Tele Radio Jaguar
MANUAL
Rev. IM-T70-003-A1

Advertisement

Table of Contents
loading

Related Manuals for Tele Radio T70 Jaguar

Summary of Contents for Tele Radio T70 Jaguar

  • Page 1 Tele Radio Jaguar MANUAL Rev. IM-T70-003-A1...
  • Page 2 CONTENTS...
  • Page 3 TELE RADIO SETTINGS DOCUMENT Download for print at: www.tele-radio.com TRANSMITTER(S) TRANSMITTER 1 Article no:_______________________________Series no: _______________________________ ID code (T70TX-08ERB): ________________________ Automatic shutoff: ______________________________ Operating Mode: _______________________________ Function Selection: 1 TRANSMITTER 2 Article no:_______________________________Series no: _______________________________ ID code (T70TX-08ERB): ________________________ Automatic shutoff: ______________________________...
  • Page 4 FREQUENCY BANK CHANNEL FREQ.BANK 3 OPTION CHANNEL FREQ.BANK 1 OPTION 433.125 433.075 433.225 433.175 433.325 433.275 433.425 433.375 433.525 433.475 433.625 433.575 433.725 433.675 433.825 433.775 433.925 433.875 434.025 433.975 434.125 434.075 434.225 434.175 434.325 434.275 434.425 434.375 434.525 434.075 434.625 434.075 CHANNEL...
  • Page 5 RECEIVER T70RX-09SB the yellow power supply LED the red CODE STORING LED the yellow LATCH LED the green INTERLOCKING LED LOGOUT LED Receiver switch Antenna connector FUNCTION button SELECT button 48-230 12-24 VAC/DC T70RX-15SB the yellow power supply LED the red CODE STORING LED the yellow LATCH LED the green INTERLOCKING LED LOGOUT LED...
  • Page 6 TRANSMITTER START START T70TX-06TTB 1. red LED 2. ON button 3. OFF button T70TX-08ERB 1. rubber cover 2. STOP button 3. yellow LED1 4. red/ green LED 5. yellow LED 2 6. button 7- START button 7. button 8- START button...

  • Page 7: Get Started

    ASSEMBLING, INSTALLING, PROGRAMMING AND USING TELE RADIO PRODUCTS. Tele Radio cannot be held responsible for any damage or other fault caused by a failure to follow the instructions. Doing so may invalidate the warranty. IT IS YOUR RESPONSIBILITY TO FIND OUT ABOUT...

  • Page 8: Technical Data

    1.3 TECHNICAL DATA THE SYSTEM OPERATING FREQUENCY: 433.075-434.650 MHz. CHANNEL: 64 (divided into 4 banks) CHANNEL SEPARATION: 25 kHz. RECEIVER T70RX-09SB 9 relays T70RX-15SB 15 relays (with expansion board) WEIGHT: 700 grams (15 relays) TRANSMITTER T70TX-08ERB SIZE: 95 x 185 mm. (incl. rubber cover) WEIGHT: 300 grams (incl.
  • Page 9 1.5 CHECK THE CONTENTS Check that you have got the product that you ordered. If anything is missing, please contact your dealer immediately. The delivery also contains: 3 alkaline batteries for the transmitter 1 connection comb 1 installation and programming instruction manual 1.6 CONNECT THE RECEIVER Check that you have connected the power supply to the correct connection terminal.

  • Page 10: Transmitter Id Code

    1.8 INSTALL BATTERIES IN THE TRANSMITTER 1.8.1 On the T70TX-06TTB transmitter Remove the clip. Remove the battery cover. Put the batteries in. Put back the battery cover (2 screws). Put back the clip (2 screws). For optimum performance, use alkaline batteries. NOTE! If you need to change the frequency bank, we recommend doing this before putting back the battery cover and clip.

