HEATED LANDING ZONE (HLZ 18 AND HLZ 22)
MANUFACTURED BY FRYMASTER, L.L.C.
P.O. BOX 51000
SHREVEPORT, LOUISIANA 71135-1000
PHONE 1(318)865-1711
1 (800) 24 FRYER
Return to Non-Fryer Cover
1. WARRANTY STATEMENT ...........................................................................................................1
1.1
WARRANTY PROVISIONS - HEATED LANDING ZONE....................................................................................... 1
1.2
PARTS RETURN .................................................................................................................................................... 1
1.3
WARRANTY EXCLUSIONS ................................................................................................................................... 1
2. PARTS ORDERING AND SERVICE INFORMATION ...................................................................2
3. HEATED LANDING ZONE............................................................................................................3
4. INSTALLATION/SETUP................................................................................................................3
5. OPERATION .................................................................................................................................3
6. HLZ MODEL/COMPONENT IDENTIFICATION ............................................................................4
7. HLZ COMPUTER OPERATION AND PROGRAMMING ...............................................................5
7.1
PROGRAMMING TEMPERATURE ........................................................................................................................ 5
7.2
OPERATION........................................................................................................................................................... 5
8. HLZ OPERATOR TROUBLESHOOTING .....................................................................................8
9. SERVICE INFORMATION ......................................................................................... 10
9.1 PARTS LIST......................................................................................................................................10
9.2 INTERIOR VIEW OF AN HLZ ...............................................................................................................10
9.3 PROCEDURES..................................................................................................................................11
9.4 TROUBLESHOOTING FLOWCHART..................................................................................................... 15
9.5 COMPONENT TEST PROCEDURES.................................................................................................... 18
9.6 AIR HEATER/PLATE HEATER RTD RESISTANCE CHART................................................................................... 21
9.7 WIRING DIAGRAM .................................................................................................................................................. 22
APPENDIX A PROTOTYPE UNITS (BUILT BEFORE JUNE 15, 1998)...................................... 23
Frymaster L.L.C., 8700 Line Avenue 71106, P.O. Box 51000, Shreveport, Louisiana 71135-1000
Printed in the United States
SERVICE MANUAL
This equipment chapter is to be inserted in the Equipment Manual.

TABLE OF CONTENTS

Click on Chapter Titles
318-865-1711
1-800-24-FRYER
FAX 318-862-2394
Service Hotline
Return to Cover
819-5659 (7/00)
