LANCOM 3850 UMTS
Chapter 2: Installation
WLAN Provides information about the WLAN connections via the internal WLAN
modules. The following can be displayed for WLAN link:
Off
Green
Green
Green
Green
Red
Red
Status of a VPN connection.
VPN
Off
Green
Green
Green
Green
ETH LAN connector status in the integrated switch:
Off
Green
Green
Red
24
No WLAN network defined or WLAN module deactiva-
ted. The WLAN module is not transmitting beacons.
At least one WLAN network is defined and WLAN
module activated. The WLAN module is transmitting
beacons.
Inverse flashing Number of flashes = number of connected WLAN stati-
ons and P2P wireless connections, followed by a pause
(default).
Alternatively, the frequency of the flashed can indicate
the input sensitivity.
Blinking DFS scanning or other scan procedure.
Flashing WLAN-Modul switched off due to fall below operating
temperature
Flickering Error in wireless LAN (TX error, e.g. transmission error
due to a poor connection)
Blinking Hardware error in the WLAN module
No VPN tunnel established
Blinking Connection establishment
Flashing First connection
Inverse flashing Other connections
On (perma- VPN tunnels are established
nently)
No networking device attached
On (perma- Connection to network device operational, not data traffic
nently)
Flickering Data traffic
Flickering Data packet collision
