MLC 104 IP Plus AAP and MLC 104 IP Plus DV+

8.23"
(20.9 cm)
Cut-Out Template for the Extron
MLC 104 IP Plus AAP
MLC 104 IP Plus DV+
4.50" (11.43 cm)
2.8" (7.1 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
TEMPLATE IS NOT FULL SIZE.
MLC 104 IP Plus Series • Reference Material
Location of MLC 104 IP Plus
To install the MLC
104 IP Plus AAP/DV+
directly into furniture,
cut along this
solid line.
Top Panel
144
