- Page 1 Trimmer HSS-99 HSS-99 HSS-99 with orthodontic accessories standard with inclined support USER MANUAL...
- Page 2 Dear customer, Thank you for choosing a product from the Wassermann range. Wassermann Dental- Maschinen incorporates the highest standards of quality and the latest technology. In order to enjoy maximum performance and years of trouble-free operation, please read this user manual carefully before you connect this device and start work, and operate the device according to the recommended guidelines.
-
Page 3: Table Of Contents
Contents 1 Features..........................4 2 Safety symbols used in this manual..................4 3 Safety Guidelines.......................5 3.1 Potential Dangers..........................5 3.2 Responsibility for Operation or Damage....................6 4 Application..........................6 5 Before Starting........................7 5.1 Transport............................... 7 5.2 Storage..............................7 6 Installation/ Start-up......................7 6.1 Installation............................. 7 6.2 Location.............................. -
Page 4: Features
Features ■ fully diamond-impregnated grinding disc for silky smooth and flat model surfaces ■ high grinding speed of 3000 min ■ extremely powerful, maintenance-free 1200 Watt motor for high efficiency, splash- protected as per IP 54 ■ optimal water control using ball valve and solenoid valve ■... -
Page 5: Safety Guidelines
Do not wear gloves. If you have long hair, wear some form of protection such as a hair net. • When working with the HSS-99, do not wear rings, chains, bracelets or • similar jewellery. Be sure to shut off the tap at night and over the weekend. -
Page 6: Responsibility For Operation Or Damage
Application The HSS-99 plaster model trimmer is used in dental laboratories and is designed only for grinding (trimming) plaster models. To prevent damage to the trimmer and/or to the grinding disc, it has to be used only with plaster. -
Page 7: Before Starting
Before Starting Transport Before transporting the unit, ensure that it has been unplugged from the power socket. Make sure that it is packed correctly in order to avoid accidental damage. Be sure to check for any transport damage when unpacking the goods. Note down any damage if found. -
Page 8: Location
Location Because the trimmer operates only with water, we recommend you install it close to a tap. The best place is right next to a washbasin. A further variation is to set up the trimmer on a console* in the basin itself (*available as accessory). The device has to stand horizontally on a steady and even surface. -
Page 9: Rinsing Water Hose
Rinsing Water Hose Locate the rinsing water hose (thinner hose with woven insert) between the tap and the hose connector on the trimmer. This connector is underneath the unit. Lay it on its side to connect the hose, making sure not to damage the paint. Use the clamps already on the hose to connect it, tightening them securely. -
Page 10: Mounting
It should be installed as shown in the diagram below. Make sure that items 1 and 2 are inserted and engaged correctly in the support plate. Setting The HSS-99 plaster trimmer does not need any other support than the one described in 6.1 “Installing the angled mount”. -
Page 11: Operation
Operation General Operating Instructions All instructions for using the unit, whether in verbal or written form, are based on our own experience and experimentation and can only be regarded as guidelines. After you switch the trimmer on, wait a few seconds for the motor to come up to speed. -
Page 12: Troubleshooting
Troubleshooting Fault Cause Solution Water spray at Water supply set too high Reduce water pressure at tap or ball disc opening valve (see 8.2 Water regulation) Drain hose has been Make sure that the diameter of the drain lengthened with a thinner hose is 1 inch (25.4 mm) hose Drain hose is kinked... -
Page 13: Care And Maintenance
11.2 Maintenance The HSS-99 plaster model trimmer does not require any maintenance. However, if you open the disc chamber for cleaning or to change the disc, be sure to clean the sealing surfaces and coat them with a new application of water-insoluble grease. -
Page 14: Repairs
11.3 Repairs Servicing or repairs to the unit has only to be carried out by qualified technicians. Only original spare parts are to be used. Responsibility for the product is voided if unauthorised persons alter it or if inappropriate components are installed. 11.4 Spare Parts If necessary please contact our service hotline phone. -
Page 15: Accessories And Spare Parts
11.7 Accessories and Spare Parts HSS-99 without diamond grinding disc 164999 HSS-99 factory-made with diamond grinding disc 164998 Incl. in delivery Item no.: Inclined support 164037 Supply hose ,1 m 320006 Discharge hose, 1 m 320017 Accessories Item no.: Spare diamond grinding disc, including puller and grease... -
Page 16: Technical Data
Technical Data HSS-99 without grinding disc Item no.: 164999 Voltage* 220–240 V / 50/60 Hz Power consumption 5.5 A Output 1200 W W x H x D 400 x 430 x 470 mm Weight 33.0 kg Sound level 65 dB (A) -
Page 17: Eu Declaration Of Conformity
Product description: Trimmer for dental Dental-Maschinen GmbH applications Rudorffweg 15-17 21031 Hamburg Germany Model: HSS-99 plaster trimmer with diamond grinding disc Item no. 164998 HSS-99 plaster trimmer without grinding disc Item no. 164999 Applicable DIN EN 61010-1 standards: DIN EN 61000-6-3... - Page 18 Notes:...
