Quick Links

GE Oil & Gas
QSTBD
10/10 - Rev A
Masoneilan
*
SVi
1000 Positioner
*
Quick Start Guide (Rev F)
GE Data Classification: Public

Advertisement

loading

  Related Manuals for GE SVi 1000 Masonelian

  Summary of Contents for GE SVi 1000 Masonelian

  • Page 1 GE Oil & Gas QSTBD 10/10 - Rev A Masoneilan 1000 Positioner Quick Start Guide (Rev F) GE Data Classification: Public...
  • Page 2 APPROVAL OF GE. Copyright All software is the intellectual property of GE Oil & Gas. The complete design and manufacture of the SVi1000 Smart Valve Interface is the intellectual property of GE Oil & Gas. Copyright 2016 by General Electric Company. All rights reserved.
  • Page 3 Document Changes Version/Date Changes B/1-2012 Updated ES-761 to Rev. B. C/4-2012 Updated ES-761 to Rev. D. D/5-2013 Updated Figure 6 Rotary Kit Components. E/9-2013 Updated load limits switch drawing and added a reference to that section in installation. Added polarity caution to the Load Limits section.
  • Page 4 This page intentionally left blank.
  • Page 5: Table Of Contents

    Contents 1. Safety Information ................7 Documentation Symbols.......................... 7 SVi1000 Product Safety..........................8 2. Introduction ...................11 Introduction ..............................11 Functionality..............................12 Modes ................................15 LED Light Functions ............................ 17 Major Components............................19 3. Mounting and Wiring ................21 Introduction ..............................21 Step 1: Mounting the SVi1000 ........................ 23 Necessary Precautions ........................
  • Page 6 Appendix C. Specifications, Spare Parts and References ....65 Introduction ...............................63 Physical and Operational Specifications................... 65 Spare Parts..............................71 Hazardous Location Installation and Declaration of Conformity.......... 72 © 2016 General Electric Company. All rights reserved 6 | GE Oil & Gas...
  • Page 7: Safety Information

    1. Safety Information This section provides safety information and defines the documentation symbols. Documentation Symbols SVi1000 instructions contain warnings, cautions and notes, where necessary, to alert you to safety related or other important information. Read the instructions carefully before installing and maintaining your instrument.
  • Page 8: Svi1000 Product Safety

    This product is not intended for use in life support systems. WARNING Do not use damaged instruments. © 2016 General Electric Company. All rights reserved 8 | =GE Oil & Gas...
  • Page 9 WARNING Installation in poorly ventilated confined areas, with any potential of gases other than oxygen being present, can lead to a risk of personnel asphyxiation. Use only genuine replacement parts which are provided by the manufacturer, to guarantee that the products comply with the essential safety requirements of the European Directives. Changes to specifications, structure, and components used may not lead to the revision of this manual unless such changes affect the function and performance of the product.
  • Page 10 This page intentionally left blank.
  • Page 11: Introduction

    2. Introduction Introduction The SVi1000 Quick Start Guide is intended to help an experienced field technician efficiently in- stall and setup an SVi1000. If you experience problems that are not documented in this guide, refer to the SVi1000 Instruction Manual, call your local representative, go to www.geoilandgas.com/valves, or contact our helpdesk at (+1) 888-784-5463.
  • Page 12: Functionality

    Upper Stop Button and LED 2 Configuration Selection Switch Auto Tune Button and LED 3 4- 20 mA Input Signal Open Stop Adjustment Screw Figure 1 Operator Controls - Standard © 2016 General Electric Company. All rights reserved 12 | =GE Oil & Gas...
  • Page 13 Figure 2 shows the optional switch interface board and optional gauges. Solid State Switch SW #2 (Optional) Solid State Switch SW #1 (Optional) Gauges (Optional) Figure 2 Optional Digital Switches and Gauges Figure 3 shows the optional position retransmit interface board and optional gauges. 4-20 mA Output Signal (optional)
  • Page 14 This function is only active when the Configuration Selector Switch is set to AutoTune. See “Auto Tune” on page 49 for this procedure. © 2016 General Electric Company. All rights reserved 14 | =GE Oil & Gas...
  • Page 15: Modes

