal amount of maintenance. Please keep in mind the following FOR YOUR SAFETY. - Page 25 Operating Instructions Page 25 of 31...
- Page 26 Operating Instructions Page 26 of 31...
-
Page 27: Trouble Shooting
Operating Instructions & Trouble shooting Page 27 of 31... -
Page 28: Care And Maintenance
Care and Maintenance Page 28 of 31... -
Page 29: Care And Maintenance
Care and Maintenance Page 29 of 31... -
Page 30: Frequently Asked Questions
Frequently Asked Questions Page 30 of 31... -
Page 31: Warranty Information
Warranty Information This product has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
