FOR YOUR SAFETY:
1. Read this Grill Guide before attempting to assemble or operate your grill.
2. Follow all safety instructions.
3. Check for leaks according to directions in this Grill Guide before operating your grill,
even if you purchased this grill assembled.
4. Keep this Grill Guide for future reference.
5. Contact 1-800-933-0527 should you need assembly assistance or have any questions.
THIS GRILL IS FOR OUTDOOR USE ONLY.
If stored indoors, then detach and leave propane cylinder outside.
Grill Guide
Model # BQ04022
LP Gas Barbecue Grill
STOP!
Missing A Part? No Need To
Go Back To The Store!
item.
If you need parts, whether they are
1-800-933-0527
1
