BEL-20+ CHAIR
This manual provides operating instructions for the BEL-20+ Chair.
The instructions contained in this booklet should be thoroughly read and understood
before operating the chair.
After the installation has been completed, keep this manual in a safe place and refer to
it for future maintenance.
(Plus)
Operating
Instructions
IMPORTANT
Series
1E0078A0
R
Advertisement
Related Manuals for Belmont BEL-20+
Summary of Contents for Belmont BEL-20+
- Page 1 Series BEL-20+ CHAIR (Plus) Operating Instructions IMPORTANT This manual provides operating instructions for the BEL-20+ Chair. The instructions contained in this booklet should be thoroughly read and understood before operating the chair. After the installation has been completed, keep this manual in a safe place and refer to it for future maintenance.
- Page 2 Table of Contents 1. Overview and major components ---------------- 1 2. Dimentions and Specifi cations -------------------- 2 3. Operation -------------------------------------------- 2 4. Care and Maintenance ----------------------------- 6 Intended Use of the Product This product is intended for the exclusive use for diagnoses, treatments and relative procedures of dentistry, and must be operated or handled by the qualifi...
-
Page 3: Overview And Major Components
CAUTION The followins are prohibited. • To modify this equipment. • To use the equipment under any failure condition. • To use the equipment without doing the daily and periodical check-up. • To wipe the plastic covers with any disinfectant or detergent that contains organic solvent. •... -
Page 4: Dimentions And Specifi Cations
2. DIMENSIONS AND SPECIFICATIONS 2-1 Dimensions (Inches) 57-7/8 23-3/8 20° 18-1/2 8° 10° 10-1/4 70° 7-5/8 20° 10° 73-5/8 21-5/8 13-5/8 4-3/4 36-1/4 21/1-4 36-1/4 26-3/8 (max 21-1/4) 73-1/2 73-1/2 Minimum 18” Minimum 22” to any object to wall at lowest at lowest position position Base... - Page 5 CAUTION To avoid the risk of electrick shock, this equipment must only be connected to a supply mains with protective earth. Grounding reliability can only archieved when the equipment is connected to an equivalent receptacle marked HOSPITAL ONLY or HOSPITAL GRADE. 2) Turn on the main power switch located on the left side of the pump cover.
- Page 6 1) Seat Height Adjustments a. Raise the seat by pressing foot, backrest or touchpad control (optional) indi- cated “Seat Raise”. b. Lower the seat by pressing foot, backrest or touchpad control (optional) indi- cated “Seat Lower”. 1) Seat Height Adjustments a.
- Page 7 2) Chair Rotation To rotate the chair, release lock lever on right side of the chair, by pushing downward. Pull lever to lock. 3) Cancellation a. Safety plate is provided below base link cover to stop motion of chair when object is accidentally caught under- neath.
-
Page 8: Care And Maintenance
4. CARE AND MAINTENANCE 4-1 Cleaning and disinfection CAUTION Do not spray liquids directly onto chair surfaces. In order to prevent damage to electrical components and systems, do not apply excess cleaning solution onto chair surfaces. Routine Care Clean plastic and upholstery surfaces iegularly using a mild soap and water solution. When cleaning, use a dampened cloth only, as excess cleaning solution can fl... - Page 9 4-3 Daily Check-up of functions by the end user The end-user is responsible for daily check-up of the equipment. In the case end user does not do this, it is al- lowed that you outsource it to a technician authorized by us. In order to assure safety use of this equipment, please carry out the following check-up in a frequency as indi- cated below.
- Page 10 4-4 Guideline for Periodical Check-up • Some parts and components of the products are degraded or deteriorated depending on the frequency of use, so yearly check-up and maintenance, as well as replacement of comsumable parts, are required. • For check-up and repair, call a technician of our authorized dealer. Parts and components that require periodical check-up Parts Description Standard Lifetime...
- Page 12 Name : Address : BELMONT EQUIPMENT, Division of Takara Belmont USA, Inc. 101 Belmont Drive Somerset, New Jersey 08873 U.S.A. TEL.:(732) 469-5000 / (800) 223-1192 Fax.:(732)526-6322 / (800) 280-7504 TAKARA CO, CANADA LTD. 2076 S. Sheridan Way, Mississauga, Ont., L5J2M4, Can.
