Unit options

There are two dehumidification modes of operation:
Hot Gas Reheat Dehumidification with Temperature
1 .
Control.
Hot Gas Reheat Dehumidification.
2 .
Hot gas reheat with temperature
control application
Hot Gas Reheat with Temperature Control uses a
combination of 2-stage thermostat and humidistat to
optimize unit capacity and for maximum latent capacity
while decreasing room humidity levels.
■ Operation:
A call for heating or cooling has a higher priority
than a call for dehumidification. Dehumidification is
allowed only if the room temperature is satisfied. If the
controller detects the need for heating or cooling, or if
the Humidistat is no longer calling for dehumidification,
dehumidification mode will be suspended.
Dehumidification mode will enable both 3-way hot gas
bypass valve, sending hot superheated refrigerant to the
hot gas reheat coils while running the compressor at full
load and the fan.
Hot gas reheat dehumidification
only
■ Operation:
In applications where only dehumidification is needed,
the humidistat can be wired to TB1-1 on the Microtech
III unit controller, allowing the WSHP unit to operate in
dehumidification mode only. The unit will only respond to
a call for dehumidification.
■ Items required:
• Humidistat
■ Unit control settings:
•
I/O Expansion Module Jumper Settings:
• JP5=Shorted
• JP6=Open
■ Wiring:
OM 1239
M
Figure 10: Unit and humidistat-dehumidification only
wiring diagram
Unit Base Board TB2
R
C
G
Y1
Y2
W1
W2
O
A
I/O Expansion Module TB1
1
2
■ Items required:
• Unit with Hot Gas Reheat option
• Humidistat and a Thermostat OR Digitally
Adjustable Wall Sensor
■ Unit control settings:
•
I/O Expansion Module Jumper Settings:
• JP5 = Shorted
• JP6 = Open
■ Wiring:
•
Thermostat (Part No. 910121750)
Sensor (Part No. 910129095 or 910129096)
Combination:
Figure 11: Thermostat and humidistat combination for hot
gas reheat dehumidification wiring diagram
Unit
R
C
G
Y1
Y2
TB-1
•
Digitally adjustable room temperature sensor (Part
No. 910121754)
23
t III u C
ICro eCh nIt ontroller
Thermostat
RC 24VAC
RH 24VAC
C 24VAC Common
G Fan
Y Cool Stage #1
Y2 Cool Stage #2
W1 Heat Stage #1
W2 Heat Stage #2
W3 Heat Stage #3
L Alarm Input
Humidistat
D/A Dehumidification
W4 Heat Stage #4
Thermostat
R 24VAC
C Common
G Fan
Y1 Cool Stage 1
Y2 Cool Stage 2
Humidistat
R 24VAC
DH Dehumid