    Modes The SVi1000 provides the following modes of operation Normal mode ® HART Override mode (ValVue Manual and Setup Modes) Failsafe mode Commission Process (Via Local User Interface) Find Stops via Local User Interface Manual upper stops adjustment via Local User Interface Autotune via Local User Interface The SVi1000 always starts up in the mode that the unit was last in before power down, except for failsafe mode when the condition causing fail safe has been corrected.
  • Page 16 Processes a status light indicates this activity (see “LED Light Functions” on page 17). Examples of Commission Processes are Auto Find Stops and Auto Tune. Once a task completes the unit returns to Normal mode. © 2016 General Electric Company. All rights reserved 16 | =GE Oil & Gas...
  • Page 17: Led Light Functions

    LED Light Functions Figure 4 shows the local user interface LEDs and explains their patterns and timings. LED 1 (Green) LED 2 (Green) LED 3 (Green) LED 4 (Red) Figure 4 SVi1000 LEDs In Table 1 dots represent an LED being active and dashes represent the LEDs off. The pattern shown recurs as long as that condition exists.
  • Page 18 Setting out of If a setting is out of range the associated Green LED flashes at twice the range rate as normal until an acceptable range is applied. © 2016 General Electric Company. All rights reserved 18 | =GE Oil & Gas...
  • Page 19: Major Components

    Major Components Figure 6 shows the unit’s major components for reference. Pneumatic Relay Terminal Board Electronics Module Figure 6 SVi1000 Major Components Masoneilan SVi1000 Positioner Quick Start Guide =| 19 © 2016 General Electric Company. All rights reserved...
  • Page 20 This page intentionally left blank.
  • Page 21: Mounting And Wiring

    3. Mounting and Wiring Introduction This section describes how to mount and wire the SVi1000, which includes: “Step 1: Mounting the SVi1000” on page 23. “Mounting the SVi1000 on Rotary Valves” on page 24 “Mounting the SVi1000 on Reciprocating Valves” on page 29 “Step 2: Connecting the Tubing and Air Supply”...
  • Page 22 Do not operate a PC in a hazardous area without compliance to local and plant regulations. © 2016 General Electric Company. All rights reserved 22 | =GE Oil & Gas...
  • Page 23: Step 1: Mounting The Svi1000

    Step 1: Mounting the SVi1000 This guide provides installation instructions for mounting an SVi1000 on both rotary and recipro- cating style valves. The mounting process can be broken down into the following: 1. Attach the mounting bracket to the actuator. 2.
  • Page 24: Mounting The Svi1000 On Rotary Valves

    Figure 8 shows a side view of a Camflex actuator, the SVi1000, and a mounting bracket. SVi1000 Rotary Actuator Mounting Bracket Figure 8 Camflex with Mounting Bracket (Side View) © 2016 General Electric Company. All rights reserved 24 | =GE Oil & Gas...
  • Page 25 Tools required: M5 Hex Key M4 Hex Key M3 Hex Key To mount the SVi1000: 1. Attach the mounting bracket to actuator (Figure 9). Mounting Bracket Mounting Long Side Holes Flat Head Socket Cap Screw, 5/ Mount the long end of the mounting Valve Position Take 16"-18UNC X 0.62"...
  • Page 26 (Table 2). If mounting kit is installed on fail-open valve, apply air to the actuator to close the valve before installing magnet holder. © 2016 General Electric Company. All rights reserved 26 | =GE Oil & Gas...
  • Page 27 Table 2: Travel Sensor Alignment Rotary Stroke Direction Magnet Valve Sensor Counts Mounting Orientation Position System Rotary <60° Rotation Closed (0%) 0 +/- 1000 Clockwise or counter- clockwise rotation (0°) >60° Rotation Full Open -8000 +/- 1500 Clockwise with increas- ing setpoint Full Closed +8000 +/- 1500...
  • Page 28 Align the end of the magnet holder assembly with the end of the mounting bracket Alignment ring V-seal in contact V-seal with alignment ring Figure 11 Camflex V-Seal © 2016 General Electric Company. All rights reserved 28 | =GE Oil & Gas...
  • Page 29: Mounting The Svi1000 On Reciprocating Valves