  • Page 11: Transmitter Settings

    2 TRANSMITTER SETTINGS 2.1 Starting/ turning the transmitter off 2.1.1 Starting T70TX-06TTB 1. Press the ON button for at least 1 second. When the transmitter is active, the transmitter LED flashes red. When transmitting, the transmitter LED lights red continuously. 2.1.2 Turning off T70TX-06TTB Press the OFF button.
  • Page 12 2.2 AUTOMATIC SHUTDOWN SETTINGS 2.2.1 T70TX-06TTB transmitter The transmitter will turn off after1 minute idle. This cannot be adjusted. 2.2.2 T70TX-08ERB transmitter Automatic shutdown means that the transmitter will switch itself off, if you do not press a button for 1 minute (you can adjust this time according to the table below). The transmitter does not log off from the receiver when it is automatically shut down.
  • Page 13 4. Enter the security code 1, 2, 3, 4 (up to 4 seconds between each number). The transmitter LED starts to flash green and yellow transmitter LED 2 goes out. 5. Enter your choice 1-5: ______________________ 1= no automatic shutdown 2= 1 minute 3= 3 minutes 4= 6 minutes...

  • Page 14: Frequency Settings

    2.3 FREQUENCY SETTINGS If your product will be used in an area with very little risk of interference from other radio-controlled equipment, skip this section. If necessary, you can switch the frequency at a later date. (See the first pages of the manual for frequency table). 2.3.1 Switch frequency bank on T70TX-06TTB NOTE! IF YOU NEED TO SWITCH FREQUENCY BANK, WE RECOMMEND DOING THIS BEFORE REPLACING THE BATTERY COVER AND CLIP.
  • Page 15 2.3.2 Moving up and down within a frequency bank on T70TX-06TTB The user can move up and down within a frequency bank while using the transmitter. This can be useful if there is a major risk of interference within the work area. The default setting is channel 1 in frequency bank 1.
  • Page 16 2.3.3 Move more than one step on the T70TX-06TTB If you want to move several steps in frequency, you will need to restart the transmitter after every step. In this case you don´t have to wait until the receiver connects to the transmitter.
  • Page 17 4. Enter the security code 1, 2, 3, 4 (up to 4 seconds between each number). CHANNEL FREQ.BANK 1 OPTION The green LED flashes and yellow LED 2 goes out. 433.075 433.175 5. Press the 3-digit number for OPTION (See the first pages of the manual for 433.275 frequency table).
  • Page 18 2.4.1 Settings to move up and down within a frequency bank on T70TX-08ERB Decide how to move up and down within a frequency bank. Skip this section if you do not want to change the default settings. 1. SAVE NEW FREQUENCY (default setting).
  • Page 19 4. Enter the security code 4, 6, 3, 5 (up to 4 seconds between each number). The transmitter LED flashes green. Yellow transmitter LED 2 lights up. 5. Enter your choice: 1. SAVE NEW FREQUENCY 2. TEMPORARY MOVE 3. OFF The transmitter turns off.
  • Page 20 2. Release button 7. Keep button 8 pressed. 1a. Keep button 8 pressed. Press 1 to move DOWN within the frequency. Yellow transmitter LED 1 lights up. 1b. Keep button 8 pressed. Press 2 to move UP within the frequency. Yellow transmitter LED 2 lights up.
  • Page 21 3. Release button 8. Within 0.3 seconds: Press button 2. Yellow transmitter LED 2 lights up and the transmitter LED flashes green. If you exceed the 0.3 second interval, the transmitter will exit the programming mode and starts up. 4. Enter the security code 3, 4, 4, 3 (up to 4 seconds between each number). The green transmitter LED starts to flash.

  • Page 22: Receiver Settings

    3 RECEIVER SETTINGS 3.1 FUNCTION SELECTION You can make several selections to decide how to use your system. Some of the settings are made on the transmitter, others are made on the receiver. You can see the Function Selections available for your transmitter in this section. This is followed by the selections that you can do on the receiver.
  • Page 23 2. Release button 7. Keep button 8 pressed. 3. Release button 8. Within 0.3 seconds: Press 1. Yellow transmitter LED 2 lights up. The transmitter LED flashes green. 4. Enter the security code 1,2,3,4 (up to 4 seconds between the numbers). The transmitter LED starts flashing green and yellow transmitter LED 2 goes out.

