- Page 1 User Manual Triton CG Model #: FSOGBG1203 Please keep this instruction manual for future reference Customer Service: (888) 922-2336, 8:00am to 10:00pm,Monday thru Saturday 9:00am to 8:00pm Sunday Central Standard Time (Made in China) Page 1 of 26...
-
Page 2: Table Of Contents
Table of Contents • Warnings • Tools and Parts • Hardware • Assembly Instructions 8-15 • Care and Maintenance 19-28 • Care and Maintenance 16-25 • Warranty Information Page 2 of 26... -
Page 3: Warnings
Warnings Warnings Warnings Warnings FOR YOUR SAFETY: FOR YOUR SAFETY: FOR YOUR SAFETY: FOR YOUR SAFETY: 1.Read this Grill Guide before attempting to assemble or operate your grill. 2.Follow all safety instructions. 3.Check for leaks according to directions in this Grill Guide before operating your grill, even if you purchased this grill assembled. -
Page 4: Safety Precautions
Warnings Warnings Warnings Warnings Safety Precautions Always read and follow all DANGER, WARNING, AND FOR YOUR SAFETY notices in this Grill Guide. Failure to follow these notices may result in property damage, bodily or physical injury, or death. 1. Grill installation must conform with local codes, or in their absence, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. -
Page 5: Tools And Parts
Tools Required Adjustable wrench (not included) Screwdriver (not included) Page 5 of 26... - Page 6 Parts List Back Panel Side Shelf(Left) Page 6 of 26...
-
Page 7: Hardware
Hardware Page 7 of 26... -
Page 8: Assembly Instructions
Assembly Instructions Step 1: Assemble the fence rail(21) to the left and right legs(20) using BOLT M6*50(AA)-4PCS and NUT M6 FLANGE LOCK (DD)- 4PCS. Step 2: Assemble fence rail(21) between legs using BOLT M6X12(BB)-4PCS. Page 8 of 26... - Page 9 Assembly Instructions Step 3: Assemble the threaded casters (22) to legs by twisting clockwise until tight. Turn over the bottom assembly when completed and lock all casters to prevent from moving. Step 4: Align and place body(12) on top of the legs.
- Page 10 Assembly Instructions Step 5: Assemble gas tank holder(24) and gas tank hook(23) on the left leg using BOLT M6X12(BB)-4PCS. Assemble the bottom hinges (13)-4PCS to the back of body using BOLT M6*40 (CC)-8PCS. Step 6: Screw in BOLT M6*12 (BB)-2PCS halfway on the upper corners of the side shelf-L(25) as shown.
- Page 11 Assembly Instructions Step 7: Assemble back panel(8) to back side of gas body using BOLT M6X12(BB)- 3PCS . Step 8: Assemble lid Hinges (4)-2PCS on gas lid (1) using M6*40 (CC)- 4PCS and NUT M6 FLANGE LOCK (DD)- 4PCS. Page 11 of 26...
- Page 12 Assembly Instructions Step 9: Assemble lid Hinges (4) - 2PCS on charcoal lid (2) using M6*40 (CC) -4PCS and NUT M6 FLANGE LOCK (DD) -4PCS. Attach the charcoal stack (3) on charcoal lid using BOLT M6*12 (BB) -2PCS and NUT M6 FLANGE LOCK (DD )- 2PCS .
- Page 13 Assembly Instructions Step 11: Assemble the warming racks(9) -2PCS by inserting the top two ends to lids and bottom side to body. Secure the top part of warming rack with COTTER PIN (FF) - 4PCS. Assemble the hooks(7) to front of right side shelf by twisting counterclockwise until tight.
- Page 14 Assembly Instructions Step 13: Place cooking grates (10)-4PCS into body. Step 14: Slide drip trays (19)- 2pcs underneath each side of the body. Install battery to ignition button by gently removing the cap, placing battery (GG) and putting back the cap. Page 14 of 26...
- Page 15 FULLY ASSEMBLY Page 15 of 26...
-
Page 16: Care And Maintenance
GAS GRILL General Information and Instructions Your new Outdoor Gourmet™ Grill has been designed and manufactured to high quality standards. It will provide you with many years of enjoyment with a minimal amount of maintenance. Please keep in mind the following FOR YOUR SAFETY. - Page 17 WARNING 1. Do not attempt to use a cylinder with any other type of connection device. 2. Do not attempt to use a cylinder with a larger capacity WARNING A frosty cylinder valve indicates possible gas overfill. Close the LP valve and call your dealer immediately.
-
Page 18: Regulator And Lp Cylinder Connections
Regulator and LP Cylinder Connections CAUTION The gas pressure regulator provided with this outdoor cooking appliance must be used. This regulator is set for an outlet pressure of 11 inches water column. Your regulator is equipped with a Q.C.C. Type 1 quick connect system. It will not allow gas to flow until a positive seal has been made. -
Page 19: For Your Safety
LEAK TESTING THE REGULATOR, VALVES, HOSES, AND CONNECTIONS 1. Ensure the LP cylinder valve and all burners are “Off”. 2. Ensure the LP cylinder is connected to the regulator. 3. If the information in the above steps is not followed exactly, a fire causing death or If the information above is not followed exactly, a fire causing death or serious injury may occur. - Page 20 Grill Operations LIGHTING Always visually inspect your grill before lighting. Replace any hoses that are frayed or cracked before lighting your grill. Look for anything that may be blocking spaces for ventilation and remove. After lighting, always check the flame to ensure you have a good flame all along each burner. If not able to light, or the flame is not even along the entire burner(s), then see the Trouble Shooting section WARNING 1.
-
Page 21: Cleaning Your Grill
TURNING OFF YOUR GRILL 1. Turn off the gas supply at the LP tank by turning the valve clockwise. 2. Turn all burner control knobs to the “Off” position. Cleaning Your Grill WARNING 1. Do not clean any part of your barbecue grill in a self-cleaning oven. 2. - Page 22 CLEANING THE BURNERS 1. Ensure the LP gas is turned off at the LP cylinder. 2. Remove the cooking grates, flame tamer, and grease tray. 3. Remove the cotter pins located underneath the back end of each burner. 4. Lift each burner up and out. 5.
-
Page 23: Grilling With Your New Grill
Grilling With Your New Grill Welcome to the world of grilling. Whether you’re already an established griller, or just starting out, your new grill should bring you much enjoyment and satisfaction, to say nothing of some phenomenal meals. We encourage you to experiment to find your own favorite recipes. The control panel is labeled “HI/LIGHT”, “LOW”, and “OFF”... -
Page 24: Trouble Shooting Guide
10. Turn foods infrequently. Generally, only turn a steak once during cooking. 11. Use tongs rather than a fork when turning the food on the grill. Less juice will be lost that way. 12. Know your sauce and when to apply. Oil and vinegar based sauces can be brushed on any time. Sugar based sauces like barbecue sauce should be applied during the last few minutes of cooking. -
Page 25: Frequently Asked Questions
Frequently Asked Questions Can I convert my gas grill from one fuel source to another? No. Your gas grill is manufactured to specific standards developed by CSA and ANSI for your safety and grilling performance for either LP or Natural Gas. We do not offer conversion kits nor do we recommend you change the fuel type. -
Page 26: Warranty Information
Warranty Information 1-888-922-2336 8:00 am to 10:00pm Monday thru Saturday 9:00am to 8:00pm Sunday, Central Standard Time Page 26 of 26...