    Mounting the SVi1000 on Reciprocating Valves This section describes the procedure for mounting the SVi1000 on Reciprocating Valves, using Masoneilan’s 87⁄88 Multi-Spring actuators as an example. Figure 13 on page 29 shows the stan- dard lever for all size installations. See“Integrated Magnet Assembly” on page 32 for the optional IM assembly.
  • Page 30 (12.7 - 20.32 mm) (133.35 mm) >0.8 – 1.5" 5.25" (20.32 - 41.5 mm) (133.35 mm) >1.5 – 2.5" 5.25" (41.5 - 63.5 mm) (133.35 mm) © 2016 General Electric Company. All rights reserved 30 | =GE Oil & Gas...
  • Page 31 4. Thread the take-off rod to the actuator stem connector (Figure 14). Magnet Housing Install 1/4-20 x 1 Nut Install 1/4-20 x 1 Cap Screw Right Hand Rod Turnbuckle Length as per Table 3 Left Hand Rod End: Install 1/4-20 x 1 Nut and Cap Screw Take Off Rod Figure 14 SVi1000 Take Off Rod Mounting...
  • Page 32: Integrated Magnet Assembly

    Figure 16 SVi1000 Lever Installed to IM Assembly NOTE You can use a custom bracket with the IM option. Refer to drawing #720012413 for assistance. © 2016 General Electric Company. All rights reserved 32 | =GE Oil & Gas...
  • Page 33: Step 2: Connecting The Tubing And Air Supply

    Step 2: Connecting the Tubing and Air Supply To connect the air supply: 1. Install the tubing to the air supply port. Minimum tubing diameter 1⁄4" (Figure 17). Actuator Connection 1/4" NPT Supply Connection 1/4" NPT Conduit Connection Figure 17 Air Ports 2.
  • Page 34: Step 3: Wiring The Svi1000

    Refer to “Optional Switch Load Limits” on page 61 for guidelines on safely wiring switch load limits. © 2016 General Electric Company. All rights reserved 34 | =GE Oil & Gas...
  • Page 35: Wiring Guidelines

    Wiring Guidelines ® Guidelines for a successful implementation of DC current signal, DC power, and HART commu- nication to the SVi1000: Compliance voltage at the SVi1000 is approximately 9 V at the current of 20 Signal to the SVi1000 must be a regulated current in the range 3.2 to 22 mA. ®...
  • Page 36: Wiring An Svi1000 Unit

    1. Loosen the four (4) cover screws and remove the SVi1000 cover (Figure 18). Figure 18 Front Cover © 2016 General Electric Company. All rights reserved 36 | =GE Oil & Gas...
  • Page 37 2. Connect the 4 - 20 mA input signal and the optional switches or position retransmit by: a. Stripping the insulation at the end of both wires 0.43" / 11 mm. b. Inserting the stripped end of the wires fully in to the appropriate terminal. Loosen the terminal screw if required to insert the wire.
  • Page 38 If the polarity is correct but the voltage is less than 8.05 V, then the current source voltage is not compliant. 2. Verify that source can supply 20 mA to SVi1000 input. If 20 mA is not attainable, troubleshoot the source. © 2016 General Electric Company. All rights reserved 38 | =GE Oil & Gas...
  • Page 39 Position Retransmit Units To troubleshoot control loop connections: 1. Connect a DC voltmeter across the input and output terminals. For an input current between 4 and 20 mA the voltage varies between 11V and 9 V respective. If voltage exceeds 11 V check that polarity is correct. If the polarity is correct but the voltage is less than 8.05 V, then the current source voltage is not compliant.
  • Page 40 This page intentionally left blank.
  • Page 41: Check Out And Configuration

    4. Check Out and Configuration Overview This section provides the calibration procedures to ensure proper valve positioning, which include: “Step 1: Inspect the Actuator, Linkages, or Rotary Adapter” on page 42 “Step 2: Verify Mounting and Linkage Adjustment” on page 42 “Step 3: Checking the Magnet”...
  • Page 42: Step 1: Inspect The Actuator, Linkages, Or Rotary Adapter

    Ensure the bracket is mounted using the proper holes (see Table 3 on page 30). © 2016 General Electric Company. All rights reserved 42 | =GE Oil & Gas...
  • Page 43: Use Valvue To Check Magnet Position

    Use ValVue to Check Magnet Position To check the magnet using ValVue: 1. Connect to the positioner in accordance with the ValVue instructions. ® a. Ensure the positioner has been installed and set up with a HART modem in a ®...
  • Page 44: Step 5: Verify Wiring Connections

    WARNING These procedures can cause the valve to move. Before proceeding ensure the valve is isolated from the process. Keep hands clear from moving parts. © 2016 General Electric Company. All rights reserved 44 | =GE Oil & Gas...
  • Page 45: Auto Find Stops

