QUICK GUIDE
Uponor Smatrix
Uponor Smatrix
Base PRO
Uponor Smatrix
Base PRO
U K I N S TA L L AT I O N A N D O P E R AT I O N Base PRO
M A N U A L
U K I N S TA L L AT I O N A N D O P E R AT I O N
M A N U A L
U K I N S TA L L AT I O N A N D O P E R AT I O N
M A N U A L
Uponor Smatrix Base
PRO components
An Uponor Smatrix Base PRO system may be a
combination of the following components:
• Uponor Smatrix Base PRO Controller X-147
(controller)
• Uponor Smatrix Base PRO Interface I-147
(interface)
• Uponor Smatrix Base Thermostat D+RH T-149
(digital thermostat T-149)
• Uponor Smatrix Base Thermostat Prog.+RH T-148
(digital thermostat T-148)
• Uponor Smatrix Base Thermostat Dig T-146 (digital
thermostat T-146)
• Uponor Smatrix Base Thermostat Standard T-145
(standard thermostat T-145)
• Uponor Smatrix Base Thermostat Flush T-144 (flush
thermostat T-144)
• Uponor Smatrix Base Thermostat Public T-143
(public thermostat T-143)
• Uponor Smatrix Base PRO Room Sensor+RH T-141
(sensor thermostat T-141)
• Uponor Smatrix Base Slave Module M-140 (slave
module M-140)
• Uponor Smatrix Base Star Module M-141 (star
module M-141)
• Uponor Smatrix Transformer A-1XX (transformer
A-1XX)
System example
1 2 3
1 2
U P O N O R S M AT R I X B A S E P R O · Q U I C K G U I D E
4
3 4
