MLC 104 IP Plus L

6.50"
(16.5 cm)
Cut-Out Template for Extron's
MLC 104 IP Plus L
3.15" (8.0 cm)
2.8" (7.1 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
TEMPLATE IS NOT FULL SIZE.
MLC 104 IP Plus Series • Reference Material
Top Panel
Location of MLC 104 IP Plus
To install the MLC
104 IP Plus L
directly into furniture,
cut along this line.
.250" (.64 cm)
.295" (.75 cm)
145