    Auto Find Stops The process first exhausts the actuator and measures the position, then fills the actuator and measures the position. From these measurements the valve position is determined. Correction can be made for nominal valve travel if it is less than full travel. To perform auto find stops: 1.
  • Page 46: Tuning

    8 are reserved for auto tuning ATO and ATC valves, respectively. Preset tuning becomes active immediately. Gain increases as the tuning value increases. Figure 22 Preset Tuning Values © 2016 General Electric Company. All rights reserved 46 | =GE Oil & Gas...
  • Page 47 To use preset tuning values: Use the Configuration Selection Switch to select a preset tuning value (Figure 23). Cancel Button LED 4 Configuration Selection Switch Figure 23 Configuration Selection Switch Masoneilan SVi1000 Positioner Quick Start Guide =| 47 © 2016 General Electric Company. All rights reserved...
  • Page 48 6b) 9" Camflex, 7-24 SR 7a) #16, 87(ATC), 6-30 SR 7b) #16, 88(ATO), 21-45 SR Large 7c) #23, 87 (ATC), 6-30 SR 7d) #23, 88(ATO), 21-45 SR © 2016 General Electric Company. All rights reserved 48 | =GE Oil & Gas...
  • Page 49: Auto Tune

    Auto Tune Auto Tune normally takes three to ten minutes and strokes the valve in large and small steps to set the PID positioning parameters for best response to an input signal change. This procedure overrides any previous configuration done using presets. To auto tune the SVi1000: 1.
  • Page 50 This page intentionally left blank.
  • Page 51: Valvue Software And The Svi1000

    Cloning transfers the configuration and calibration parameters from one device to another. Cloning operations are to be performed only by GE personnel or qualified channel partners trained on properly performing the cloning function. This feature is not available during normal ValVue operation.
  • Page 52: Valvue And Svi1000 Dtm Software Installation

    ValVue Installation 1. From your web browser and go to the GE Oil and Gas Download center at: http://www.ge-mcs.com/en/download.html. 2. On the web page enter items in the pulldowns as in Figure 25 and click Search.
  • Page 53 4. Click the link and Figure 27 appears. Figure 27 Download Software Terms 5. Review the information and click I Accept and Figure 28 appears. Figure 28 Registration Form Masoneilan SVi1000 Positioner Quick Start Guide =| 53 © 2016 General Electric Company. All rights reserved...
  • Page 54 9. Open the Downloads folder, double-click the zip file, then double-click the .exe and follow the system prompts to install. Once installed, along with the SVi100 DTM file you are able to access the online help. © 2016 General Electric Company. All rights reserved 54 | =GE Oil & Gas...
  • Page 55 SVi1000 DTM Installation 1. Open your web browser and go the link: http://www.ge-mcs.com/en/ download.html. 2. On the web page and enter SVi1000 DTM Software in the Search for a particular product field and click Search. Navigate through the list and find the latest DTM software as in Figure 31.
  • Page 56 4. Review the information and click I Accept and Figure 33 appears. Figure 33 Registration Form 5. Enter the required information in all fields, click Submit and Figure 34 appears. Figure 34 Ready to Download © 2016 General Electric Company. All rights reserved 56 | =GE Oil & Gas...
  • Page 57 6. Click the link and Figure 35 appears. Figure 35 DTM Download ® 7. Click Save File, click OK to automatically save it to your Windows Downloads folder. 8. Open the Downloads folder, double-click the SVi1000_DTM_Installer zip file, then double-click the .exe and follow the system prompts to install. Once installed, along with the ValVue file you are able to access the online help.
  • Page 58: Hart® Handheld Communicator

    Communicator product manual included with the HHC or other HART Communi- cation devices. 12.00 mA Input Signal GE DPI620 ® Figure 36 SVi1000 HART Communicator Connections © 2016 General Electric Company. All rights reserved 58 | =GE Oil & Gas...
  • Page 59: Appendix A. Svi1000 Theory

    HART Modem ValVue GE DPI620 Figure 37 General Purpose Installation For information and diagrams to install the SVi1000 when located in a hazardous area protected by Intrinsically Safe wiring practices, refer to ES-761 the Intrinsically Safe Wiring Requirements section ( “Hazardous Location Installation and Declaration of Conformity”...
  • Page 60: Grounding Practices

    The SVi1000 is unique in that it requires LESS voltage at higher current which complements the characteristic of the source requiring only 9 V at 20 mA. © 2016 General Electric Company. All rights reserved 60 | =GE Oil & Gas...
  • Page 61: Appendix B. Optional Switch Load Limits

