LANCOM 3850 UMTS
Chapter 10: Appendix
10 Appendix
10.1
Performance data and specifications
Frequency band
Connections
ETH1, ETH2
WLAN1
WLAN2
Power supply
12V DC via external power supply adapter, or Power over Ethernet by IEEE 802.3 standard
Antenna connection
Two reverse SMA connections for external LANCOM AirLancer-Extender antennas and 3-dBi-
dipol dualband antennas (in package contents)
Please respect the restrictions given in your country when setting up an antenna system. For
information about calculating the correct antenna setup, please refer to
www.lancom-systems.com.
Housing
210mm x 143mm x 45mm (BxHxT), rugged plastic case, stackable, provision for wall moun-
ting
Norms
CE compliant according to ETSI EN 300 328, ETSI EN 301 893, ETSI EN 301 489-1, ETSI EN
301 489-17, EN 60950
Radio licenses for all EU countries and Switzerland
Regulations
Notified in Germany, Belgium, Netherlands, Luxemburg, Austria, Switzerland, United King-
dom, Italy, France, Spain, Portugal
Environment
Temperature range 0°C to +50°C at 95% max. humidity (non condensing)
Service
Warranty: 3 years
Support
Via hotline and Internet
Accessories
Options
82
2400 - 2483,5 MHz (ISM) or 5150 - 5750 MHz
10/100base-TX, autosensing
Two reverse SMA connections with antenna diversity
32 bit cardbus interface for optional UMTS or second radio card
LANCOM Modem Adapter Kit for connecting modems (analog or GSM) to the serial
configuration interface (item no. 61500)
LANCOM Advanced VPN Client for Windows 98SE-XP, 1 License, item no. 61600
LANCOM Advanced VPN Client for Windows 98SE-XP, 10 Licenses, item no. 61601
LANCOM Advanced VPN Client for Windows 98SE-XP, 25 Licenses, item no. 61602
LANCOM ES-1108P compact, robust 8-port Ethernet switch with 4 PoE interfaces, item no.
61450
Lightning-protector adapter SA-5 (2.4 and 5 GHz), item no. 61212
Lightning-protector adapter SA-LAN, item no. 61213
LANCOM Rack Mount Option (item no. 61501)
LANCOM VPN Option 25 channels (hardware accelerated, max. 25 simultaneous
connections, 50 connections configurable) for VPN in WAN (item no.60083)
LANCOM Public Spot Option (item no. 60642)
LANCOM 3850 UMTS