  • Page 24: Operating Mode

    3.2 OPERATING MODE There are two receiver models available (see pictures in the first pages of the manual): T70RX-09SB- 9 relays T70RX-15SB- 15 relays (with expansion card) With the T70TX-08ERB transmitter you can choose functionality for the system by choosing one of the preset Operating Modes (see overview on next page).
  • Page 25 OPERATING MODE TWO- INTER- LATCHING RELAYS RECEIVERS BUTTONS LOCKING programmable programmable 9 or 15 MODE MODE 9 or 15 programmable programmable automatic MODE automatic MODE automatic automatic MODE automatic automatic MODE automatic automatic not possible not possible MODE automatic not possible MODE...

  • Page 26: Select Operating Mode

    3.3 SELECT OPERATING MODE SELECT OPERATING MODE BEFORE STORING THE TRANSMITTER! 1. Open the receiver (4 screws). 2. Enter the settings on the receiver switch in accordance with the picture shown for each Operating Mode. In some Operating Modes you can decide whether to put the switch in ON or OFF position, depending on what functionality you want for the receiver.
  • Page 27 3.3.3 Operating Mode 2 TRANSMITTER: T70TX-08ERB RECEIVERS: 1-2 receiver(s) with 9/ 15 relays NUMBER OF TRANSMITTERS: 1-3 4/10 5/11 LATCHING: Available on relays 4-15 INTERLOCKING: Available on relays 4/5, 6/7, 8/9, 10/11, 12/13 och 14/15. 6/12 7/13 FUNCT. SELECT 1: Yes.
  • Page 28 3.3.5 Operating Mode 4 TRANSMITTER: T70TX-08ERB RECEIVERS: 1 receiver with 15 relays NUMBER OF TRANSMITTERS: 1-3 LATCHING: Available on relays 14 and 15 INTERLOCKING: Automatic on relays 4/5/6, 7/8/9 and 10/11/12 MODE-SPECIFIC: Relay 13 is not used FUNCT. SELECT 1: Not possible FUNCT.
  • Page 29 3.3.7 Operating Mode 6 TRANSMITTER: T70TX-08ERB RECEIVERS: 1 receiver with 15 relays NUMBER OF TRANSMITTERS: 1-3 LATCHING: Available on relays 14 and 15 INTERLOCKING: Automatic on relays 4/5/6/7, 8/9/10 and 11/12/13 FUNCT. SELECT 1: Not possible 8/10 9/10 FUNCT. SELECT 2: Yes.
  • Page 30 3.3.9 Operating Mode 8 TRANSMITTER: T70TX-08ERB RECEIVERS: 1 receiver with 15 relays NUMBER OF TRANSMITTERS: 1-3 LATCHING: Not possible INTERLOCKING: Available on relays 4/5/6, 7/8/9, 10/11/12 and 13/14/15 FUNCT. SELECT 1: Not possible FUNCT. SELECT 2: Yes. Func. Select. 2. must be selected on the transmitter. Transmitter button 8 controls the receiver via the yellow transmitter LEDs.
  • Page 31 3.4 CHANGE OF LED THAT LIGHTS UP DURING STARTUP 3.4.1 On the T70TX-06TTB transmitter The transmitter does not have this option. 3.4.2 On the T70TX-08ERB transmitter Applies to T70TX-08ERB with Function Selection 2. You can select how the yellow LEDs on the transmitter will light up when you start the transmitter.
  • Page 32 4. Enter the security code 7, 4, 8, 3 (up to 4 seconds between the numbers). The green LED starts to flash and yellow LED 2 goes out. 5. Enter your choice: 1. No yellow LED lights up 2. Yellow LED 1 lights up 3.
  • Page 33 1. Start the transmitter by pressing the START buttons 7 and 8 for at least 1 second. 2. Release button 7. Keep button 8 pressed. 3. Release button 8. Within 0.3 seconds: Press 1. Yellow LED 2 lights up. The LED starts to flash green. 4.

