- Page 1 Suction Unit Timobil Mobil Suction Table with Motor Handpiece USER MANUAL...
- Page 2 Dear customer, Thank you for choosing a product from the Wassermann range. Wassermann Dental- Maschinen incorporates the highest standards of quality and the latest technology. In order to enjoy maximum performance and years of trouble-free operation, please read this user manual carefully before you connect this device and start work, and operate the device according to the recommended guidelines.
-
Page 3: Table Of Contents
Contents 1 Features...........................4 2 Safety Symbols used in this Manual.................5 3 Safety Guidelines......................5 3.1 Duty S6 4 min / 10 min....................6 4 Responsibility for Operation or Damage................6 4.1 Warranty........................6 5 Application........................7 6 Before Starting.........................7 6.1 Transport........................7 6.2 Storage........................7 6.3 Installation........................8 7 Installation/ Start-up......................8 8 Operation..........................9 8.1 General Operating Instructions..................9... -
Page 4: Features
• The electrical cable rolls up automatically into the unit • The Timobil also has a sturdy handpiece motor: The speed range is between 1,000 • – 40,000 rpm and is infinitely adjustable using a foot pedal Turning the casing up to the stop opens and closes the chuck •... -
Page 5: Safety Symbols Used In This Manual
Safety Symbols used in this Manual Warning! This is a warning of risk situations and dangers. Failure to observe this warning could be life-threatening. These warnings has to be observed. Information! This symbol draws your attention to specific features that has to be observed. Safety Guidelines Configuring and operating this equipment requires precise knowledge and observance of the instructions in this user manual. -
Page 6: Duty S6 4 Min / 10 Min
The unit has to be maintained and operated in accordance with this user manual. Wassermann Dental-Maschinen GmbH is not responsible for damage arising from the nonobservance of these instructions. -
Page 7: Application
Application The Timobil is a stand-alone dust extractor with an integrated handpiece for use in the laboratory and in the field. It is especially useful for cutting and trimming dental appliances while sitting on a bench stool. Only use the device for this type of application. -
Page 8: Installation
Installation Open the box, remove the packing materials, and carefully lift out the device and accessories. Check the included accessories. The accessories are located in the unit, under the filter. The device has to stand horizontally on a steady and even surface. Install the device in a place where it will not block the working area and the functionality (take the dimensions into account). -
Page 9: Operation
Operation General Operating Instructions All instructions for using the unit, whether in verbal or written form, are based on our own experience and experimentation and can only be regarded as guidelines. Troubleshooting Fault Cause Solution Little or no extraction Filter bag full Change filter bag No power Microswitch... -
Page 10: Care And Maintenance
Care and Maintenance 10.1 Repairs Servicing or repairs to the unit has only to be carried out by qualified technicians. Only original spare parts are to be used. Responsibility for the product is voided if unauthorised persons alter it or if inappropriate components are installed. 10.2 Changing the Filter The unit has a one-way filter bag, which is easy to change when it is full. -
Page 11: Cleaning
10.5 Cleaning Disconnect the power plug before starting any maintenance work. The identification plate has always to be kept in easily legible condition and has not to be removed. Remove external dirt from time to time with some form of cold cleaner. Use only cold cleaners to avoid damaging the paintwork or removing the lettering. -
Page 12: Scope Of Delivery/ Accessories
(dust class M), 1 set = 4 pieces Spare filterbag for plaster 611018 (class 1 / class 2), 1 set = 4 pieces Storage tray 149010 Technical Data Timobil Artikel Nr.: 149999 Voltage 220–240 V / 50/60 Hz Power consumption 1.5 A Plug socket power consumption max... -
Page 13: Disposing Of The Unit
Disposing of the Unit The unit has to be disposed by an authorized recycling operation. The selected company has to be informed of all possibly health-hazardous residues in the unit. 12.1 Information on Disposal for Countries within the EU To conserve and protect the environment, prevent environmental pollution and improve the recycling of raw materials, the European Commission adopted a directive that requires the manufacturer to accept the return of electrical and electronic units for proper disposal or recycling. -
Page 14: Eu Declaration Of Conformity
Dental-Maschinen GmbH dental Rudorffweg 15-17 applications 21031 Hamburg Germany Model: Timobil Item no.: 149999 Timobil short version Item no.: 149996 Applicable DIN EN 61010-1 standards: DIN EN 61000-6-3 DIN EN 61000-6-1 DIN 45635-1 DIN EN 60335-1 Hiermit wird bestätigt, dass die oben bezeichnete Maschine den genannten EU-Richtlinien entspricht. - Page 15 Notes:...