    Appendix B. Optional Switch Load Limits General Configuration Notes The SVi1000 supports two identical contact outputs, SW #1 and SW #2 (Digital Output switches), that can be logically linked to status bits. The Digital Output switch terminals are solid state con- tacts.
  • Page 62 Load is designed to ensure that voltage across the switch is < 1 V. LOAD External SVi1000 Switch Voltage Output: 1 V Source with switch ON Figure 38 Simplified Switch Installation Drawing: Correct Configuration © 2016 General Electric Company. All rights reserved 62 | =GE Oil & Gas...
  • Page 63: Optional Retransmit Output

    Without a load, when the switch is on (closed) the external voltage would be dropped across the switch. This damages the switch (Figure 39). Full voltage drop is occur- External ring across the SVi1000 NOT ALLOWED Voltage switch (no cur- Switch Source rent limit in...
  • Page 64 (current) can be transferred into voltage (Figure 40). 4 - 20 mA current flow External Voltage SVi1000 Switch Source: Retransmit 10 V to 30 V Figure 40 Simplified Retransmit Option Installation Drawing © 2016 General Electric Company. All rights reserved 64 | =GE Oil & Gas...
  • Page 65: Appendix C. Specifications, Spare Parts And References

    Appendix C. Specifications, Spare Parts and References Physical and Operational Specifications This section provides the physical and operational specifications for the SVi1000. Specifications are subject to change without notice Table 6: Environmental Specifications Parameter Storage & Transport (Packaged) Operating Temperature Limits -40 °F to 185 °F (-40 °C to 85 °C) Storage Temperature Limits -58 °F to 200 °F (-50 °C to 93 °C)
  • Page 66 Equal Percentage (of 50:1 or 30:1) inherent characteristic. Camflex Quick Opening (inverse of 50:1 equal percent- age) User Configurable Tight Shut Off 0 -20% of input © 2016 General Electric Company. All rights reserved 66 | =GE Oil & Gas...
  • Page 67 Table 7: Operational Specifications (Continued) Position Auto Tune Proportional gain: 0 to 5000 SVi1000 performs automatic determination Integral time: 0 to 100 seconds - displayed as 0 to 1000 (1/10s) of the optimal valve position control param- eters. In addition to P, I, D, the position algo- Derivative time: 0 to 200 ms rithm uses damping, symmetry for exhaust Dead Zone: 0 to +/-5% (0 to 10% deadband)
  • Page 68 ValVue standalone, ValVue AMS SNAP-ON application ® software available, Plug-In Application For Yokogawa PRM, ValVue ® For Honeywell FDM, Device Type Manager (DTM) for ® Host © 2016 General Electric Company. All rights reserved 68 | =GE Oil & Gas...
  • Page 69 Table 11: Pneumatics Single Acting Standard Flow Air Supply Dry, oil-free, 5 micron filtered air (per ISA S7.3) Action Direct Acting Supply Pressure 15 to 100 psi max. (1.03 to 7 Bar) Regulate 5 psi minimum above actuator spring range. Do not exceed actuator rating. Air Delivery 10.0 scf/min (283 L/min.) at 30 psi (2.1 bar) supply 16.6 scf/min.
  • Page 70 SVi1000 /SW/G/IM Assembly with switches, gauges and integrated magnet SVi1000 /PR/IM With position retransmit and integrated magnet SVi1000 /PR/G/IM With position retransmit, gauges and integrated magnet © 2016 General Electric Company. All rights reserved 70 | =GE Oil & Gas...
  • Page 71: Spare Parts

    Spare Parts Spare part kits available include: SVi1000 Position Retransmit Main Electronics Assembly and Terminal Board (Part Number 720045089-999-000) SVi1000 IP Replacement (Part Number 720045087-999-000) SVi1000 Housing Cover Replacement (Part Number 720045085-999-000) SVi1000 Position Retransmit Terminal Board Electronic Assembly (Part Number 720045084-999-000) SVi1000 Switch Terminal Board Electronic Assembly (Part Number 720045083-999-000) SVi1000 Main Electronics Assembly (Part Number 720045081-999-000)
  • Page 72: Hazardous Location Installation And Declaration Of Conformity

