- Page 1 Polymerisation Unit Wapo-Mat III USER MANUAL...
- Page 2 Dear customer, Thank you for choosing a product from the Wassermann range. Wassermann Dental- Maschinen incorporates the highest standards of quality and the latest technology. In order to enjoy maximum performance and years of trouble-free operation, please read this user manual carefully before you connect this device and start work, and operate the device according to the recommended guidelines.
-
Page 3: Table Of Contents
Contents 1 Features..........................4 2 Safety Symbols used in this Manual..................4 3 Safety Guidelines.......................5 4 Responsibility for Operation or Damage................5 5 Application..........................5 6 Before Starting........................6 6.1 Transport........................6 6.2 Installation........................6 6.3 Storage........................6 7 Installation/ Commissioning/ Menufunctions..............7 8 Operation.........................13 8.1 General Operating Instructions.................13 8.2 Operation........................14 9 Warranty...........................14 10 Troubleshooting......................15... -
Page 4: Features
Features Compact benchtop unit for long-time and boiling polymerisation • Fully automatic program sequence, capable to handling 9 flasks simultaneously • Touchscreen-multifunctional display with minute and degree settings, remaining • time reading Powerful, electronically controlled heater for optimal water temperature, low water •... -
Page 5: Safety Guidelines
Warranty and responsibility provisions contained in the sales and supply conditions of Wassermann Dental-Maschinen GmbH are not extended by these instructions. Application The Wapo-Mat III is designed for water-bath polymerisation. All readily available plastics can be polymerised fully automatically, slowly (up to 99 hours), and at high temperature (99°C). -
Page 6: Before Starting
Before Starting Transport Before transporting the unit, ensure that it has been unplugged from the power socket. Make sure that it is packed correctly in order to avoid accidental damage. Be sure to check for any transport damage when unpacking the goods. Note down any damage if found. -
Page 7: Installation/ Commissioning/ Menufunctions
Installation/ Commissioning/ Menufunctions Before commissioning, please install the following connections: Firmly clamp the supplied drainage hose to the device and ensure there is a suitable drainage facility. Insert the plug into the socket – make sure that the voltage information between the device and the mains network is identical. - Page 8 The Set-Up Menu Page 1 Make the following settings in the set-up menu: Start temperature Timer Continue in the menu Sleep Calibration method Back to start menu The Set-Up Menu Page 2 C/°F Date and time Continue in the menu Heating ramp Information Back to the start menu...
- Page 9 Description of Functions 6 - 14 Program Parameters Defines the parameters for the program temperature and time. Touch the numbers to change the values. It is possible to store up to three polymerization steps # 1-3. Polymerization Step 1: Delete To the next program Save Examples of the Steps 2 and 3:...
- Page 10 Polymerization Stop / Pause Cancel Pause Back Start Preheating Temperature Defines the target temperature once the main switch has been activated. The preheat temperature also applies to waiting times and rest periods. Default: 65°C If the programme temperature selected is higher, the temperature falls back to this value when the programme ends.
- Page 11 Sleep Button Display Press the Sleep button to switch the system to sleep mode. Definition of Calibration Method DEF: Default (calibrated for mains water) CAL Calibration (only necessary for extreme deviations in water quality) Drain water Replenish water. This measure defines the conductance of the water!
- Page 12 Choose between °C Celsius and °F Fahrenheit Pictogram for the Sequence in Time and Date Function Choice of Working Mode Defines whether the time should start immediately or once the heating value has been reached. (a) (Default) Unit heats up to the temperature programmed via .After reaching this value, the result measured is validated by a control cycle.
-
Page 13: Operation
An additional safeguard protects the heating against overheating; it is automatically deactivated at above 99°C. Wear heat-retardant gloves when working with the Wapo-Mat III. Unplug the device if it is not in use for a longer period. -
Page 14: Operation
Operation Fill the work device with mains water to above the white plastic ring in the container (max. 18.5 litres). Activate main switch (green rocker switch). Check the water level – the low water alarm must not flash. ... -
Page 15: Troubleshooting
Troubleshooting Fault Cause Solution Wapo-Mat III does not Dirty level sensor Clean level sensor heat up Water level too low Add water Water-level LED comes Dirty level sensor Clean level sensor on and warning tone sounds fig,: 1. Water level too low... -
Page 16: Maintenance
Maintenance 11.1 Cleaning Pull out the mains plug before maintenance work. The model plate must always be legible and must not be removed. Clean the outside of the unit and any accessories with a sponge and/or a soft cloth and mild detergent. The equipment should be cleaned regularly (ie, clean every 4 weeks with Kalk-Ex) to guarantee problem-free operation. -
Page 17: Maintenance
11.2 Maintenance The Wapo-Mat III does not require any special maintenance. You just need to keep it clean. 11.3 Repairs Servicing or repairs to the equipment must only be carried out by trained technicians. Only original Wassermann spares are to be used. Responsibility for the product is voided if altered by unauthorised persons or if inappropriate components are installed. -
Page 18: Technical Data
Technical Data Wapo-Mat III Item no.: 170980 Voltage* 220–240 V / 50/60 Hz Power consumption: Output: 1800 W Overall dimensions: Width x 330 x 460 x 530 mm Height x Depth Weight: 18,5 kg Capacity : 18,5 l *Other voltages on request. -
Page 19: Eu Declaration Of Conformity
Product description: Polymerisation Dental-Maschinen GmbH Unit for dental Rudorffweg 15-17 applications 21031 Hamburg Germany Model: Wapo-Mat III Item no. 170980 Applicable DIN EN 61010-1 standards DIN EN 61000-6-3 DIN EN 61000-6-1 DIN 45635-1 DIN EN 60335-1 Hiermit wird bestätigt, dass die oben bezeichnete Maschine den genannten EU-Richtlinien entspricht.
