3.0 Specifications

Electrical Specifications

Frequency Range:
Input Impedance (Nominal):
VSWR (Average):
Maximum Continuous Power
30 MHz—60 MHz:
60 MHz—600 MHz:
600 MHz—1000 MHz:
Peak Power:
Pattern Type:
Polarization:
Connector:

Physical Specifications

Height (Overall):
Length:
Width:
Weight:
Specifications
26 MHz–1 GHz
50 Ω
2:1 above 80 MHz
500 W
1 kW
500 W
1.3 kW
Directional
Linear
Type N female
76.2 cm (30 in)
124.35 cm (48.96 in)
133.75 cm cm (52.66 in)
5.5 kg (12 lb)
| 13