  • Page 34: Latching Relay Function

    6. Re-start the transmitter by pressing the START buttons 7 and 8 for at least 1 second. 3.6 LATCHING RELAY FUNCTION In some Operating Modes you can assign a latching function to certain relays (see description of Operating Modes). Latching Receiver means that the relay is activated every time a button is pressed, switch...
  • Page 35 3.7 INTERLOCKING RELAY FUNCTION In some Operating Modes you can assign an interlocking function to certain relays (see description of Operating Modes). Interlocking means that you can prevent selected relays from activating at the same time, even if the buttons Receiver switch are pressed at the same time, e.g.
  • Page 36 3.8 STORE THE TRANSMITTER IN THE RECEIVER NOTE! Do not store the transmitter in the receiver until you have selected Operating Mode. Depending on receiver model, you can store 1-3 transmitters. If the maximum number of transmitters has already been stored, all transmitters must be erased before you can store the transmitters that you want.
  • Page 37 3. Press the receiver’s SELECT button. All red relay LEDs will light up. The receiver will now start to search for and connect to the transmitter. 4. When the transmitter has been stored, the red relay LEDs on the receiver will flash 3 times. 5.
  • Page 38 2. Hold down the FUNCTION button and the SELECT button for more than 10 seconds. After 10 seconds, the receiver’s memory has been erased. 3.11 LOGOUT TRANSMITTERS 3.11.1 On the T70TX-06TTB transmit- There is no LOGOUT function on this transmitter. 3.11.2 On the T70TX-08ERB transmit- If you want to use more than one stored transmitter with your receiver, you must LOGOUT the transmitter that you used last.
  • Page 39 LOGOUT 2- only if button 7 is not used for a high-risk function 1. Start the transmitter you want to log out. 2. Press button 7. 3. Press the STOP button without releasing button 7. The red transmitter LED lights up for 1 second. Yellow transmitter LED 1 flashes.
  • Page 40 REPLACE TRANSMITTERS On the TX1-C transmitter There is no replacing function on this transmitter. On the TX2 transmitter To replace a lost or broken transmitter with a new, without having to use the receiver. Simply use the new transmitter for all button operations. NOTE! The new transmitter must use the same frequency bank as the transmitter that is being replaced.
  • Page 41 THE REMOVABLE RUBBER COVER On the TX2 transmitter The TX2 transmitter comes with a removable rubber cover that helps prevent the transmitter from bumps, dirt and dust. The rubber cover can be easily removed and wiped off. THE RUBBER COVER MUST BE REMOVED TO: 1.
  • Page 42 LOCATE THE IC AND FCC LABELS 1. Reveal the product information label (see picture). 2. Reveal the FCC and IC label (see picture below). On the TX1-C transmitter 1. Remove the clip (2 screws). 2. Remove the battery lid (2 screws) and the batteries.
  • Page 43 On the TX2 transmitter 1. Remove the battery lid (2 screws) and the batteries. 3. The FCC and IC labels are placed on the inside of the battery compartment. The FCC label is placed on the right side. The IC label is placed on the left side.

  • Page 44: Fcc Statements

    During the guarantee period Tele Radio may replace the product or faulty parts with new ones. Work under warranty must be carried out by Tele Radio or by an authorized service centre specified by Tele Radio.
  • Page 45 TELE RADIO AB Sweden, Main office Tel. +46 (0)31-748 54 60 www.tele-radio.com e-mail: info@tele-radio.com TELE RADIO BV TELE RADIO SVERIGE TELE RADIO OÜ Sweden Estonia Benelux Tel. +46 (0)31-724 98 00 Tel. +372 44 511 55 Tel. +31-(0)70-419 41 20 e-mail: info@teleradio.nl...