    Declaration of Conformity. WARNING The installation procedure is accurate at time of print. For further hazardous installation information please consult the factory. © 2016 General Electric Company. All rights reserved 72 | =GE Oil & Gas...
  • Page 73 GE Oil & Gas Original Instructions ES-761 SPECIAL INSTRUCTIONS FOR INSTALLING MASONEILAN SVi1000 IN AREAS WHERE THERE IS A POTENTIAL FOR EXPLOSIVE GAS ATMOSPHERES Written by B. Belmarsh Dec 15, 2010 Description Date Initial Release Dec 15, 2010 Checked by H.
  • Page 74 Technologies, Dresser Inc. It is confidential and must not be made public or copied and is subject to return upon demand. ES-761 Rev F Page 2 of 12 © 2016 General Electric Company. All rights reserved 74 | =GE Oil & Gas...
  • Page 75 Mounting does not affect the suitability of the SVi1000 for use in a potentially explosive gas atmosphere. For language translation assistance contact your local representative or email svisupport@ge.com. Pour la langue de traduction aide, contactez votre représentant local ou envoyez un e-mail svisupport@ge.com.
  • Page 76 Technologies, Dresser Inc. It is confidential and must not be made public or copied and is subject to return upon demand. ES-761 Rev F Page 4 of 12 © 2016 General Electric Company. All rights reserved 76 | =GE Oil & Gas...
  • Page 77 GE Oil & Gas o Verify that the markings on the label are consistent with the application. o Verify that the air supply pressure can not exceed the marking on the label. Model Number Description of SVi1000 The SVi1000 model numbers approved for the use in potentially explosive atmospheres are shown in the following table.
  • Page 78 Technologies, Dresser Inc. It is confidential and must not be made public or copied and is subject to return upon demand. ES-761 Rev F Page 6 of 12 © 2016 General Electric Company. All rights reserved 78 | =GE Oil & Gas...
  • Page 79 GE Oil & Gas 5.2 Operating Ranges 5.2.1 Temperature C to 85 5.2.2 Input Voltage 30 volts 5.2.3 Supply Pressure 100 psig Clean instrument air and natural gas are the typical supply sources. 5.2.4 Current 4 to 20mA 5.3 Enclosure Type...
  • Page 80 Technologies, Dresser Inc. It is confidential and must not be made public or copied and is subject to return upon demand. ES-761 Rev F Page 8 of 12 © 2016 General Electric Company. All rights reserved 80 | =GE Oil & Gas...
  • Page 81 GE Oil & Gas 6.2 Model SVi1000abc, where a = PR Installation NON-HAZARDOUS LOCATION – UNSPECIFIED EXCEPT THAT BARRIERS MUST NOT BE SUPPLIED FROM NOR CONTAIN UNDER NORMAL OR ABNORMAL CONDITIONS A HAZARDOUS LOCATION SOURCE OF POTENTIAL WITH RESPECT TO EARTH IN SEE NOTES 7.1 AND 7.2...
  • Page 82 500 volts R.M.S. to earth or frame of the apparatus for 1 minute. Installation must be in accordance with GE guidelines. The installation including the barrier earthing requirements must comply with the installation requirements of the country of use.
  • Page 83 FOR USE IN A HAZARDOUS LOCATION. Only qualified service personnel are permitted to make repairs on the SVi1000 positioner. Replace ONLY with genuine GE parts. Replacement of the Main electronics board, Basic, Switch and Position Retransmit Terminal boards, Housing cover kit, pressure gauges, I/P assembly and Integral magnet assembly are the only field repairs permitted.
  • Page 84 Ensure the four cover bolts screws are secure by applying 17.7±1.77 in-lbs or 2.0±0.20 N*m. For assistance, contact the nearest sales office, your local representative or email svisupport@ge.com. Visit our web page at www.ge-energy.com/valves Maintenance Connection The electronics module is protected by a plastic snap on cover.
  • Page 85 Masoneilan SVi1000 Positioner Quick Start Guide =| 85 © 2016 General Electric Company. All rights reserved...
  • Page 86 DISTRIBUTOR E.P. & S. - FRANCE 24 bis rue de Picpus 75012 PARIS Tel: +33 (0)9 83 01 21 01 ventes@fr-eps.com E.P. & S. - CAMEROON Immeuble Carré d'Or, Rue Njo-Njo Bonapriso, DOUALA Tel: +237 6 52 12 70 95 ventes@fr-eps.com Visit your web-site: www.fr-eps.com...
